All LED Excalibur ASPK500F Installation Manual & User Manual

Safety
• Do not cover the ground contact.
• Do not cover the luminaire, hang or fasten anything from it.
• Do not operate if any visible damage can be seen to the product.
• Do not operate if any water ingress has occurred.
• Do not operate if any smoke, steam or crackling noises can be heard from the luminaire.
• Do not operate if any signs of overheating are recognised.
• Avoid installation in any areas where there is a risk of strong mechanical loads.
• Do not place any material over the lens or LED diode/chip.
• Do not insert objects into the luminaire.
• Do not clean using any solvent based abrasive or aggressive product.
• Do not pull any cables connected to the product.
• Do not direct the luminaire into a person's eyes, as this unit may have an intense light output, which if incorrectly
used may cause eye damage.
• Light engines/LEDs and other light sources may heat up, please take care when handling the products.
• The manufacturer will not be deemed liable or held responsible for any damages caused by faults or manufacturing
defects that may be present in any of its products or the misuse or incorrect installation of this device. Please refer to
our troubleshooting guide for further information.
• The manufacturer will not be held liable for any death(s) or injuries caused by misuse or poor installation or any
unreported faults of this product version or versions thereof. LEDs are sensitive to electrostatic discharge. Do not
touch the surface of the LED module.
• Do not connect to a temporary electricity supply, this may damage the electronics.
• Light fittings with an integrated emergency option come with a separate installation and wiring leaflet.
• Please refer to this manual for further details. If the manual is unavailable please contact an ALL LED representative
for assistance.
• It is strongly recommended that a Residual-Current Device (RCD) is used with this product to minimise the risk of
electrocution.
• REPLACE DAMAGED ITEMS IMMEDIATELY.
• Keep away from children.
• Do not install in areas with; high acid rain, acidic soil, high salt content, coastal environments, high concentration of
chemical substances.
• Do not remove, or attempt to remove, open or tamper with the lens assembly as this will void any warranty
Returns & Faulty Items
• If any problem is encountered during or after installation, please call ALL LED technical department to get the
problem resolved as soon as possible.
• Please do not just return the item to the outlet you purchased it from, as you are only entitled to a replacement or
refund after the unit has undergone testing and the unit has been confirmed as having a manufacturing defect/fault.
Your statutory rights are not affected.
• The manufacturer will not be deemed liable or held responsible for any damages caused by faults or manufacturing
defects that may be present in any of its products or the misuse or incorrect installation of this device. Please refer to
our troubleshooting guide for further information.
• All installations must be carried out in accordance with this installation guide and user manual.
• All goods are supplied under the terms and conditions of ALL LED LTD, a copy of which may be obtained upon
written request.
Environmental Protection
Waste electrical products should
not be disposed of with household
waste. Please recycle where
facilities exist. Check with your
Local Authority or retailer for
recycling advice
The manufacturer will not be deemed liable or held responsible for any damages
caused by faults or manufacturing defects that may be present in any of its products
or the misuse or incorrect installation of this device
Your statutory rights are not affected.
ENSURE POWER SUPPLY IS OFF WHEN HANDLING ANY ELECTRICAL EQUIPMENT.
• This product must be installed by a qualified electrical installer.
• All electrical work should be completed in accordance with the latest IET regulations, or any other relevant rules,
regulations or laws of the country in which it is being installed.
• This item is suitable for humid environments when installed correctly and carries an ingress protection rating of IP65.
• This item is suitable for installation on the ground, however please ensure the item is isolated from any areas where it
can be knocked over or could pose a risk to people.
• Ensure the spike accessory is firmly pushed into the ground and install in an area where the ground has good
drainage and is not permanently wet.
• Ensure power supply is isolated prior to installation, maintenance or performing any other form of electrical work.
• The company MUST be contacted immediately for advice or swift resolution of any matters concerning any of ALL
LED's products.
• Ensure the luminaire is installed at least 0.5M from any objects. Please be mindful of dry foliage or similar flammable
materials that may cause a fire risk.
Technical Specifications
Product Code
Luminous Flux (LM)
Useful Luminous Flux (LM)
CCT (Kelvin)
Beam Angle (°)
SDCM
CRI
Operating Voltage (V)
Max Output Power (W)
Operating Current (A max)
Power Factor (Pf)
Body Material
Frame Colour
ALL LED LTD
Switching Cycles
42 Sedgwick Road,
Luton, LU4 9DT
Ingress Protection
Ambient Operating Temperature (°C)
www.allledgroup.com
sales@allledgroup.com
Input Frequency (Hz)
Tel: +44 (0)208 841 9000
Guarantee
Cable Length
Life Time (L70 B50)
Lumen Maintenance Factor
INSTALLATION GUIDE & USER MANUAL
ASPK500F
ASPK500F/30
420
410
3000K
30°
<6
≥80
220-240V
5W
0.022
>0.5
Aluminum
Black
100,000
IP65
-30°C~65°C
50/60Hz
2 Years
2M
25,000
7%
!
PLEASE READ
BEFORE USE!
ASPK500F/40
440
420
4000K
30°
<6
≥80
220-240V
5W
0.022
>0.5
Aluminum
Black
100,000
IP65
-30°C~65°C
50/60Hz
2 Years
2M
25,000
7%
