OPERATOR'S MANUAL
INVERTER AC/DC PULSED TIG WELDER
SANARG 180AP
IMPORTANT: Read this Owner's Manual Completely before attempting to use this
equipment. Save this manual and keep it handy for quick reference. Pay particular
.
attention to the safety instructions we have provided for your protection. Contact your
distributor if you do not fully understand this manual.
Date: 11/24/24

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SANARG 180AP and is the answer not in the manual?

Questions and answers

Related Manuals for SanRex SANARG 180AP

Summary of Contents for SanRex SANARG 180AP

  • Page 1 OPERATOR’S MANUAL INVERTER AC/DC PULSED TIG WELDER SANARG 180AP IMPORTANT: Read this Owner’s Manual Completely before attempting to use this equipment. Save this manual and keep it handy for quick reference. Pay particular attention to the safety instructions we have provided for your protection. Contact your distributor if you do not fully understand this manual.

  • Page 2: Table Of Contents

    CONTENT 1 SAFETY --------------------------------------------------------------------------------------------------------------------------- 1 1.1 S ------------------------------------------------------------------------------------------------------- 1 IGNAL XPLANATION 1.2 A ---------------------------------------------------------------------------------------------------- 1 ELDING AMAGE 1.3 T ------------------------------------------------------------------- 5 HE KNOWLEDGE OF LECTRIC AND AGNETIC IELDS 2 SUMMARY ---------------------------------------------------------------------------------------------------------------------- 6 2.1 B ------------------------------------------------------------------------------------------------------- 6 RIEF NTRODUCTION 2.2 W -------------------------------------------------------------------------------------------------------- 8 ORKING RINCIPLE...

  • Page 3: Safety

    SAFETY 1 SAFETY 1.1 Signal Explanation  The above signals mean warning! Notice! Running parts and getting an electric shock or thermal parts will take damage for your body or others. The corresponding notices are as follows. It is quite a safe operation after taking several necessary protection measures.
  • Page 4 SAFETY semiautomatic welding gun are also electrically “hot”.  Always be sure the work cable makes a good electrical connection with the metal being welded. The connection should be as close as possible to the area being welded. Maintain the electrode holder, work clamp, welding cable and welding machine in good, safe operating condition.
  • Page 5 SAFETY the arc when welding or observing open arc welding.  Use suitable clothing made from durable flame-resistant material to protect your skin and that of your helpers from the arc rays.  Protect other nearby personnel with suitable, non-flaSMAWble screening and /or warn them not to watch the arc nor expose themselves to the arc rays or to hot spatter or metal.
  • Page 6 SAFETY cause an explosion even though they have been “cleaned”.  Vent hollow castings or containers before heating, cutting or welding. They may explode.  Sparks and spatter are thrown from the welding arc. Wear oil free protective garments such as leather gloves, heavy shirt, cuff less trousers, high shoes and a cap over your hair.

  • Page 7: The Knowledge Of Electric And Magnetic Fields

    SAFETY 1.3 The knowledge of Electric and Magnetic Fields Electric current flowing through any conductor causes localized Electric and Magnetic Fields (EMF). The discuss on the effect of EMF is ongoing all the world. Up to now, no material evidences show that EMF may have effects on health.

  • Page 8: Summary

    SUMMARY 2 SUMMARY 2.1 Brief Introduction SANARG 180AP welding machine adopts the latest pulse width modulation (PWM) technology and insulated gate bipolar transistor (IGBT) power module. Thus, it is characterized as portable, small size, light weight, low consumption and etc.
  • Page 9 4. For AC TIG (rectangle wave), arc is more stable than Sine AC TIG. SANARG 180AP welding machine is suitable for all welding positions on various plates made of stainless steel, carbon steel, alloyed steel, titanium, aluminum, magnesium, etc, which is also applied to pressure pipe, tool &...

  • Page 10: Working Principle

    SUMMARY 2.2 Working Principle The working principle of SANARG 180AP welding machines is shown as the following figure. , then by PFC circuit, DC (about single-phase 120/240VAC 50/60Hz. frequency is rectified into DC 380V) , then is converted to medium frequency AC (about 44K Hz) by inverter device (IGBT module), after reducing voltage by medium transformer (the main transformer) and rectifying by medium frequency rectifier (fast recovery diodes), then is outputted DC or AC by selecting IGBT module.

