Resmed AirFit N30 Manual

How to use the fitting template

1. Please ensure the template is printed to scale
2. Cut out along dotted line
3. Refer to diagram on template to determine appropriate cushion size

Actual Size:
5 1/2" (Width)
4 1/4" (Height)

Fitting guide for AirFit N30

1. While holding the nasal cradle cushion away from the nose, make sure the cushion size from the nose, make sure the cushion (SML, MED or SML-WIDE), and left (L) (SML, MED or SML-WIDE), and right (R) indicators are facing towards and right (R) indicators you. Place the nasal cradle cushion under you. Place the nasal cradle cushion under the nose.

2. Pull the QuickFit™ headgear over the head by holding the bottom band and guiding it around the back of the head. The top band should sit comfortably on the crown of the head.

3. Briefly pull the nasal cradle cushion away from the nose, and then place it back under the nose to ensure the cushion fits well.

4. To achieve a comfortable fit, spread the split bands on the QuickFit headgear apart to loosen the mask or draw them closer together to tighten the mask.

5. To fix a mask leak, adjust the QuickFit headgear by pulling it through the single side-clip. Adjust it just enough for a comfortable seal. Do not overtighten. You may need to adjust the headgear over time.

6. The mask is now fitted and ready to use.


For patients with long hair, we recommend feeding it through the back of the headgear. If tied in a ponytail, it should sit high enough to fit comfortably through the split strap on the headgear.

ResMed.com/AirFitN30
