All LED ADRCV1215 Installation Manual & User Manual

Safety
• Do not cover the ground contact.
• Do not cover the item, hang or fasten anything from it.
• Do not operate if any visible damage can be seen to the product.
• Do not operate if any water ingress has occurred.
• Do not operate if any smoke, steam or crackling noises can be heard from the item.
• Do not operate if any signs of overheating are recognised.
• Avoid installation in any areas where there is a risk of strong mechanical loads.
• Do not place any material over the item.
• Do not insert objects into the item.
• Do not clean using any solvent based abrasive or aggressive product.
• Do not pull any cables connected to the product.
• Light engines/LEDs, other light sources and lighting products may heat up, please take care when handling the
products.
• The manufacturer will not be deemed liable or held responsible for any damages caused by faults or manufacturing
defects that may be present in any of its products or the misuse or incorrect installation of this device. Please refer to
our troubleshooting guide for further information.
• The manufacturer will not be held liable for any death(s) or injuries caused by misuse or poor installation or any
unreported faults of this product version or versions thereof.
• Do not connect to a temporary electricity supply, this may damage the electronics.
• Isolate the item from direct, strong sunlight.
• Keep away from children.
Returns & Faulty Items
• If any problem is encountered during or after installation, please call ALL LED technical department to get the
problem resolved as soon as possible.
• Please do not just return the item to the outlet you purchased it from, as you are only entitled to a replacement or
refund after the unit has undergone testing and the unit has been confirmed as having a manufacturing defect/fault.
Your statutory rights are not affected.
• The manufacturer will not be deemed liable or held responsible for any damages caused by faults or manufacturing
defects that may be present in any of its products or the misuse or incorrect installation of this device. Please refer to
our troubleshooting guide for further information.
• All goods are supplied under the terms and conditions of ALL LED LTD, a copy of which may be obtained upon
written request.
Environmental Protection
Waste electrical products should
not be disposed of with household
waste. Please recycle where
facilities exist. Check with your
Local Authority or retailer for
recycling advice
The manufacturer will not be deemed liable or held responsible for any damages
caused by faults or manufacturing defects that may be present in any of its products
or the misuse or incorrect installation of this device
Your statutory rights are not affected.
ENSURE POWER SUPPLY IS OFF WHEN HANDLING ANY ELECTRICAL EQUIPMENT.
• This product may need to be installed by a qualified electrical installer.
• Please read this guide in its entirety to fully understand the products before attempting any install.
• All electrical work should be completed in accordance with the latest IET regulations, and/or any other relevant rules,
regulations or laws of the country in which it is being installed.
• The item must be installed in isolation from any insulating material and is adequately ventilated to prevent premature
failure.
• Ensure power supply is isolated prior to installation, maintenance or performing any other form of electrical work.
• The company MUST be contacted immediately for advice or swift resolution of any matters concerning any of ALL
LED's products.
Technical Specifications
Product Code
Operating Voltage
Operating Current (A Max)
Max Output Power
Output Current (Max)
Output Voltage (Max)
PF
Efficiency %
No Load Power (W)
Dimmable
Class
Body Material
Frame Colour
Switching Cycles
Ingress Protection
Ambient Operating Temperature (°C)
Input Frequency (Hz)
Guarantee
ALL LED LTD
Lifetime
42 Sedgwick Road,
Displacement Factor
Luton, LU4 9DT
Inrush Current
www.allledgroup.com
Over Temperature Protection
sales@allledgroup.com
Tel: +44 (0)208 841 9000
Overload Protection
No Load Protection
INSTALLATION GUIDE & USER MANUAL
ADRCV1215
!
PLEASE READ
BEFORE USE!
ADRCV1215
220-240V
0.2A
15W
1.25A
12V
>0.7
78%
<0.5W
No
II
Polymer
White (Orange Caps)
>100,000
IP20
-20°C ~ +50°C
50/60Hz
3 Years
30,000H
>0.7
20A, 0.1μs
Yes
Yes
Yes
