Instructions - Parts
EFR
Electric Fixed-Ratio Proportioner
For use with two-component sealant and adhesive materials. For professional use only.
Not approved for use in explosive atmospheres or hazardous locations.
2000 psi (13.8 MPa, 138 bar) Maximum Fluid Inlet Pressure
3500 psi (24.1 MPa, 241 bar) Maximum Fluid Outlet Pressure
See page 4 for model information.
Important Safety Instructions
Read all warnings and instructions in
this manual and in related manuals
before using the equipment. Save these
instructions.
3A6165U
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EFR Series and is the answer not in the manual?

Questions and answers

Related Manuals for Graco EFR Series

Summary of Contents for Graco EFR Series

  • Page 1 Instructions - Parts 3A6165U Electric Fixed-Ratio Proportioner For use with two-component sealant and adhesive materials. For professional use only. Not approved for use in explosive atmospheres or hazardous locations. 2000 psi (13.8 MPa, 138 bar) Maximum Fluid Inlet Pressure 3500 psi (24.1 MPa, 241 bar) Maximum Fluid Outlet Pressure See page 4 for model information.

  • Page 2: Table Of Contents

    Check Oil Level ......29 Graco Standard Warranty ....80 Change the Oil .

  • Page 3: Related Manuals

    Related Manuals Related Manuals Manual Description Z-Series Chemical Pumps Instruc- 3A0019 tions-Parts APD20 Advanced Precision Driver 3A6482 Instructions 312185 MD2 Valve Instructions-Parts Communications Gateway Module Instal- 3A6338 lation Kit Instructions-Parts Z-Series Chemical Pumps High Wear 3A6394 Instructions-Parts ADM Token In-System Programming 3A6321 Instructions Voltex Dynamic Mix Valve Instruc-...

  • Page 4: Models

    Models Models Use the following matrix to determine the 8-digit system part number. NOTE: To order replacement parts, see the Parts section on page 42. The digits in the matrix do not correspond to the Ref. Nos. in the Parts drawings and lists. Digit 4 Digit 5 Digit 6...

  • Page 5: Warnings

    Warnings Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclama- tion point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When these symbols appear in the body of this manual or on warning labels, refer back to these Warnings. Product-spe- cific hazard symbols and warnings not covered in this section may appear throughout the body of this manual where applicable.
  • Page 6 Warnings WARNING SKIN INJECTION HAZARD High-pressure fluid from dispensing device, hose leaks, or ruptured components will pierce skin. This may look like just a cut, but it is a serious injury that can result in amputation. Get immediate surgical treatment. •...
  • Page 7 Warnings WARNING MOVING PARTS HAZARD Moving parts can pinch, cut or amputate fingers and other body parts. • Keep clear of moving parts. • Do not operate equipment with protective guards or covers removed. • Equipment can start without warning. Before checking, moving, or servicing equipment, follow the Pressure Relief Procedure and disconnect all power sources.

  • Page 8: Keep Components A (Red) And B (Blue) Separate

    Warnings Keep Components A (Red) and A (Red) and B (Blue) B (Blue) Separate Components NOTE: Material suppliers can vary in how they refer to plural component materials. For all machines: Cross-contamination can result in cured material in fluid lines which could cause serious injury or •...

  • Page 9: Component Identification

    Component Identification Component Identification . 1: Component Identification Key: A Pump Pressure Relief Drain Tubes B Pump A-Side Outlet Drain/Relief Valve* B-Side Outlet Drain/Relief Valve* Power Disconnect Switch Advanced Display Module (ADM) Pump Yoke Shroud Electric Driver Required components supplied with the system. Incoming Power Connection EFR sytems configured without pumps are provided Pump Inlets...

  • Page 10: Typical Installation

    Component Identification Typical Installation Power Cord with User Supplied Dedicated Inlet Regulators 6 Circuit Protection Dispense Valve* EFR Proportioner A Supply System* B Supply System* . 2: Typical Installation with Supply Systems Required accessories not supplied with the propor- tioner. ✖...
  • Page 11 Component Identification Power Cord with User Supplied Dedicated Inlet Regulators 6 Circuit Protection Dispense Valve* EFR Proportioner B Day Tank* A Day Tank* . 3: Typical Installation with Day Tanks Required accessories not supplied with the proportioner. ✖ Optional accessories not supplied with the proportioner. 3A6165U...

