Installation Guide for the
Venture VideoBAR All-in-One Conferencing Camera and
Venture TableMIC Tabletop Expansion Microphone
This guide contains only the information required to install this product. Refer to the Complete Manual
for Venture VideoBAR and Venture TableMIC for information on configuring and using this product.
Overview
This guide provides information about:
Venture VideoBAR All-in-One Conferencing Camera,
▪
999-50909-000 (worldwide)
Venture TableMIC tabletop expansion microphone, 999-85909-000 (worldwide)
▪
What's in this Guide
This guide covers:
Product features
▪
Unpacking
▪
Tips for a successful installation
▪
Instructions for installing the camera mount
▪
Information on connecting the system components
▪
System power-on
▪
If you are responsible for configuring the equipment after installing it, please use the Complete Manual. It
includes all the information in this guide, plus information on configuring, operating, and troubleshooting
the camera.
Features
UHD (4K) PTZ+ePTZ camera ideal for small to medium conference rooms
▪
Simultaneous HDMI, USB 3.0, and IP (H.264) video
▪
110° horizontal field of view lens with up to 5x zoom
▪
Three advanced tracking technology options frame the active speaker, the whole group, or present a
▪
gallery view
Easy configuration, system administration, and remote management via web interface
▪
Integrated audio system with option to add up to three external Venture microphones
▪
Universal Video Class (UVC) and Universal Audio Class (UAC) drivers supported in Windows®,
▪
Mac® OS, and Linux operating systems, compatible with most UC conferencing applications
▪
Presenter-friendly RF remote control
▪
Tiltable table and wall-mounting options
▪
Document Number 411-0070-31 Rev C – September 2024
Advertisement
Table of Contents
Related Manuals for LEGRAND VADDIO Venture VideoBAR
Summary of Contents for LEGRAND VADDIO Venture VideoBAR
- Page 1 Installation Guide for the Venture VideoBAR All-in-One Conferencing Camera and Venture TableMIC Tabletop Expansion Microphone This guide contains only the information required to install this product. Refer to the Complete Manual for Venture VideoBAR and Venture TableMIC for information on configuring and using this product. Overview This guide provides information about: Venture VideoBAR All-in-One Conferencing Camera,...
- Page 2 Installation Guide for Venture VideoBAR All-in-One Conferencing Camera and Venture TableMIC Tabletop Expansion Microphone Unpacking the Camera or Microphone Make sure you received all the items you expected. Venture VideoBAR Worldwide: 999-50909-000 The box should contain these items: Venture VideoBAR with tiltable table mount ▪...
-
Page 3: A Quick Look At The System
Installation Guide for Venture VideoBAR All-in-One Conferencing Camera and Venture TableMIC Tabletop Expansion Microphone A Quick Look at the System This section covers the physical features of the camera and microphone. Front of the Camera Camera and Zoom Lens – Venture VideoBAR camera zooms up to 5x. ▪... - Page 4 Installation Guide for Venture VideoBAR All-in-One Conferencing Camera and Venture TableMIC Tabletop Expansion Microphone Top of the Microphone Mute button with status light – Tactile button indicates power and mute status. ▪ Cloth-wrapped body – Houses microphone elements positioned so that people seated at the ▪...
-
Page 5: Installation And Connections
Installation Guide for Venture VideoBAR All-in-One Conferencing Camera and Venture TableMIC Tabletop Expansion Microphone Installation and connections This section covers: Selecting the location for the camera ▪ Tips for a successful audio installation ▪ Cabling notes ▪ Connection diagrams ▪ Don’t void your warranty! Caution This product is for indoor use. -
Page 6: Cabling Notes
Installation Guide for Venture VideoBAR All-in-One Conferencing Camera and Venture TableMIC Tabletop Expansion Microphone Cabling notes Caution Do not use pass-through RJ-45 connectors when making cables for this product. Poorly crimped connectors of this type can cause intermittent connections and degraded signal quality. -
Page 7: Basic Connections
Installation Guide for Venture VideoBAR All-in-One Conferencing Camera and Venture TableMIC Tabletop Expansion Microphone Basic connections This diagram shows a basic conferencing configuration. A laptop provides USB connectivity. This system provides acoustic echo cancellation. - Page 8 Installation Guide for Venture VideoBAR All-in-One Conferencing Camera and Venture TableMIC Tabletop Expansion Microphone Camera connections with external microphones Add up to three optional Venture TableMIC microphones for more flexibility in the room layout. Connect the first external microphone’s UP connector “upstream” to the camera’s EXT MIC connector. When adding a second or third microphone, connect its UP connector to the DOWN connector of the next microphone “upstream”...
- Page 9 Installation Guide for Venture VideoBAR All-in-One Conferencing Camera and Venture TableMIC Tabletop Expansion Microphone Mounting the Venture VideoBAR camera This section covers: Tabletop use ▪ Installing the wall mount cleat for the Venture VideoBAR camera ▪ Mounting the VideoBAR ▪ Other mounting options ▪...
-
Page 10: Powering Up The System
· Phone 800.572.2011 / +1.763.971.4400 · Email av.vaddio.techsupport@legrand.com Vaddio is a registered trademark of Legrand AV Inc. The Adopted Trademarks HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries.
