- Page 1 Model SD1120 SUBMERSIBLE SCALE 11 POUNDS/5 KILOGRAMS/176 OUNCES by pounds, pounds:ounces, ounces, fractional ounces, kilograms and grams...
-
Page 2: Power Adapter
Before using the external power adapter, make sure that the printed voltage complies with the local voltage. Note: Use only an original CDN power adapter (AD-AC1110X). The use of other adapter is subject to approval by CDN. 1. Insert the adapter plug into the jack on the side of the scale. - Page 3 3. Press the POWER button ( ) to turn off. B. Auto Off The scale automatically turns off after 2 minutes of inactivity. Note: Auto-off is disabled when the AC adapter is used. See Section L2 to program the auto-off up to 5 minutes or disable completely. C.
- Page 4 G. Tare The tare function resets the scale display to zero to measure only the weight of an item. It is frequently used to subtract the weight of containers. 1. When the scale is on, place a container on the platform. 2.
-
Page 5: Field Calibration
b. If the weight is higher than high limit, the scale beeps and the backlight becomes red. HIGH appears on the left side of the display. c. If the weight is within the Low/High limits, the backlight remains green. 6. To clear the Low/High limits, press the SET and TARE buttons simultaneously. -
Page 6: Battery Status
3 seconds before automatically turning off. Return to Section I2 and try again. J. Battery Status 1. The BATTERY icon ( ) and bAtt appear on the display when battery status is low and needs to be charged. 2. The BATTERY icon ( ) flashes continuously while charging. - Page 7 on (enabled) and oFF (disabled). e. Press the SET button to confirm the status and to select the next unit in the sequence. f. Repeat steps d. and e. for each respective unit. Upon confirming the status for kg, Unit appears on the display.
-
Page 8: Usage Guidelines
Note: Clean the scale platform before each use. The stainless steel removable platform is dishwasher safe; the scale base is not dishwasher safe. Note: Replacement AC adapter, removable platform and 5 kg calibration weight available. USAGE GUIDELINES • Scales are precision instruments and must be handled with extreme care. - Page 9 PRECAUTIONS • Keep the scale and/or adapter away from children. • Do not clean the scale with abrasive or corrosive compounds, which may scratch the surface and corrode the electronic circuits. • Do not subject the scale to excessive force, shock, dust, temperature or humidity, which may result in malfunction, shorter electronic life span, damaged battery and/or distorted parts.
-
Page 10: Specifications
SPECIFICATIONS Measurement Range 11 lb/176 oz/5kg capacity Unit of Measure oz/frac oz/kg/g/lb:oz/lb Resolution 0.05 oz, 1/8 oz, 0.001 kg, 1 g, 0 lb:0.1 oz, 0.002 lb Operating Range 59 to 104°F/15 to 40°C, 30-85% RH Storage Range 32 to 104°F/0 to 40°C, ≤85% RH Water Resilience IP68 –... - Page 12 Any instrument that proves to be defective in material or workmanship (excluding batteries) within one year of original purchase will be repaired or replaced without charge upon receipt of the unit prepaid at: CDN, PO Box 10947, Portland, OR 97296-0947. This warranty does not cover...