  • Page 12: Advanced Display Module (Adm)

    Component Identification Advanced Display Module (ADM) User Interface TI12362a1 . 4: ADM Component Identification - Front Buttons Callout Button Function Callout Button Function Soft Defined by application using ADM. System Enables/disables system. When Keys enable/ system is disabled, temperature disable control and dispense operation are Cancel Cancel a selection or number entry...
  • Page 13 Component Identification ti12363a1 . 5: ADM Component Identification - Rear Key: ADM Module Status LEDs (AN) Conditions AJ Flat Panel Mount AK Model Number AL USB Module Interface Module Status LED AM CAN Cable Connections Signal Description AN Module Status LEDs AP Accessory Cable Connections Green on System is powered up.

  • Page 14: Installation

    Installation Installation Connect Power 1. Cut power cord wires to the following lengths: • Ground wire - 6.5 inches (16.5 cm) All electrical wiring must be done by a qualified elec- • Power wires - 3.0 inches (7.6 cm) trician and comply with all local codes and regula- •...
  • Page 15 Installation NOTE: Inside the junction box, power wires are 4. Attach the ground wire to the ground terminal inside pre-installed to terminals 2T1 and 4T2 on the disconnect the junction box as shown in F . 9. block. Refer to F .

  • Page 16: Install Vented Oil Cap Before Using Equipment

    Installation Install Vented Oil Cap Before Using Equipment The driver gear-box is shipped from the factory pre-filled with oil. The temporary unvented cap (PX) prevents oil leaks during shipment. This temporary cap must be replaced with the vented oil cap (PY), supplied with the equipment, before use.

  • Page 17: Setup

    Setup Setup After placing the EFR in the desired area of operation: 4. Connect the supply systems. a. Install feed pumps for component A (Red) and NOTE: Make sure the EFR is placed on a level surface. See Dimensions on page 77 for space requirements. B (Blue) supply drums.

  • Page 18: Flushing

    Setup Driver and Yoke Position 5. Attach the fluid outlet hoses to the pump outlets (K). Adapter fittings may be required, see Addi- tional Accessories on page 47. The driver and yoke position must be initially set for the volume mix ratio of the system. A further precision alignment can made after the completed system is run through a production dispense cycle, and pump pressures have been recorded during the dispense...
  • Page 19 Setup Precision Alignment Formula (Right Right press. psi pump size cc Ratio = (Right Right + Left Left press. psi pump size cc press. psi pump size cc Indicator 137.77 = Pump Center to Center Distance Lines = 137.77 x (Ratio -1/2 Left 5.
  • Page 20 Setup 4. Place a wrench on the adapter rod (DA), then use the supplied tool (DT) to loosen the serrated yoke nut (DB) above the yoke (DC). 5. Loosen the three nuts (D2) below the driver tie rods. Driver Thrust Rod 6.

  • Page 21: Fluid Pathway

    Setup Fluid Pathway 3A6165U...

  • Page 22: Can Cable Connections (With Day Tanks)

    Setup CAN Cable Connections (With Day Tanks) 3A6165U...

  • Page 23: Signal Connections

    Setup Signal Connections 3A6165U...
  • Page 24 Setup 3A6165U...
  • Page 25 Setup 3A6165U...

  • Page 26: Operation

    Operation Operation Startup Keep Components A and B Separate Cross-contamination can result in cured material in 1. Use the supply systems to load the fluid. fluid lines which could damage equipment or cause serious injury if injected or splashed on skin or in NOTE: The EFR is tested with oil at the factory.

  • Page 27: Shutdown

    Operation Shutdown Pressure Relief Procedure Follow the Pressure Relief Procedure whenever you see this symbol. 1. Park the pumps. a. From the Home screen, press the icon. Material will dispense. The pump will park auto- matically. Once the pump is parked, the pump This equipment stays pressurized until pressure is will stop moving.

  • Page 28: Adjust Material Inlet Pressure

    Operation Adjust Material Inlet Pressure 9. Once material is flowing from the drain hose, slowly decrease pressure on the inlet regulator until flow stops. 10. Gradually increase pressure to the inlet regulator NOTICE until material begins to flow again. Care must be taken when applying pressure to sys- 11.

  • Page 29: Maintenance

    If oil is low, open valve manual fill cap (FB) and add Graco Part No. 16W645 ISO 220 silicone-free synthetic EP gear oil. See F . 12. Clean dispense valve check...

