User Manual
AU-X2I-DA
DANTE 2CH XLR INPUT ADAPTER
(HW Rev. 2)
All Rights Reserved
Version: AU-X2I-DA_2024V1.4
DANTE 2CH XLR INPUT ADAPTER
Product Introduction
Thanks for choosing the AU-X2I-DA. The device inputs
2 channels of analog line level audio to be distributed
through your Dante network, supporting sampling rates
up to 96kHz, using Audinate's original Dante Ultimo chip.
Features
⚫
Plug and Play
Dante and AES67 support
⚫
⚫
24-bit audio support
⚫
2X0 audio channels
⚫
Supports 802.3af PoE
Packing List
1x AU-X2I-DA
⚫
1x User Manual
⚫
Note: Please contact your distributor immediately if
any damage or defect in the components is found.
Panel Description
2
2
AU-X2I-DA
1
2CH Analog Input
MAC and SN
1.
RJ45: Dante network communication port.
Green steady light indicates link; yellow flashing
light indicates data traffic. The green light will
flash to identify the device when clicking the
Dante Controller "Identify" button (an eye-shaped
symbol) on the host computer.
2.
XLR: 2 x XLR-F connectors, for input signal
Advertisement
Related Manuals for TiGHT AV AU-X2I-DA
Summary of Contents for TiGHT AV AU-X2I-DA
- Page 1 DANTE 2CH XLR INPUT ADAPTER Panel Description Product Introduction Thanks for choosing the AU-X2I-DA. The device inputs 2 channels of analog line level audio to be distributed through your Dante network, supporting sampling rates up to 96kHz, using Audinate’s original Dante Ultimo chip.
- Page 2 Bit Depth Customer Service 1, 2 or 5ms (configurable Packaging recycling information TiGHT AV provide a limited warranty for the product Dante Device Latency using Dante Controller) Note: This manual is recycled as paper (mixed paper within five years counting from date of purchase (The and card).