  • Page 11: Installation And Adjustment

    INSTALLATION AND ADJUSTMENT 3 Installation and Adjustment 3.1 Parameters model SANARG 180AP Parameters Rated input voltage（V） 1~120V±10%，50Hz 1~240V±10%，50Hz SMAW SMAW Rated input current（A） 27.8(AC) 29.2(AC) 21.7(AC) 25(AC) 26.6(DC) 27(DC) 21.4(DC) 23(DC) 3.7(AC) 3.7(AC) 5.0(AC) 5.8(AC) Rated input power（KW） 3.4(DC) 3.4(DC) 4.7 (DC)

  • Page 12: Duty Cycle & Overheat

    3.4 Power supply input connection SANARG 180AP welding machine operates on single-phase 120 - 240VAC primary power. When the power supply voltage is over voltage, there are over voltage and under voltage protection inside the welder, the alarm light will turn on, at the same time, the current output will turn off, If the power supply voltage continually goes beyond the safe work voltage range, it will shorten the welder lifespan.

  • Page 13: Polarity Connection（Smaw

    INSTALLATION AND ADJUSTMENT 3.5 Polarity Connection（SMAW） SMAW (DC): Choosing the connection of DCEN or DCEP according to the different electrodes. Please refer to the electrode Data Sheet. SMAW (AC): No requirements for polarity connection. SANARG SANARG 180AP 180AP Welding holder Welding holder electrode electrode...
  • Page 14 Consumable parts for TIG torch, such as tungsten electrode、tip、gas nozzle、electrode  shield(short/long) are 10N series common TIG Consumables.. When SANARG 180AP welding machine is operated in HF ignition method, the ignition spark  can cause interferences in equipment near the welding machine. Be sure to take specially...

  • Page 15: Operation

    MAINTENANCE AND TROUBLESHOOTING 4 Operation 4.1 Layout for the panel Negative output - Negative polarity output. Shield gas connector - Is connected to the gas input pipe of torch. Aero socket (Remote Receptacle) - Is connected to torch switch control wire. Positive output - Positive polarity output.

  • Page 16: Control Panel

    OPERATION 4.2 Control panel (4) Power/ Alarm indicator (6) Welding current display (2) Mode selecting key (3) Gas-test key (1) AC/DC selecting (7) HF (high-frequency) ignition key (8) Rod electrode welding key (9) Pulse key (5) Welding current adjust...
  • Page 17 The illustration below shows an overview of the main settings needed for day-to-day operation, using the SANARG 180AP control panel as an example. You will find a detailed description of these settings in the following section.
  • Page 18 OPERATION Tdown Available parameters where 2T and 4T mode have been selected: Gas pre-flow time Unit Setting range 0.1—10 Factory setting Starting current (only with 4T) Unit Setting range 5 - 100% of main current Iw (DC), 10 - 100% of main current Iw (AC) Factory setting Upslope time Unit...
  • Page 19 OPERATION Factory setting Important! Only selectable when “pulse key” has been pressed. Tdown Downslope time Unit Setting range 0 - 10 Factory setting Crater arc current (only with 4T) Unit Setting range 5 - 100% of main current Iw (DC)；10 - 100% of main current Iw (AC) Factory setting Gas post-flow time Unit...

  • Page 20: Remote Control

    OPERATION 4.3 Remote control 1-2 ：They are factory set, can’t be changed. If they are changed, the welder may not function. 1-2 ：They are factory set, can’t be changed. If they are changed, the welder may not function. 3 FOOT_REMOTE CONTROL SELECT： When it is ON, the Foot pedal control can be used； When it is OFF, the remote control can be used.

  • Page 21: Gun Switch / Current Control

    OPERATION 4.3.2 Gun switch / current control Current adjust buttons. Gun Trigger switch 4.4 Argon Arc Welding Operation 4.4.1 TIG welding – (4T operation with supplied Torch Switch） The start current and crater current can be pre-set. Pulsed TIG long welding（4T） ： I( A) Repress down the Welding current (peak...
  • Page 22 OPERATION t4: Press and Hold the gun switch closed, the output current slopes down to crater current; if the  output pulse function is turned on, the slope down current is pulsed; t4～t5: Down slope time, adjustment rang of down slope time: 0~10.0S; ...