  • Page 30: Change The Oil

    3. Reinstall the oil drain plug (FA). Torque to 18-23 ft-lb (25-30 N•m). 4. Open the fill cap (FB) and add Graco Part 16W645 ISO 220 silicone-free synthetic EP gear oil. Check the oil level in the sight glass (FC). (See F .

  • Page 31: Calibrate The Electric Driver

    Maintenance Calibrate the Electric Driver 6. Turn the power disconnect switch (C) to the ON position. 7. Navigate to Maintenance Screen 1 on the ADM (see page 65). Press to enter Calibration mode. 1. Park the pumps: a. From the Home screen, press the icon.

  • Page 32: Adm - Battery Replacement And Screen Cleaning

    Maintenance ADM - Battery Replacement and Grease Cup Maintenance Screen Cleaning Frequency of greasing intervals is dependent on material being pumped. As a basic schedule, lubricate pump with grease after 250 gallons of product ( five drums of 55 gallon pails) has been passed through the pump.

  • Page 33: Troubleshooting

    Troubleshooting Troubleshooting NOTE: For Online help, visit http://help.graco.com for causes and solutions to each error code. 1. Follow Pressure Relief Procedure, page 27. 2. Check all possible problems and causes before disassembling. 3. Turn the power disconnect switch OFF. Try the recommended solutions in the order given for each problem, to avoid unnecessary repairs. Also, determine that all circuit breakers, switches, and controls are properly set and wiring is correct before assuming there is a problem.
  • Page 34 Troubleshooting Problem Cause Solution The wrong pressure is displayed on The dial position on the pressure Set the inlet pressure fluid cube to the ADM/CGM fluid cube is not set correctly the correct dial position: 25B128: Dial position 0 25U084: Dial position 1 Incorrect pressure transducer is Verify that the correct pressure being used...

  • Page 35: Efr Error Codes

    Troubleshooting EFR Error Codes Error Code Code Description Cause Solution Inlet pressure too high, Reduce inlet supply pressure. causing retract stroke to require too much torque Pump sizes too large for motor Reduce combined pump size. A4NX High current motor to drive out the operating Reduce outlet flow rate or outlet operating pressure...
  • Page 36 Troubleshooting Error Code Code Description Cause Solution Out of material Verify B material supply Inspect and clean B side check valve. DDDB Pump Cavitation B Check valve not working Check for leaking seals or damage to the properly ball Visually inspect the machine and hoses for Leak Detected Outlet Pressure leaking from A side DHDA...
  • Page 37 Troubleshooting Error Code Code Description Cause Solution If the tanks appear to have plenty of material, check to make sure the level Blue High Material Defective fill valve sensor is connected to the proper port and L3TB Level that the cord is not damaged. Replace fill valve is leaking Bad level sensor Replace level sensor...
  • Page 38 Troubleshooting Error Code Code Description Cause Solution Check feed system for low or empty material. Pressure A is below Low Pressure Check feed system filters for blockage if P2FA user-defined dispense Deviation Inlet A installed. pressure limit Check for blockage in feed system. Check pressure settings on setup screen.
  • Page 39 Troubleshooting Error Code Code Description Cause Solution Inspect for hardened material or obstructions to flow Attempt to purge material at a reduced Pressure A exceeds flow rate High Pressure P3DC user-defined Deviation Outlet A Reduce operating pressure by reducing dispense pressure limit. flow rate and/or restriction in the hose and valve Check pressure settings on setup screen.
  • Page 40 Troubleshooting Error Code Code Description Cause Solution Pressure A exceeds Check settings on feed system, decrease High Pressure Alarm P4FA user-defined dispense pressure if necessary. Inlet A pressure limit. Check pressure settings on setup screen. Pressure B exceeds Check settings on feed system, decrease High Pressure Alarm P4FB user-defined dispense...
  • Page 41 Troubleshooting Error Code Code Description Cause Solution Cycle Power. Increase Ramp up time. Cycle Over Torque power to unit. Voltex Dynamic Mix WVCX Clean mixer. Cycle power to unit. Valve Motor Fault Make sure that motor has power. Check No power to motor power supply if need cycle power.

  • Page 42: Parts

    Parts Parts EFR Common System Parts 3A6165U...

  • Page 43: Fluid Section

    Parts Fluid Section A Side Pump B Side Pump 3A6165U...

