CAME A3024N Installation Manual
Swing-gate gearmotor
Hide thumbs
Also See for A3024N:
- Installation manual (13 pages) ,
- Installation manual (13 pages) ,
- Installation manual (49 pages)
Related Manuals for CAME A3024N
Summary of Contents for CAME A3024N
- Page 1 Swing-gate gearmotor FA02040-EN A3024N A5024N A3124N English INSTALLATION MANUAL...
- Page 3 Machinery Directive (2006/42/EC) and with the reference harmonised technical standards are specified in the general CAME product catalogue or on the website www.came.com. • Make sure the mains power supply is disconnected during all installation procedures. • Check that the temperature ranges given are suitable for the installation site.
-
Page 4: Dismantling And Disposal
DISMANTLING AND DISPOSAL CAME S.p.A. employs an Environmental Management System at its premises. This system is certified and compliant with the UNI EN ISO 14001 standard to ensure that the environment is respected and safeguarded. Please continue safeguarding the environment. At CAME we consider it one of the fundamentals of our operating and market strategies. -
Page 5: Intended Use
Description 001A3024N A3024N - Irreversible gearmotor 24 V for swing gates with leaf up to 3 m and 400 kg. 001A5024N A5024N - Irreversible gearmotor 24 V with opening and closing micro limit switch for swing gates with leaf up to 5 m and 400 kg. - Page 6 (**) The average product life specified should be understood purely as an indicative estimate. It applies to normal usage conditions and where the product has been installed and maintained in compliance with the instructions provided in the CAME technical manual. The average product life is also affected, including significantly,...
-
Page 7: Installation
Cable types and minimum thicknesses Cable length (m) up to 20 from 20 to 30 Power supply 24 V AC 4G x 1.5 mm² 4G x 2.5 mm² If the cable lengths differ from those specified in the table, define the cable cross-sections according to the actual power draw of the connected devices and in line with regulation CEI EN 60204-1. - Page 8 Deciding where to fasten the brackets Install with the gate closed. Respect the values indicated in the table. The gate bracket and pillar bracket must be aligned horizontally. A3024N A3124N Gate-leaf opening (°) Max. C A5024N Gate-leaf opening (°) Max. C...
-
Page 9: Fastening The Brackets
Fastening the brackets With the gate closed, fasten the anchoring plate and bracket to the gate. Fasten in place with screws or weld the bracket to the gate. The holes on the bracket fixing plate allow you to vary the opening angle of the gate leaf. ø... - Page 10 Fastening the gearmotor Lubricate all moving parts on the operator.
- Page 11 Determining the opening end-of-travel points Perform these operations on both gearmotors. Release the gearmotor. Manually open the leaf to the desired point. Unscrew the screws in the opening microswitch assembly. Slide the microswitch assembly along the boom until it is activated by the slide guide fixed on the nut bushing. Secure the microswitch assembly to the boom again using the screws.
-
Page 12: Electrical Connections
Determining the closing slowdown travel end points Perform these operations on both gearmotors. Release the gearmotor. Manually close the leaf to the desired point. Unscrew the screws in the closing microswitch assembly. Slide the microswitch assembly along the boom until it goes beyond the contact point with the slide guide fixed on the nut bushing. Activation of the microswitch (cam pressed) signals the starting point for the closing slowdown phase. - Page 13 Control panel Gearmotor delayed while opening Gearmotor delayed while closing 230 V AC - 50-60 HZ power supply input Yellow/green cable M N R M N R M1 N1 ENC1/RALL1 M2 N2 ENC2/RALL2...
- Page 14 Weld the pillar bracket to an additional bracket and position it in place. Open the gate a maximum of 90° and take measurement E. Fasten the second bracket to the gate. Additional bracket (not included) A3024N A3124N Gate-leaf opening (°) A5024N...
-
Page 15: Final Operations
Electrical connections Where there is only one gearmotor in the system, make the electrical connections on the gearmotor (M2). Control panel Gearmotor delayed while opening Gearmotor delayed while closing 230 V AC - 50-60 HZ power supply input Yellow/green cable M1 N1 ENC1/RALL1 M2 N2 ENC2/RALL2 M N R... - Page 16 Check the release mechanism is working efficiently by performing a manoeuvre with the leaf free. The gate leaf must not be obstructed. Check the cables are intact and connected correctly. CAME S.p.A. Via Martiri della Libertà, 15 31030 Dosson di Casier Treviso –...
