User's
Models FP112/FP113/FP212/FP213
Manual Sanitary Pressure Sensor with Terminal Box
Models FP211/FP211A
Sanitary Pressure Sensor
Please read through this User's Manual before use for correct handling.
Please keep this User's Manual for future reference.
For safety:
The following symbol is used on the product and in this manual to ensure safe use:
indicates caution. This symbol is displayed on the product when it is necessary to refer to the User's
CAUTION
Manual for information on personnel and instrument safety. This symbol is displayed in the User's Manual
to indicate precautions for avoiding danger to the operator, such as an electric shock.
The following symbol is used only in this manual:
draws attention to essential information for understanding the operations and/or functions of the product.
NOTE
• Product Disposal
The instrument should be disposed of in accordance with local and national legislation/regulations.
• Authorized Representative in EEA
In relation to the CE Marking, the authorized representative for this product in the EEA (European Economic Area) is:
Yokogawa Europe B.V.
Euroweg 2, 3825 HD Amersfoort, The Netherlands
All Rights Reserved, Copyright © 2002, Yokogawa Electric Corporation
1. PRODUCT INSPECTION
The pressure sensors are shipped only after stringent inspection at the factory. Upon delivery, check the
sensor according to the instructions given below.
(1) Visually check the sensor to ensure that it is free from damage.
(2) The model and suffix codes and the pressure range are indicated on the data plate attached to the
sensor. Cross-check this information with that in Table 2, 3 "Model and Suffix Codes" to ensure that the
sensor is as specified in the order.
Note: If the specifications of the ordered sensor are not standard, refer to the label tag attached to the sensor.
2. HANDLING PRECAUTIONS
2.1 Storage
(1) Store the sensor in a location that meets the following requirements.
• No exposure to rain or water
• No major mechanical vibration or shocks
• Humidity and temperature within the following ranges—preferably as close as possible to the
normal condition (25°C, 65% RH)
Temperature: −20 to 80°C; humidity: 5 to 95% RH (non-condensing)
• No corrosive gases
(2) Whenever possible, store the sensor in the same packaging that it was shipped in by the manufacturer.
(3) If the sensor has been put into use and the pressure-sensing chamber contains fluids, clean the
chamber thoroughly before storing the sensor.
Even when cleaning the sensor, exercise care to avoid damaging the seal diaphragms.
2.2 Installation Location
CAUTION
Never use the sensor in an environment containing any explosive gas. It is not designed to be explosion-
proof.
Although the pressure sensors are designed for use in severe environment, the following precautions
should be observed to ensure that the sensors are used safely and that they achieve the required accuracy
for a prolonged period.
(1) If it is likely that the sensor will be exposed to direct sunlight and/or other radiated heat, prepare some
kind of heat insulation for the sensor.
(2) Avoid installing the sensor in an environment containing any corrosive gas.
(3) Although the sensor is designed to be watertight, whenever possible, avoid installing it in a location
exposed to splashes of rain. Especially, prevent water from staying in the wiring inlet.
(4) Although the sensor is durable for vibration, install it in a location where mechanical vibration and/or
shocks are minimal.
2.3 Precautions to Avoid Damaging the Sensor
(1) When measuring pressure or cleaning the sensor, exercise care to avoid damaging the seal
diaphragms.
(2) The seal diaphragm may be damaged if the measured fluid within the pressure-sensing chamber
freezes. If it is likely to occur, prepare some kind of heat insulation etc. to avoid measured fluid from
freezing.
(3) The FP112/FP113 pressure sensors can withstand a pressure up to 200% of each measuring range.
(Normal clamp can withtand up to 1 MPa. When a pressure more than 1 MPa is applied at more than
500 kPa range, use a clamp that can withstand 2 MPa or more.) But take care not to apply a pressure
more than the maximum allowable pressure because piping condition and characteristics of pressure
source may cause an instantaneous burst of pressure.