  • Page 44: Driver And Yoke Assembly

    Parts Driver and Yoke Assembly Apply blue thread-locker. Torque to 0.8-1.13 N •m (7-10 in-lbs). Torque to 20-27 N •m (15-20 ft-lbs). Torque to 23-32 N •m (17-23 ft-lbs). Torque to 67-81 N •m (50-60 ft-lbs). Torque adapters to 122-135 N •m (90-100 ft-lbs).

  • Page 45: Part Description

    Parts Parts Common to All Systems Ref. Part Description Qty. U90126 NUT, hex, 3/8-16 Ref. Part Description Qty. 238▲ 17Y723 LABEL, safety, warning, See Table LOWER, chemical, SST (B-side) horizontal See Table LOWER, chemical, SST (A-side) 239▲ 15H108 LABEL, safety, warning, pinch 15M669 SENSOR, pressure, fluid outlet 16H888...

  • Page 46: Electrical Assembly

    Parts Electrical Assembly 240V 480 V 240V 480 V Systems Systems Systems Systems Ref. Description Part Qty. Part Qty. Ref. Description Part Qty. Part Qty. CORD GRIP, strain 121171 121171 COVER, pump, lower 25E103 25E103 relief, 3/4-14 NPT male, 221† SCREW 114182 114182 cable range 0.35-0.63...

  • Page 47: Accessories

    Accessories Accessories Additional Accessories Miscellaneous NOTE: See the MD2 Valve Instructions-Parts manual for more information on mixers and accessories. Part Description Voltex Dynamic Mix Valve 121728 ADM Extension Cable, 4 meter 255244 Foot Switch with Guard and 4 meter Cable 17Z431 Foot Switch, 4 meter adapter cable, 8-pin to Part Description...

  • Page 48: Efr Supply System Accessories

    Accessories EFR Supply System Accessories Ram Supply Systems for EFR (A and B Drum Supply Pumps for EFR (A and B Side) Side) NOTE: For supplying material to EFR directly out of a 55 gallon drum. NOTE: Do not use with Day Tanks or Recirculation. Part Description Part...
  • Page 49 Accessories Day Tank Accessories (A and B Side) EFR Outlet Material Hose (A and B Side) Part Description Part Description 257770 Refill Kit For Customer Supplied Feed System 17K152 15 FT - 2mm PTFE Core SST Braided Hose - 4800 PSI (33 MPa, 331 bar) WP 257778 Nitrogen Kit For 1 Tank 25E525 10 FT - 1/8 in PTFE Core SST Braided Hose -...

  • Page 50: Other Options

    Accessories Applicators 255244 FOOT SWITCH ASSEMBLY WITH 4M CORD NOTE: Recirculation can only be with the Voltex 121728 CAN Cable for remote placement of ADM Dynamic Mix Valve. (4.0M) 123660 6m Extension Cord for Electric MD2 Valve Handle Part Description 255179 1:1 MD2 Valve with Soft Seats (Do not use with recirculation) 255180 1:1 MD2 Valve Hard Seats (Do not use with recir-...
  • Page 51 Accessories Voltex Dynamic Mix Valve Power Cord Voltex Dynamic Mix Valve Mixers NOTE: Used to power Voltex Dynamic Mix Valve Con- Part Description trol Box. 255024 8mm x 12 Element,10 Pack Part Description 255025 8mm x 12 Element,50 Pack 255026 10mm x 12 Element,10 Pack 121055 CORD SET,US, MX, PR, CA, TW,115V,10A 255027 10mm x 12 Element,50 Pack 121054 CORD SET,US,250V,10A,10FT...

  • Page 52: Fitting Kits

    Accessories Fitting Kits Part Description Part Description EKH013 KIT, EFR, fitting conn, H13 EKA001 KIT, EFR, fitting conn, A1 EKH014 KIT, EFR, fitting conn, H14 EKA002 KIT, EFR, fitting conn, A2 EKJ001 KIT, EFR, fitting conn, J1 EKA003 KIT, EFR, fitting conn, A3 EKJ002 KIT, EFR, fitting conn, J2 EKA004...
  • Page 53 Accessories Part Description Part Description EKL005 EKN012 KIT, EFR, fitting conn, L5 KIT, EFR, fitting conn, N12 EKL006 EKN013 KIT, EFR, fitting conn, L6 KIT, EFR, fitting conn, N13 EKL007 EKN014 KIT, EFR, fitting conn, L7 KIT, EFR, fitting conn, N14 EKL008 KIT, EFR, fitting conn, L8 EKL009...

