To ensure safe operation of your stroller, please follow these instructions carefully. Please keep these instructions for future reference.
![]()
Before assembly and each use, inspect this product for damaged hardware, loose joints, missing parts or sharp edges. NEVER use if any parts are missing or broken.
![]()
Adult assembly is required.
The front wheels, rear wheels, child tray, and parent tray MUST be installed prior to use.
FRONT WHEELS
To attach the front wheels, unfold stroller as described in the section following:
- Unlock the fold latch (Fig. 1a).
![]()
- Unfold stroller frame by sliding the thumb trigger to the left and squeezing the pull trigger (Fig. 1b) while pulling backward on the stroller handle (Fig. 1a).
![]()
- To attach the front wheels, lean the stroller back so that it rests on the handle with the front and rear legs pointing upward. Position the front wheels over the front leg tubes so that the hole in the housing lines up and will slide onto the legs (Fig. 1c). Firmly push down until the wheels lock securely into place. Tug on each wheel to ensure they are both securely attached.
![BABYTREND - Sit-N-Stand Ultra - ASSEMBLY - Step 1 ASSEMBLY - Step 1]()
REAR WHEELS
-
- Position rear axle over the rear leg tubes, brake pedals facing the back. At the same time, push down applying equal pressure to both sides until they lock into place (Fig. 2).
![BABYTREND - Sit-N-Stand Ultra - ASSEMBLY - Step 2 ASSEMBLY - Step 2]()
NOTE: NEVER use the stroller if the wheels do not lock into place. If you need assistance, please contact our customer service department at 1-800-328-7363, M-F, between 8 a.m. and 4:30 p.m., PST.
FOOT REST
-
- Push downward on the foot rest until it snaps onto the U-shaped frame cross member (Fig. 3).
![BABYTREND - Sit-N-Stand Ultra - ASSEMBLY - Step 3 ASSEMBLY - Step 3]()
CHILD TRAY
![]()
The child's tray is not a restraint device: always secure your child with the seat belt. DO NOT lift the stroller by the child's tray. Use care when attaching the child's tray on the stroller with a child in the stroller.
-
- To attach the child tray: Push the tray downward and onto each side of the front armrests until both sides snap into place (Fig. 4).
NOTE: Check that tray is securely latched in place.
![BABYTREND - Sit-N-Stand Ultra - ASSEMBLY - Step 4 ASSEMBLY - Step 4]()
-
- To access the child seat: Pull one side of the release lever (Fig. 5a) located on the underside of the child tray and lift upward. Either side of the child tray will lift and rotate out of the way to allow access to the seat (Fig. 5b).
![]()
-
- To rotate the child tray: In order to attach an infant car seat to the stroller, the child tray must be rotated to the vertical position. Press buttons on both sides of the child tray to rotate down 90 degrees (Fig. 6).
![BABYTREND - Sit-N-Stand Ultra - ASSEMBLY - Step 6 ASSEMBLY - Step 6]()
-
- To remove the child tray: Pull both release levers located on the underside of each side of the tray and lift upward (Fig. 7).
![BABYTREND - Sit-N-Stand Ultra - ASSEMBLY - Step 7 ASSEMBLY - Step 7]()
CUP HOLDERS
-
- To attach the cup holder: Push the cup holders downward and onto each side of the armrests until it snaps into place (Fig. 8). To remove, pull the release lever located on the underside of the cup holder.
![BABYTREND - Sit-N-Stand Ultra - ASSEMBLY - Step 8 ASSEMBLY - Step 8]()
CANOPY AUVENT
-
- To attach the canopy: Line up the male fittings on the canopy with the slots on the armrest and push both fittings downward until snapped into place (Fig. 9a).
![BABYTREND - Sit-N-Stand Ultra - ASSEMBLY - Step 9 ASSEMBLY - Step 9]()
- To open the canopy, push forward on the front edge of the canopy while holding the rear of canopy in place. To close the canopy, pull backward on the front edge. To remove the canopy: Press the snap button under the armrest and pull to release the fitting from the slot. Repeat for the other side (Fig. 9b).
![BABYTREND - Sit-N-Stand Ultra - ASSEMBLY - Step 10 ASSEMBLY - Step 10]()
NOTE: The canopy is only needed when using the seated position for your child. It is not needed when using with the infant car seat.
PARENT TRAY
-
- To attach the parent tray, position the tray so that the hinges for the storage compartment are facing forward. Snap the parent tray to the stand at the top of the frame (Fig. 10).
NOTE: Check that the tray is securely latched in place.
![BABYTREND - Sit-N-Stand Ultra - ASSEMBLY - Step 11 ASSEMBLY - Step 11]()
SAFETY
BRAKES
![]()
Always set brakes when the stroller is not being pushed so that the stroller will not roll away. NEVER leave stroller unattended on a hill or incline as the stroller may slide down the hill.
-
- To engage brakes, apply light downward pressure to the brake lever located on each rear wheel. The stroller may require slight forward or rearward movement in order to line up the teeth on the brake with each wheel brake cluster (Fig. 11a).
NOTE: Check that the stroller will not move and that both brakes are properly applied.
![]()
- To release, gently lift up on the brake lever (Fig. 11b).
![]()
TO SECURE THE CHILD
![]()
Avoid serious injury from falling or sliding out. Always use the safety harness.
STRANGULATION HAZARD: Child can strangle in loose straps. Never leave child in seat when straps are loose or undone.