2.4 Insulation Resistance and Withstanding Voltage Test Procedures
CAUTION
Carry out these tests only when absolutely necessary. Mistake in testing may result in electric shock to
the operator or damaging the sensor.
(1) Short-circuit the terminals except the ground terminal. For each test, apply the following voltages
across the short-circuited terminals and the ground terminal.
• Insulation Resistance Test: 500 V DC, for 2 minutes max.
Make sure the insulation resistance is 20 MΩ or more.
• Withstanding Voltage Test: 500 V AC, for 1 minute max.
Make sure the leak current is 1 mA or less.
(2) After the tests, connect a 100 kΩ resistor across the short-circuited terminals and the ground terminal
in order to discharge any internal charge.
2.5 Receiver Input Impedance
Use a receiver with input impedance of 10 kΩ or more for receiving the output signal (1 to 5 V DC) of the
FP112/FP113.
YOKOGAWA ELECTRIC CORPORATION
Headquarters
9-32, Nakacho, 2-chome, Musashino-shi, Tokyo, 180-8750 JAPAN
Phone : 81-422-52-5555
IM 01C10E01-01E
1st Edition: July 2002 (MC)
8th Edition: July 2021 (YK)
3. PRODUCT OVERVIEW
The FP112/FP113/FP212/FP213/FP211/FP211A pressure sensors can be used to measure gauge or
absolute pressure and output an electrical signal corresponding to the measured pressure. The sensors can
measure gas and liquid pressures directly with high accuracy and performance (e.g. temperature effects),
along with long-term stability.
3.1 Specifications
Table 1 Measuring Range
Code
U (*1, *2)
J (*1)
N (*1)
M (*1)
T (*1, *2)
S (*1, *2)
*1: Not available for absolute pressure range.
*2: Can not specify /HT.
*3: The maximum allowable pressure for B or C range is 2 MPa. But normal clamp can withstand up to 1 MPa. When a
pressure more than 1 MPa is applied, use a clamp that can withstand 2 MPa or more.
Measurement accuracy
(*1, *5)
Temperature effect (zero
point) [% of span/°C] (*4)
Compensation temperature
range
Operating temperature
range
Supply voltage effect
(zero point)
Attitude error
Output signal
Measured fluid
Vacuum pressure
Supply voltage
Load resistance
Process connection
Material
Weight
Power consumption
(FP112/FP113)
Output resistance
(FP112/FP113)
Insulation resistance
Withstanding voltage
EMC standards (*8)
EU RoHS Directive
Vibration resistance
Mechanical shock
resistance
Time constant
Enclosure classification
*1: This sensor is adjusted under the following conditions before shipment at the factory.
- Ambient temperature: 25°C±5°C
- Power supply voltage: 24 V DC±1%
- Mounting position: Horizontal (position in Figure 8)
*2: The maximum allowable pressure for B or C range is 2 MPa. But normal clamp can withstand up to 1 MPa. When a
pressure more than 1 MPa is applied, use a clamp that can withstand 2 MPa or more.
*3: Although the case is watertight, waterproof sealing for the wiring inlet is to be carried out by the user.
*4: Temperature effects (zero point) for 0 to 50°C are as follows.
±0.015% of span/°C (A, B, C range)
±0.03% of span/°C (L, J, N, M range)
±0.06% of span/°C (K range)
±0.075% of span/°C (T, S range)
*5: <Reference> Formula for overall accuracy is shown below:
Overall accuracy is the amount of all errors such as accuracy, error caused by temperature change (temperature
effect) and the like. The expression for overall accuracy is as follows.
Overall accuracy=
A=Sensor temperature when measuring pressure − Temperature mentioned in the certificate
Temperature effect (span) [% of span/°C]=±0.02 (reference value)
*6: For the gauge pressure type, reference atmospheric pressure is let in through wiring cable.
