LUMINA H380
380W LED Hybrid moving head with CMY
1
LUMINA H380 User's Manual Ver. 1.00
Page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LUMINA H380 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Evolite LUMINA H380

Summary of Contents for Evolite LUMINA H380

  • Page 1 LUMINA H380 380W LED Hybrid moving head with CMY LUMINA H380 User’s Manual Ver. 1.00 Page...
  • Page 2 This Evolite appliance must be installed using strong hooks of the correct size for the weight carried. The equipment must be screwed to the hooks and tightened properly to prevent it from falling due to vibrations produced by the machine during operation.
  • Page 3 Contact your retailer or an authorised specialist repairer. There are no user-replaceable parts.  Introduction Congratulations on your purchase of this evolite projector. This professional projector features the latest technological advances and has been designed for professional use. Its quality and reliability are the result of careful manufacture to exacting specifications.

  • Page 4: Product Description

    Linear CMY 9+open, interchangeable, indexable and bidirectional rainbow effect Color bounce Gobos Outside￠20mm，inside ￠16mm 8+open custom interchangeable position for rotating gobo wheel 13+open fixed gobos Real indexable and gobo shaking Distinctive gobo animation effect LUMINA H380 User’s Manual Ver. 1.00 Page...
  • Page 5 Fan speed auto change according to temperature Display 2.4inch super nice LCD display Auto lock and flip Power Max power consumption:520W Powercon in , 3+5 pins DMX Power supply: Electronic auto-ranging Input voltage range: 100–240V, 50-60Hz LUMINA H380 User’s Manual Ver. 1.00 Page...
  • Page 6 14. Enter button 15. Up button 16. Right button 17. 5-pin DMX out 18. 3-pin DMX out 19. 5-pin DMX in 20. 3-pin DMX in 21. Fuse 22. USB 23. Power out 24. Power in LUMINA H380 User’s Manual Ver. 1.00 Page...
  • Page 7 Open High rendering finger color sheet 6000K 3200K 2400K CYAN Open CTB-011/468 BARK BLUE MAGENTA LUMINA H380 User’s Manual Ver. 1.00 Page...
  • Page 8 Open green Dark pink Light orange YELLOW Static gobo wheel LUMINA H380 User’s Manual Ver. 1.00 Page...
  • Page 9 When the fixture is hanged overhead, the safety rope must be fixed to the bottom of the device to the appropriate fixing point. Always carry the device by the handles, do not take the head or arm directly for transportation. LUMINA H380 User’s Manual Ver. 1.00 Page...

  • Page 10: Installation

    When the fixture is hanged, always additionally secure the device with the safety chain, fasten the safety rope at a suitable position so that the maximum fall of the projector will be 20 cm. LUMINA H380 User’s Manual Ver. 1.00 Page...

  • Page 11: Control Menu

    Total Read) Power On Cycle (Read And Partial Reset) Temperature Near Source Temp,Driver PCB Temp,Led PCB Temp,… Fans Speed Near Source Fan,Base Fan … Channel Value Pan…… Error Message Pan,Tilt…… Fixture Model xxxxxxxxxxxx LUMINA H380 User’s Manual Ver. 1.00 Page...
  • Page 12 Chase Test Edit Chase② Step 01 =xxx Chase 8 Step 64 =xxx Edit Scene 001 Pan,Tilt,…… =xxx ~ Edit Scene 250 --Fade Time-- =xxx Edit Scenes② --Secne Time-- =xxx DMX Input Scenes Record ScXX=>ScXX LUMINA H380 User’s Manual Ver. 1.00 Page...