  • Page 23: Tig Welding (2T Operation)

    OPERATION 4.4.2 TIG welding (2T operation) This function without the adjustment of start current and crater current. Pulsed TIG short welding（2T） ： I( A) Loosen the welding gun Welding current (peak switch current) setting value Base current setting value Striking Stop arc success t( s)

  • Page 24: Welding Parameters

    OPERATION ○ 3 SMAW operation： if the electrode touches workpiece over two seconds, the welding current will drop to the 0 automatically to protect the electrode. Prevent arc-break function： TIG operation， Avoid arc-break with special means, even if arc-break occurs the HF will keep the arc stable.

  • Page 25: Tig Parameters

    OPERATION TIG Parameters...

  • Page 26: Operation Environment

    OPERATION 4.6 Operation Environment ● Height above sea level is below 3280ft. ● Operation temperature range:-50 F～+204 ● Relative humidity is below 90 % (68 F), relative humidity is below 50 % (104 ● The inclination of the power source does not exceed 10 ●...

  • Page 27: Maintenance & Troubleshooting

    SETUP GUIDE 5 Maintenance & Troubleshooting 5.1 Maintenance To guarantee the arc welding power supply works efficiently and safely, it must be maintained regularly. Maintenance items detailed in the following table. ● Warning: For safety while troubleshooting the power supply, please shut off the input power and wait for 5 minutes! date Maintenance item...

  • Page 28: Troubleshooting

    SETUP GUIDE Using the dry compressed air to clear the inside of arc welding machine. Especially for clearing up the dusts on radiator, main voltage transformer, inductance, IGBT module, the Monthly fast recover diode and PCB, etc. examination Check up the bolt in arc welding machine, if it is loose, please screw down it. If it is skid, please replace.
  • Page 29 SETUP GUIDE Troubles Reasons Solution Adjust potentiometer Imin on the power value The max value is not accordant (refer to 3.1) board. displayed doesn’t accord with Adjust potentiometer Imaxin the current the set value. The min value is not accordant (refer to 3.1) meter.
  • Page 30 SETUP GUIDE Troubles Reasons Solution Working time too Reduce duty cycle (work long intermittently) Over-voltage Power supply Using the stable power supply protection fluctuates Power supply Using the stable power supply fluctuates Low-voltage Too many machines protection Reduce the machines using power using power supply supply in the same time in the same time...

  • Page 31: Electrical Principal Drawing

    SETUP GUIDE 5.3 Electrical principal drawing...
  • Page 32 MAINTENANCE & TROUBLESHOOTING Exploded View...
  • Page 33 MAINTENANCE & TROUBLESHOOTING Parts List Serial number material number material name quantity 8.462.116 Fast plug 1.00 7.232.735 switch 1.00 7.154.404 power cable 1.00 8.068.620 Rear panel 1.00 7.720.020 1.00 8.123.047 Connection lump 6.00 5.496.824-B control board 1.00 8.301.590 cover 1.00 8.253.020 handle 1.00...
  • Page 34 MAINTENANCE & TROUBLESHOOTING Part Number Quantity Item Description MAGIC 200 PFC DC inverter module Support bar （ 1 ） 8.123.641 4.00 8.425.595 Heat sink(6) 1.00 5.496.336-C MAGIC 200 PFC DC inverter board 1.00 7.411.021 bridge 1.00 7.421.541 2.00 8.713.182 Isolation lump 4.00 7.425.553 IGBT...

  • Page 35: Quick Setup Guide

    SETUP GUIDE 6 Quick Setup Guide This guide assumes the operator has a general understanding of TIG Welding. Please read and understand Section 1 safety, Section 3 Installation & Adjustment and Section 4 Operation in the owner’s manual that came with your 180AP. 180AP TIG Setup •...
  • Page 36 SETUP GUIDE • 2T/4T Remote Control – Select 2T (2 arrows one up one down) when using a foot control. Select 4T (2 Double arrows) when using the controls on the supplied TIG torch. AC/DC Selection – Selects AC or DC output. •...
  • Page 37 SETUP GUIDE Parameter setup Start left to right. Rotate the red knob to highlight the Parameter to adjust. The yellow light will illuminate to show selection. Push red knob to set parameter value. 1. Tpr - Gas Pre-Flow. Value in seconds. 2.
  • Page 38 SETUP GUIDE Press and hold close the ON/OFF button again. The Amperage  decreases at Down-Slope time to crater amperage. Release ON/OFF button. Arc stops then post flow.  • TIG operation with Foot Control o Set the 2T/4T Remote Control Button on the Front Panel for 2T operation. 2T Setting.
