Braun Silk-epil 5 (5391) Manual

Introduction

Description

* INGREDIENTS: PEG-115M, PEG-7M, PEG-100, SILICA, ALOE BARBADENSIS LEAF JUICE, PENTAERYTHRITYL TETRA-DI-T-BUTYL HYDROXYHYDROCINNAMATE, TOCOPHERYL ACETATE, TRIS(DI-T-BUTYL)PHOSPHITE, VITIS VINIFERA (GRAPE) SEED OIL, PERSEA GRATISSIMA (AVOCADO) OIL, BHT, GLYCOL

1. Skin contact cap
2. Epilation head

3a. Charge indicator
3b. SensoSmart^TM light*

4. On/off button
5. Release button
6. Special cord set (design can differ)
7. Massage cap*
8. Beginner cap with protective cover*
9. Shaver head with trimmer cap*

* not with all models

Charging

• Using the special cord set (6) connect the appliance to an electrical outlet and charge it for 1 hour.
  Charging light (3a)
  Flashing green: charging
  Green: fully charged
  Yellow: 15 min charge left
  Flashing yellow: 5 min charge left
• Once fully charged, use the appliance cordless. Operation time is 30 minutes when it is used within 24 hours after charging. Recharge it when the yellow charging light comes on or when the motor has stopped completely. For best performance, always use a fully charged appliance.
• The best environmental temperature for charging, using and storing the appliance is between 15°C and 35°C. In case the temperature is beyond this range, the charging time might be longer whereas the cordless operation time might be reduced.

Switching on

Push the on/off button (4) to switch on (speed 1).
Push a second time to switch to speed 2. Push one more time to turn off the appliance.
The SensoSmart^TM light (3b) shines red when you apply too much pressure.

Travel lock

Push and hold the on/off switch at least 3 seconds to activate the travel lock. A beep confirms that the switch is locked. To unlock, push and hold 3 to 5 seconds. You can also unlock the switch by connecting the appliance to the mains.

Epilation

• When epilating on dry skin, your skin must be free from grease or cream.
• The appliance can be used on wet skin, even under running water. Make sure that the skin is very moist. In order to achieve optimum gliding conditions for the appliance, you may use a shower gel while epilating.

The epilation head (2) is equipped with different caps (1, 7 or 8 depending on model). Choose the cap according to your needs:

Skin contact cap (1): provides a close skin contact and adapts to all body areas. Whenever the SensoSmart^TM light shines red, this is to remind you not to press too hard.

Massage cap (7): can be used instead of the skin contact cap (1). It stimulates the skin to make the epilation process more comfortable.

Always stretch your skin while epilating. Hold the appliance at a right angle (90°) against your skin and guide it in a slow, continuous motion against the hair growth in the direction of the switch.

Use on legs:
Epilate your legs in an upward direction. When epilating behind the knee, keep the leg stretched out straight. Keep your leg stretched out straight when removing hair in the area behind the knee
.

Use on underarm and bikini zone:
Since these areas are sensitive to pain, start with speed 1. With repeated usage, the pain sensation will diminish. Before epilating, thoroughly clean the respective area to remove residues (like deodorant). When epilating the underarm, keep your arm raised up and guide the appliance in different directions in order to catch all hairs that might grow in various directions.

Beginner cap (8) for first time users

Combines epilation and shaving to help getting used to hair removal from the root. It has been designed for wet usage on legs only. Always apply shave foam or gel on your wet skin when using the beginner cap.

In the beginning phase (first 4 weeks), use the epilator with the beginner cap once a week to epilate and shave. Take special care on bony, uneven skin areas in order to avoid injuries caused by the blades. Between usages, rinse off the foam built up on the beginner cap.
After 4 weeks, you will be used to hair removal and can switch to epilation using the skin contact (1) or massage cap (7). If you want to continue to use the beginner cap, make sure to replace it after 12 usages (or in case the blade shows signs of wear, kinks, or damage). Replacement caps (reference #771WD) are available from the retailer where the appliance was bought, from Braun Service Centres or via www.service.braun.com.

