KI Toggle EL Assembly Instructions Manual

Motor-Operated Furnishing
-FOR COMMERICAL USE ONLY-
M6 x 35 M8 x 12
socket head button-head
cap screw
machine screw
Figure 1
ATTENTION: Following assembly,
prior to being placed into service.
table to malfunction.
Table "Zero Setting" Press and hold the Up button for
:
two seconds then release. Next, press and hold the Down
button until table has reached its lowest position then release
Down button. Then, press the Down button again and hold for
approximately 10 seconds. The table now re-set at its "Zero
Setting" position and is ready to operate.
Assembly Instructions
Dual Motor Adjustable-Height Base, Model EL
Detail A
M6 x 35
socket head
cap screw
foot
leg-to-leg
spanners
set screw
holes
cross-support
tube
table must be "zero set"
Failure to do so can cause
Toggle Tables
®
July 2024
adjustable
"
#10-24 x / 3
glide
8
Torx head
screws
non-locking
caster
locking
caster
foot
adjustable
glide
foot
plate
leg
column
M8 x 12
button-head
machine screw
mounting
flange of
motor housing
end-support
tube
Assemble units as described herein only. To do otherwise
may result in instability. All screws, nuts and bolts must be
tightened securely and must be checked periodically after
assembly. Failure to assemble properly, or to secure parts
may result in assembly failure and personal injury.
Adjustable-Height Base Assembly
1. Carefully remove contents from
packaging, set out on a soft,
protective surface and refer to
Figure 1 to identify the parts required
for assembly.
2. Position two cross-support tubes
(with mounting tabs down and facing
inward), and one end-support tube
out as illustrated. Place a leg column
assembly over the three tubes,
aligning all six mounting holes on
the flange of the column with the
mounting holes on the three tubes.
Using six M8 x 12 button head
machine screws torqued to 9.5 ft/lb,
secure the flange of the leg column
to the three base tubes (Figure 1).
3. Mount the foot to the leg column by
first positioning a plastic foot plate
over the mounting location on the leg
column. The plastic foot plate should
be oriented so the raised flange faces
down on the leg to nest the foot plate
in place. Position a foot over the flat
face of the foot plate, aligning holes
in underside of the foot with the
mounting holes in the column, and
secure foot to column with four
M6 x 35 socket head cap screws.
Torque to 7.5 ft/lb (Figure 1).
4. If casters are required, twist both
adjustable glides out of the foot.
Locking and non-locking casters are
supplied. Locking casters should be
located toward the front, user side of
the table for easy access while the
non-locking casters are located to the
back. Using four #10-24 x / " Torx
3
8
screws, carefully secure the casters
to the foot (Detail A).
5. Repeat steps 2 & 3 for second leg
assembly and step 4 if casters are
required (Figure 1).
6. Position two leg-to-leg spanners
with channel opening face up, then
slide both spanners into the open
ends of each base tube of both base
assemblies. Slide bases together, but
do not secure with set screws at this
time (Figure 1).
