All LED ADIM/150W Installation Manual

Returns & Faulty Items
• If any problem is encountered during or after installation, please call the All LED technical
department to get the problem resolved as soon as possible.
• Please do not just return the item to the outlet you purchased it from, as you are only entitled to
a replacement or refund after the unit has undergone testing and the unit has been confirmed as
having a manufacturing defect/fault. Your statutory rights are not affected.
• The manufacturer will not be deemed liable or held responsible for any damages caused by faults
or manufacturing defects that may be present in any of its products or the misuse or incorrect
installation of this device. Please refer to our troubleshooting guide for further information.
• All goods are supplied under the terms and conditions of All LED LTD, a copy of which may be
obtained upon written request.
Dimensions
Environmental Protection
Waste electrical products should
not be disposed of with household
waste. Please recycle where
facilities exist. Check with your
Local Authority or retailer for
recycling advice
The manufacturer will not be deemed liable or held responsible for any damages
caused by faults or manufacturing defects that may be present in any of its products
or the misuse or incorrect installation of this device
Your statutory rights are not affected.
ENSURE POWER SUPPLY IS OFF WHEN HANDLING ANY ELECTRICAL EQUIPMENT.
• This product may need to be installed by a qualified electrical installer.
• Please read this guide in its entirety to fully understand the products before attempting any install.
• All electrical work should be completed in accordance with the latest IET regulations, and/or any
other relevant rules, regulations or laws of the country in which it is being installed.
• The item must be installed in isolation from any insulating material and is adequately ventilated to
prevent premature failure.
• Ensure power supply is isolated prior to installation, maintenance or performing any other form of
electrical work.
• In the event of incorrect or improper function with specific regard to any of ALL LED's products
and contact ALL LED for further advice.
Technical Specifications
Product Code
Operating Voltage
Operating Current (A Max)
Output Power
PF
No Load Power (W)
Class
Body Material
Ingress Protection
Ambient Operating Temperature (°C)
ALL LED LTD Input Frequency (Hz)
42 Sedgwick Road,
Luton, LU4 9DT
Guarantee
www.allledgroup.com
Dimming Mode (Trailing or Leading)
sales@allledgroup.com
Tel: +44 (0)208 841 9000
INSTALLATION GUIDE
ADIM/150W
ADIM/150W
220-240V
0.7A
5W - 150W LED
≥0.83
0W
II
Polycarbonate
IP20
-10°C~40°C
50Hz
2 Years
Fully Programmable - Leading Edge And Trailing Edge (2 Modes)
!
PLEASE READ
BEFORE USE!
1