Epilation tips

• If you have not used an epilator before, or if you have not epilated for a long period of time, it may take a short time for your skin to adapt to epilation. The discomfort experienced in the beginning will decrease considerably with repeated use as the skin adapts to the process.
• When epilating for the first time, it is advisable to epilate in the evening, so that any possible reddening can disappear overnight. To relax the skin we recommend applying a moisturizing cream after epilating.
• Epilation is easier and more comfortable when the hair is at the optimum length of 2 to 5 mm. If hairs are longer, we recommend that you first shave and epilate the shorter, re-growing hairs after 3 to 5 days.
• Fine, re-growing hairs might not grow up to the skin surface. Exfoliation helps preventing in-grown hairs by scrubbing/ removing the upper skin layer so that fine hairs can get through to the skin surface.

Cleaning the epilation head

Regularly cleaning the epilation head ensures good hygienic conditions. First remove the cap used (1, 7 or 8) and rinse it under running water. To remove the epilation head, press the release button (5).

Dry: Thoroughly clean the tweezers element using the cleaning brush.

Wet: After each wet usage (especially with gel), clean the epilation head under running water. During cleaning, turn on the epilator for a few seconds. Re-attach one of the caps only when the epilation head is completely dry.

General information on epilation

All methods of hair removal from the root can lead to in-grown hairs and irritation (e.g. itching, discomfort or reddening of the skin), depending on the condition of the skin and hair. This is a normal reaction and should quickly disappear, but may be stronger when you are removing hair from the root for the first few times or if you have sensitive skin.

If after 36 hours the skin still shows irritation, we recommend that you contact your physician.

In general, the skin reaction and the sensation of pain tend to diminish considerably with repeated use of Silk·épil. In some cases inflammation of the skin could occur when bacteria penetrate the skin (e.g. when sliding the appliance over the skin). Thorough cleaning of the epilation head before each use will minimize the risk of infection.

If you have any doubts about using this appliance, please consult your physician. In the following cases, this appliance should only be used after prior consultation with a physician: eczema, wounds, inflamed skin reactions such as folliculitis (purulent hair follicles), varicose veins, around moles, reduced immunity of the skin, e.g. diabetes mellitus, during pregnancy, Raynaud's disease, haemophilia, immune deficiency or candida.

Shaving

The shaver head (9) is designed for a fast and close shave of legs, underarms and bikini line, contour trimming and cutting hair to 5 mm length. Use the shaver head only on dry skin and with speed II.

1. Shaving: Select « ».

2. Contour trimming: Select « ».

3. Cutting hair to 5 mm length: Select « » and put on the trimmer cap (I).

4. Cleaning Tap the shaver foil (II) on a flat surface. Do not clean it with the brush as this may damage the foil.

5. The shaving parts need to be lubricated regularly every 3 months.

6. Replace the foil frame (II) and cutter block (III) when you notice a reduced shaving performance.

   Replacements parts can be obtained from your retailer or Braun Customer Service Centres or via www.service.braun.com. Do not shave with a damaged foil.

Guarantee

We grant a 2 year guarantee on the product commencing on the date of purchase.

Telephone: +612 8864 5000
Facsimile: +612 8864 5574
Email: gillette@au.pgconsumers.com

Braun Customer Service Centre: address information available online at www.service.braun.com

Safety Instructions

Before using the appliance, please read the usage instructions carefully and keep them for future reference.

• This appliance is provided with a special cord set (6) with an integrated Safety Extra Low Voltage power supply. Do not exchange or manipulate any part of it. Otherwise there is risk of electric shock.
• Only use the special cord set provided with the appliance.
• If the appliance is marked 492, you can use it with any Braun power supply coded 492-XXXX.
• This appliance is suitable for use in a bathtub or shower. For safety reasons, it can only be operated cordless.
• Do not open the appliance! The built-in rechargeable battery only be replaced by an authorized Braun Service centre.
• This appliance can be used by children aged from 8 years and above and people with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the safe use of the appliance and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children unless they are older than 8 years and supervised.
• For hygienic reasons, do not share this appliance with other people.
• When switched on, the appliance must never come in contact with the hair on your head, eyelashes, ribbons, etc. to prevent any danger of injury as well as to prevent blockage or damage to the appliance.
