- Page 1 User Manual AU-X2IPRO-DA DANTE 2CH INPUT ADAPTER All Rights Reserved Version: AU-X2IPRO-DA _2023V1.0...
- Page 2 DANTE 2CH INPUT ADAPTER Product Introduction Thanks for choosing the AU-X2IPRO-DA. The device inputs 2 channels of analog audio to be distributed through your Dante network, supporting sampling rates up to 96kHz using Audinate’s original Dante Ultimo chip. Features Plug and Play •...
- Page 3 DANTE 2CH INPUT ADAPTER Panel Description ① Dante(PoE): Dante network ② DC12V: Connect to DC12V power communication port. ③ Input: 1x 6-pin terminal block, for 2 adapter(sold separately). channel input audio signal. ④ Reset: 1x button, pressing and hold 5s for factory default.
- Page 4 DANTE 2CH INPUT ADAPTER ⑤ SENSITIVITY: 2x 5-pin Dip switch for adjusting input sensitivity between +24dBu to -10 dBV per channel. The default setting is +24dBu. LED status According to the working condition of Dante, the network port lights will have different states: Green LED Yellow LED...
- Page 5 DANTE 2CH INPUT ADAPTER Technical Specification Audio +24 dBu / +4 dBu / 0 Max input level (balanced) dBu/ 0 dBV /-10 dBV Frequency 20Hz to 20kHz (-/+0.5dB) Response 7.2k Ohm balanced Impedance 3.6k Ohm unbalanced Dynamic >100 dB Range Signal to >100 dB Noise Ratio...
- Page 6 Compliance FCC, CE Environmental RoHS, REACH, WEEE Customer Service TiGHT AV provide a limited warranty for the product within five years counting from date of purchase (The purchase invoice shall prevail). For more information see TiGHT AV general Warranty Statement at...
- Page 7 DANTE 2CH INPUT ADAPTER Environment and recycle information Disposal of electric and electronic devices EC Directive 2012/19/EU This product is not to be treated as regular household waste but must be returned to a collection point for recycling electric and electronic devices.