  • Page 54: Advanced Display Module (Adm) Operation

    Advanced Display Module (ADM) Operation Advanced Display Module (ADM) Operation When main power is turned on by turning the power disconnect switch (C) to the ON position, the splash screen will be displayed until communication and initial- ization is complete. To begin using the ADM, the machine must be on and enabled.

  • Page 55: Adm Screen Overview

    ADM Screen Overview ADM Screen Overview Home Screen System Active Sequence Error and Events State Selected Display Status of Valve To select a sequence, use the navigation keys to high- light the active sequence bar. Then press the Enter but- to open a drop down menu where the desired sequence can be selected.
  • Page 56 ADM Screen Overview Along the right side of the home screen, there are icons De-Pressurize: When pressed, the de-pressurize icon that will allow the user to prime, park, de-pressurize, and purge the unit. will open the dispense valve, which will relieve pressure in the pump lines.

  • Page 57: Voltex Dynamic Mix Valve Run Screen

    ADM Screen Overview Voltex Dynamic Mix Valve Run Recirculation: When pressed, the recirculation icon Screen will recirculate material through the pumps. To stop recirculating material from the pumps, press the recirculation icon again. Tank Stand Status Information . 14 NOTE: This screen will only be displayed if the Voltex NOTE: The tank stand status information and icons will Dynamic Mix Valve is connected to the EFR Network.

  • Page 58: Index Menu

    ADM Screen Overview 6. Manual Motor: This button allows the motor to be turned on by the ADM at the RPM setpoint. 7. Motor Actual RPM: Shows what speed the motor is at during the ramp period. It is not direct feedback from the motor.
  • Page 59 ADM Screen Overview NOTE: If the user selects seconds for the shot size, cal- If the user enters the home screen while a sequence ibration will no longer be an option for the selected shot size. NOTE: If the user selects operator mode for the shot size, the EFR will only dispense at the desired flow rate as long as an external trigger source or foot switch is active for that particular shot of the sequence.
  • Page 60 ADM Screen Overview NOTE: If the active sequence does not contain a checked shot size, the unit will start dispensing when icon or an external trigger signal is supplied. The sequence will continue to dispense until finished. Sequence Delays Screen 2 This screen allows the user to define delay settings for a sequence.
  • Page 61 ADM Screen Overview Pressure Units: The pressure units can be set to either Alarm: This is the amount of time the EFR will wait after psi or bar. the idle period has been reached. This allows time for the robot to move into the purge location. Pressure Imbalance Alarm: When checked, the pres- sure imbalance alarm will watch the pressure for both A Repeat Until: The selected sequence will be repeated...
  • Page 62 ADM Screen Overview Recirculation Off: This is the amount of time the system will wait before starting the Recirculation On timer when the Recirculation Mode is set to Timer. Park Using Recirculation Valves: If checked, the park feature will park the pumps using the recirculation valves instead of the dispense valves.
  • Page 63 ADM Screen Overview NOTE: 100ms is the fastest acceleration and 9000ms is the slowest acceleration. The goal is to try and prevent breaking mixers with a slower acceleration. Example: 500ms = half a second to get to the RPM setpoint of 4400RPM.
  • Page 64 ADM Screen Overview • This icon can also be used to abort a refill opera- tion. Refill Setting: If a refill setting other than Disabled is selected, the user must set at least two level sensor locations as installed by checking the check box on the screen.
  • Page 65 ADM Screen Overview Advanced Screen 2 Maintenance Screen 1 This screen allows the user to view and upgrade soft- This screen keeps track of the cycles of the A and B pump, both current and lifetime, as well as the number ware installed on the system.
  • Page 66 ADM Screen Overview Shot Log This screen shows users a list of all completed shots. Each shot entry includes a date and time stamp, the sequence selected, the amount dispensed, and that start pressures of the A and B pumps. Maintenance Screen 2 This screen allows users to see the line voltage of the incoming AC power, the motor temperature, the per-...
  • Page 67 ADM Screen Overview Errors Screens Installation Kit Instructions-Parts manual for more infor- mation. This screen shows users a list of errors that have occurred in the system. Each error entry includes a description and error code along with a date and time stamp.
  • Page 68 ADM Screen Overview USB Plug-In Screen This screen will appear when a USB device is plugged into the ADM. Here the user can select dates to download data from the ADM to the USB device by pressing the left and right arrow icons on either side of the screen .