  • Page 13: Dmx Protocol

    Standard Pan Coarse Pan fine Pan Fine Tilt Tilt Coarse Tilt fine Tilt Fine XY Speed Fast to Slow Close Strobe from slow to fast Shutter Open Pulse in from slow to fast LUMINA H380 User’s Manual Ver. 1.00 Page...
  • Page 14 Forward Spin From fast to slow Stop Stop Reverse Spin From slow to fast Indexed Open Open + LIGHT GREEN Color Wheel 3 LIGHT GREEN LIGHT GREEN + PINK PINK PINK + LIGHT ORANGE LUMINA H380 User’s Manual Ver. 1.00 Page...
  • Page 15 From fast to slow Gobo Rot Stop Stop Reverse Spin From slow to fast Gobo Rot Fine Lineary from 0° to 360° (Indexed) Indexed Open Fixed Gobo GOBO 1 GOBO 2 GOBO 3 LUMINA H380 User’s Manual Ver. 1.00 Page...
  • Page 16 Prism 2 Prism insert Indexed Lineary from 0° to 360° Forward Spin From fast to slow Prism 2 Rotation Stop Stop Reverse Spin From slow to fast Continuous Frost Lineary from 0% to 100% LUMINA H380 User’s Manual Ver. 1.00 Page...
  • Page 17 Reserved Reserved Reserved ROTATING GOBO WHEEL CONTINUOUS MOVEMENT (index) ROTATING GOBO WHEEL STEP MOVEMENT (index) FIXED GOBO WHEEL CONTINUOUS MOVEMENT (index) FIXED GOBO WHEEL STEP MOVEMENT (index) Reserved Reserved DISPLAY ON DISPLAY 10S LUMINA H380 User’s Manual Ver. 1.00 Page...
  • Page 18 RESET COLOR 2 RESET COLOR 3 RESET ROTATING GOBO RESET GOBO ROTATION RESET FIXED GOBO RESET ZOOM RESET FOCUS RESET ANIMATION RESET 6F PRISM RESET 8F PRISM RESET FROST Reserved FACTORY DEFAULT OF CONTROL FUNCTIONS LUMINA H380 User’s Manual Ver. 1.00 Page...

  • Page 19: Unique Features

    The outside of the camera should be cleaned regularly. The lenses must be cleaned to ensure optimum brightness. If the luminaire is installed in a dusty or smoky environment, regular cleaning is very important. Unplug the device before carrying out any work! LUMINA H380 User’s Manual Ver. 1.00 Page...

  • Page 20: Technical Specifications

    Lamp Advanced 380W white led DMX channels 30 channels Beam angle 4° to 48 ° Luminous flux 93000 lux@5m Fuse T8A , 250 V Device dimensions 415*340*632mm Net Weight 21KG Gross Weight 22.5KG LUMINA H380 User’s Manual Ver. 1.00 Page...
  • Page 21 Avant d'utiliser votre appareil, nous vous recommandons de lire toutes les instructions contenues dans ce manuel. ATTENTION ! Cet appareil produit une lumière intense et puissante. Risque pour les yeux. Ne pas regarder directement dans le faisceau. LUMINA H380 User’s Manual Ver. 1.00 Page...
  • Page 22 Cet appareil Evolite doit être installé à l'aide de crochets solides et de taille adaptée au poids transporté. L'équipement doit être vissé aux crochets et serré correctement afin d'éviter qu'il ne tombe en raison des vibrations produites par la machine pendant son fonctionnement.

  • Page 23: Description Du Produit

    Effet arc-en-ciel 9+ ouvert, interchangeable, indexable et bidirectionnel Rebond de couleur Gobos Extérieur￠20mm，intérieur ￠16mm 8+positions personnalisées interchangeables pour la roue de gobos rotative 13+ouverture de gobos fixes Indexation réelle et secousses des gobos LUMINA H380 User’s Manual Ver. 1.00 Page...
  • Page 24 Ecran LCD 2,4 pouces super agréable Verrouillage et basculement automatique Puissance Consommation électrique maximale : 520 W Entrée Powercon, DMX 3+5 broches Alimentation électrique : Auto-régulation électronique Plage de tension d'entrée : 100-240V, 50-60Hz LUMINA H380 User’s Manual Ver. 1.00 Page...
  • Page 25 17. Sortie DMX à 5 broches 18. Sortie DMX à 3 broches 19. Entrée DMX à 5 broches 20. Entrée DMX 3 broches 21. Fusible 22. USB 23. Coupure d'électricité 24. Le pouvoir en LUMINA H380 User’s Manual Ver. 1.00 Page...
  • Page 26 Ouvrir Feuille couleur à haut rendu 6000K 3200K 2400K CYAN Ouvrir LUMINA H380 User’s Manual Ver. 1.00 Page...
  • Page 27 CTB-011/468 BLEU rouge MAGENTA Ouvrir vert Rose foncé Orange clair JAUNE Roue de gobos statiques LUMINA H380 User’s Manual Ver. 1.00 Page...
  • Page 28 Ne placez pas ou n'installez pas l'appareil sur une surface sujette à des vibrations ou à des chocs. L'appareil est censé fonctionner dans une plage de températures comprises entre -15° Ta=45℃ C et +45° C. Ne pas utiliser l'appareil lorsque les températures dépassent cette plage. LUMINA H380 User’s Manual Ver. 1.00 Page...
  • Page 29 à un endroit approprié de manière à ce que la chute maximale du projecteur soit de 20 cm.  Menu de contrôle LUMINA H380 User’s Manual Ver. 1.00 Page...
  • Page 30 ( Lire Total seulement ) Cycle de mise sous tension (Lecture et Partiel réinitialisation) Température de la source proche, température du circuit imprimé Température du conducteur, température du circuit imprimé des diodes électroluminescentes,... LUMINA H380 User’s Manual Ver. 1.00 Page...