TANDEM STROLLER - 5-POINT HARNESS
-
- The shoulder straps of the 5-point harness has 2 attachment positions. Select the loop position that places the shoulder strap level with, or below the top of the child's shoulder and feed the shoulder harness under the correct loop. To adjust harness slot unhook the shoulder strap from the crotch buckle (Fig. 12a). Feed the shoulder strap through the harness spread slots. You can access these slots from the rear of the seat. Feed shoulder strap through appropriate slot and reattach shoulder strap to crotch buckle.
![]()
- Carefully place the child in the stroller seat and bring the safety harness around the child's waist and over the shoulders. Place the crotch strap between the child's legs. Insert the male end of each shoulder/waist belt into the buckle on the crotch strap. Tighten the harness to be snug around the child's waist and over the child's shoulders (Fig. 12b).
![]()
-
- To release, push Button on Center Clasp, the two Harness Buckles will pop free (Fig. 13).
NOTE: Buckles may be hard to release when first used.
![]()
CAR SEAT SAFETY BELT
-
- Strap the safety belt over the infant car seat through the seat belt slots on the infant car seat, connect the buckles together (Fig. 14a). The safety belts for the infant car seat is located in small pockets on outer sides of seat pads (Fig. 14b). Tighten the strap so the infant car seat fits snug and can't move.
IT IS VERY IMPORTANT THAT THE INFANT CAR SEAT STRAP IS ALWAYS TIGHTLY FASTENED AROUND THE INFANT CAR SEAT.
NOTE: When the stand feature safety belt is not used, you must store the stand feature safety belt back to its storage.
![]()
![]()
PLATFORM - Safety Belt
-
- The stroller rear is equipped with a safety belt designated for the platform. Always secure the stand feature safety belt behind child and engage buckle when using the platform (Fig. 15a).
![]()
- To release, apply pressure to both sides of each male clip until the clip is released. This process requires a moderate amount of effort so as to prevent an accidental release by your child (Fig. 15b).
![]()
OPERATION
TO RECLINE SEATS
![]()
The upright position should be used only for a child that is at least 6 months old.
-
- The front seat has a two position recline. To recline the seat, rotate the recline bar and press backward on the seat back (Fig. 16). To place the seat in the upright position, press upward on the seat back while rotating the recline bar.
![]()
TO ATTACH INFANT CAR SEAT
![]()
This stroller is NOT compatible with any ALLY Car Seats.
Infant car seat sold separately
(visit babytrend.com for compatibility chart)
ATTENTION: The infant car seat may only be attached on the front seat of the stroller.
-
- To attach the infant car seat in the front seating position: Attach the child tray in the front seating position and rotate to the vertical position. Place the seat in the reclined position (refer to Fig.16). Set the infant car seat facing toward the rear of the stroller so the seat shell goes into the child tray and latches into place (Fig. 17).
![BABYTREND - Sit-N-Stand Ultra - OPERATION - Step 1 OPERATION - Step 1]()
-
- To remove the Infant Car Seat, squeeze the release handle located at the foot-end of the seat and carefully lift upward on the seat (Fig. 18).
![]()
JUMP SEAT
![]()
The rear platform and jump seat are designed to accommodate a child who is at least 2 1/2 years old, has good balance and coordination, and is not over 40 inches tall.
Jump Seat: To use jump seat, please remove the child tray (if attached).
SIT ON JUMP SEAT
-
- Have the child sit on the jump seat facing backwards. Secure the child with the jump seat 3-point harness. Part of the 3-point harness is stored in the pocket on the back of the front seat. Put the seat belt around the child's waist, and buckle to the crotch strap. Adjust the seat belt to be snug around the child's waist (Fig. 19a).
![BABYTREND - Sit-N-Stand Ultra - OPERATION - Step 2 OPERATION - Step 2]()
- RELEASE! Push the button on the center clasp and the all the harness straps will release (Fig. 19b).
![BABYTREND - Sit-N-Stand Ultra - OPERATION - Step 3 OPERATION - Step 3]()
STAND ON THE PLATFORM
-
- Position the child on the platform on the back of the stroller. Be sure child is standing facing forward and hands are holding frame. Secure the stand feature safety belt behind child and engage buckle (Fig. 20). To release see step 15.
NOTE: Be sure that the child's feet are fully on the platform at all times.
![BABYTREND - Sit-N-Stand Ultra - OPERATION - Step 4 OPERATION - Step 4]()
FOLD
TO FOLD STROLLER
![]()
Care must be taken when folding and unfolding the stroller to prevent finger entrapment.
![]()
Do not allow children near stroller
- Close the canopy as described in the canopy section.
- Pull stroller backward several inches to rotate the front wheels to the front (Fig. 21a).
![]()
- To fold the stroller slide the fold lock with your thumb while squeezing the large fold button in the center of the handle and push forward on the handle (Fig. 21b).
![]()
- Once the stroller begins to fold, release the handle and push forward on the handle until the stroller is folded. Lock the fold latch (Fig. 21c).
![]()
MAINTENANCE
CARE AND MAINTENANCE
Seat Pad
- To clean the seat pad, use only mild household soap or detergent and warm water on a sponge or clean cloth.
OTHER
- Check your stroller for loose screws, worn parts, torn material or stitching on a regular basis. Replace or repair parts as needed.
CUSTOMER SERVICE
The Customer Service Department can be contacted at 1 (800) 328-7363 Monday through Friday between 8:00 a.m. and 4:30 p.m. (PST). Return Authorizations are required prior to returning product(s) to Baby Trend®.
Baby Trend, Inc.
13048 Valley Blvd.
Fontana CA 92335
1-800-328-7363 (8:00am ~ 4:30pm PST)
www.babytrend.com
