Split Core 1-phase AC Current
Transducer
Istructions
CE-IJ03-##GS4-0.5
1 Overview
This device is a split core 1-phase AC current electrical isolation
transducer with principle of electromagnetic isolation, It is designed
to measure and monitor average RMS AC current, then produce a
standard signal such as 4-20mADC, 0-5VDC and so on. The
products are widely used in telecommunications, electricity,
railways, industrial industries and other fields.
2 Case style
3 Part Number
4 Specifications
Test conditions: auxiliary power: +24 VDC
room temperature: 25 ℃.
Input range: 0~10AAC~500AAC
Output: voltage, current, switch, frequency, tracking
Power supply: 12VDC, 15VDC, 24VDC
Accuracy: 0.5class
Load capacity: load ≥ 2KΩ (voltage output Vz)
load ≤ 250Ω (current output Iy, Iz)
Temperature drift: ≤400ppm/℃
Isolation voltage: ≥2500 V DC
Response time: ≤300 mS
Quiescent Current: ≤10mA
≤0.4W, ≤0.5W
:
Rated power consumption
http://www.ce-transducer.com
sales@ce-transducer.com
Output ripple: ≤10mV
Frequency range: 45~65Hz (up to 5K, please specify when
Surge impact immunity:
Input overload capacity: 20 times the nominal value of the
(Applying a repetition of five times a second, interval 300S);
Operating temperature: -10~ 60°C; humidity: ≤95% (no dew);
Storage temperature: -55 ~+65°C
5 Connections Diagram
(For reference only, the actual application to the product wiring
diagram shall prevail)
Figure1
6 Mounting diagram (mm)
Unit 501,BLDG C, BAOFU Jewelry Garden, 33 BULAN Road, Longgang district
Shenzhen City, China
ordering);
Power port level ± 2KV (L-N/2Ω/integrated wave)
Analog I/O port level ±2KV (L-N/40Ω/integrated wave);
measurement current (maximum 500A)
Figure 3 the voltage output wiring diagram
Figure 4 the current output wiring diagram
Figure 5 the two-wire output wiring diagram
Figure 6 the switch output wiring diagram
DIN35 rail mounting or screw mounting, the installation size
Post code: 518049
humidity: ≤95% (no dew).
;
Voltage
Signal output
Power supply
Current
Signal Output
Power Supply