  • Page 69: Software Update

    Software Update Software Update NOTE: If burning your own software token, see the NOTICE ADM Token Programming manual. See Related Manu- A status is shown while software is updating to als on page 3. Otherwise, proceed to 17Y711 Software indicate progress. To prevent corrupting the Update Procedure.

  • Page 70: I/O Integration

    I/O Integration I/O Integration NOTE: The EFR software considers +5V as ON, which means the +5V supply o pin 4 of connector 4 can also be used as an external source to trigger digital input pins ON. Connector 3 Connector 1 Connector 5 Connector 2 Connector 4...

  • Page 71: Pin Out Of Connector 3 And Connector 4

    I/O Integration Pin Out of Connector 3 and Connector 4 Connector Input/Output Description Recirculation Valves Signal: When this digital output pin is ON, the recirculation valves will be opened. When this digital output pin is Digital Output: OFF, the recirculation valves will be closed. •...

  • Page 72: I/O Integration Diagrams

    I/O Integration I/O Integration Diagrams green, and “Active” is displayed in the upper left corner of the display. The system can also be put into the active state by turning the system enable I/O pin ON. Before any integration signals can be sent over the I/O connection(s), the integration inputs to the EFR must be Once the system is in the active state, dispense com- enabled on Integration Screen 1, and the system must...
  • Page 73 I/O Integration EFR Discrete Signal Run Sequence Automation Inputs (EFR Outputs) System Ready Alarm Active Valve Signal Automation Outputs (EFR Inputs) Trigger Signal (Foot Switch) System Enable Sequence Select Bits (optional command) EFR State Sequence Running EFR Sequence is running If the sequence is not in operator mode, a pulse on the trigger pin will result in the sequence being played.

  • Page 74: Foot Switch Connection

    I/O Integration EFR Discrete Signal Stop Sequence Automation Inputs (EFR Outputs) System Ready Alarm Active Valve Signal Automation Outputs (EFR Inputs) Trigger Signal (Foot Switch) System Enable Sequence Select Bits (optional command) EFR State Sequence Running EFR Sequence is running EFR Sequence is being stopped An OFF pulse on the system enable I/O pin will stop the sequence.

  • Page 75: Remote Sequence Selection

    I/O Integration Remote Sequence Selection Remote Sequence Selection Table Sequence Sequence Sequence Sequence The active sequence can be changed using Connector Sequence Selection Selection Selection Selection #1 (AP) on the ADM. Selection bits are pulled high by Number BIT0 BIT1 BIT2 BIT3 default and must be dropped low to select the desired...

  • Page 76: Wiring Diagrams

    Wiring Diagrams Wiring Diagrams NOTE: See the APD20 Advanced Precision Driver Instructions manual for driver internal wiring. Power Wiring Customer Ground Customer Power In Customer Ground X1-X3 Customer X6-X9 Power In H1-H3 H6-H9 3A6165U...

  • Page 77: Dimensions

    Wiring Diagrams Dimensions A Machine Mounting Holes 21.5 in. (55 cm) For 3/8 in. (10mm) Mounting Fasteners B Machine Mounting Holes 21.1 in. (54 cm) C Total Machine Height 22 in. (56 cm) D Total Machine Length 50 in. (127cm) E Total Machine Width 22.5 in.

  • Page 78: Technical Specifications

    Technical Specifications Technical Specifications Metric Maximum fluid working pressure ‡ 3500 psi 24 MPa, 241 bar Maximum fluid temperature 120°F 50°C Fluid circulation ports 1/4 NPS(m) 200-240V, 1ph, 50/60 Hz Line voltage rating 400-480V, 1ph, 50/60 Hz Stainless steel, zinc-plated carbon steel, brass, tungsten Wetted parts carbide, chrome, fluoroelastomer, PTFE, ultra-high molec- ular weight polyethylene, silicon nitride...

  • Page 79: California Proposition 65

    California Proposition 65 Pump Performance Table Performance Combined Displacement Min Shot Size Min Output Max Output Flow Max Average Outlet (A Pump + B Pump) Flow (20 cycles/min max)* Pressure‡ ** 60 cc 0.3 cc 20 cc/min 1,200 cc/min 3,500 psi (241 bar) 80 cc 0.3 cc 20 cc/min...

  • Page 80: Graco Standard Warranty

    With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