  • Page 31: Protocole Dmx

    Chase 8 Étape 64 =xxx Modifier la scène Pan, Tilt, ..=xxx Modifier ~ Modifier la scène --Temps de fondu-- =xxx scènes② --Seconde heure... =xxx Entrée DMX Enregistrement ScXX=>ScXX des scènes  Protocole DMX LUMINA H380 User’s Manual Ver. 1.00 Page...
  • Page 32 Tilt Tilt Coarse Tilt fine Tilt Fine XY Speed Fast to Slow Close Strobe from slow to fast Open Shutter Pulse in from slow to fast Open Pulse out from slow to fast LUMINA H380 User’s Manual Ver. 1.00 Page...
  • Page 33 Stop Reverse Spin From slow to fast Indexed Open Open + LIGHT GREEN LIGHT GREEN Color Wheel 3 LIGHT GREEN + PINK PINK PINK + LIGHT ORANGE LIGHT ORANGE LIGHT ORANGE + YELLOW LUMINA H380 User’s Manual Ver. 1.00 Page...
  • Page 34 Gobo Rot Stop Stop Reverse Spin From slow to fast Gobo Rot Fine Lineary from 0° to 360° (Indexed) Indexed Open GOBO 1 Fixed Gobo GOBO 2 GOBO 3 GOBO 4 GOBO 5 LUMINA H380 User’s Manual Ver. 1.00 Page...
  • Page 35 From fast to slow Prism 2 Rotation Stop Stop Reverse Spin From slow to fast Continuous Frost Lineary from 0% to 100% Zoom Lineary from in to out Zoom Fine Lineary from in to out LUMINA H380 User’s Manual Ver. 1.00 Page...
  • Page 36 ROTATING GOBO WHEEL CONTINUOUS MOVEMENT (index) ROTATING GOBO WHEEL STEP MOVEMENT (index) FIXED GOBO WHEEL CONTINUOUS MOVEMENT (index) FIXED GOBO WHEEL STEP MOVEMENT (index) Reserved Reserved DISPLAY ON DISPLAY 10S DISPLAY 20S DISPLAY 30S LUMINA H380 User’s Manual Ver. 1.00 Page...

  • Page 37: Caractéristiques Uniques

    RESET FOCUS RESET ANIMATION RESET 6F PRISM RESET 8F PRISM RESET FROST Reserved FACTORY DEFAULT OF CONTROL FUNCTIONS  Caractéristiques uniques RDM est l'abréviation de "Remote Device Management". Grâce à cette fonction, les utilisateurs LUMINA H380 User’s Manual Ver. 1.00 Page...
  • Page 38 Si le luminaire est installé dans un environnement poussiéreux ou enfumé, un nettoyage régulier est très important. Débranchez l'appareil avant toute intervention ! Utilisez un chiffon propre et sec. LUMINA H380 User’s Manual Ver. 1.00 Page...

  • Page 39: Spécifications Techniques

    Lampe 380W LED Canaux DMX 30 canaux Angle du faisceau 4° à 48 ° Flux lumineux 93000 lux@5m Fusible T8A , 250 V Dimensions de l'appareil 415*340*632mm Poids net 21KG Poids brut 22.5KG LUMINA H380 User’s Manual Ver. 1.00 Page...
  • Page 40 Importé par / Imported by EVOLITE – MSC 9, Rue C. Flammarion 91630 Avrainville / FRANCE infos@msc-distribution.com Tel : +33 1 69 34 80 62 LUMINA H380 User’s Manual Ver. 1.00 Page...