*7: <Measures against condensation>
Keep the sensor more than 30 cm apart from cold water tank by tank spud to make the temperature difference
between the sensor and ambient temperature within 5°C. Or use /HT type with radiation fin.
*8: Immunity influence during the test: Output shift is specified within ±5% of Max. range.
Maximum Allowable
Typical Range Code
Pressure
−10 to 10 kPa 200 kPa R (*1, *2)
−100 to 0 kPa 400 kPa K
−100 to 100 kPa 800 kPa L
−100 to 300 kPa 2 MPa A
0 to 10 kPa 100 kPa B
0 to 20 kPa 150 kPa C
(including linearity, hysteresis and repeatability after ZERO adjustment with a clamp at the
factory.) [% of span]
±0.25 (other than S, T or U range), ±0.5 ( S, T, U range)
±0.02 (A, B, C range), ±0.05 (L, J range), ±0.03 (N, M range), ±0.08 (K, R range),
±0.1 (T, S, U range)
−10 to 75°C (*4) (other than U range), 0 to 50°C (U range)
main unit: – 10 to 80C° (other than U range)
–10 to 60C° (U range)
(Note that the main unit must not be wet with moisuture beads.)
wetting part: –10 to 100C° (max. 140C° within 30 min. at cleaning except for U range)
wetting part of /HT: − 10 to 180C° (Note that fluids which corrode stainless such as steam at
150C° or more must not be applied.
±0.005% of span/V
Approx. 100 Pa/90°, approx. 400 Pa/90° (/HT) (Standard position is horizontal.)
FP112/FP113: 1 to 5 V DC, four-wire, FP212/FP213/FP211/FP211A: 4 to 20 mADC, two-wire
Liquid or gas
2.7 kPa abs or more (gauge pressure): 130 Pa abs or more (absolute pressure); 13 Pa abs
or more for /HT
Note that negative pressure must not be applied when the range is R, S or T.
FP112/FP113: 12 to 30 V DC, FP212/FP213/FP211/FP211A: 12 to 28 V DC (recommended
voltage: 24V DC ±10%) see Graph above.
FP112/FP113: 10 kΩ or more, FP212/FP213/FP211/FP211A: 0 to 600 Ω (at 24 V DC power
supply) See Graph above.
ISO51 (IDF2S) or ISO38 (IDF1.5S) clamp mounting
Diaphragm: SUS316L, head: SUS316, case/cover (FP112/FP113/FP212/FP213): aluminum
alloy, case (FP211/FP211A): SUS304, fill fluid: silicone oil, O-ring (waterproof case): NBR
Mounting size
ISO51 (IDF2S) clamp: approx. 430 g or approx. 560 g (/HT)
ISO38 (IDF1.5S) clamp: approx. 370 g or approx. 530 g (/HT)
20 mA or less (at 24 V DC power supply voltage)
Up to 2 Ω
20 MΩ or more/500V DC
500 V AC for 1 minute, 1 mA or less
FP112/FP113: EN61326-1 Class A, Table 1, EN61326-2-3
FP212/FP213/FP211/FP211A: EN61326-1 Class A, Table 2, EN61326-2-3
Applicable standard: EN IEC 63000
20 m/s 2 (in 3 directions for 2 hours at 150 Hz or less)
300 m/s 2 (in 3 directions for 3 times), 200 m/s
3 ms or less, 10 ms or less (/HT)
JIS C 0920 IP67 watertight type (*3)
±√(Accuracy) 2 +(Temperature effect (zero point)×A)
Jan. '20
Printed in Japan
Maximum Allowable
Typical Range
Pressure
0 to 30 kPa 150 kPa
0 to 50 kPa (abs) 200 kPa
0 to 100 kPa (abs) 400 kPa
0 to 200 kPa (abs) 800 kPa
0 to 500 kPa (abs) 2 MPa (*3)
0 to 1MPa (abs) 2 MPa (*3)
2 (/HT)
2 +(Temperature effect (span)×A) 2
