Summary of Contents for Ogawa OG 7888
- Page 1 User Manual OGAWA MASSAGE CHAIR OG 7888...
-
Page 2: Table Of Contents
OG 7888 MASSAGE CHAIR Thank you for purchasing this product, please read this manual in detail before you use it to learn the correct use of this product. Please pay special attention to important safety warnings and keep the operation manual in good condition for reference. -
Page 3: Important Safety Warnings
Important Safety Warnings • Please read this safety precaution carefully before starting to use product. • The precautions shown here are to remind you to use this product properly to prevent you and others from being hurt or damaged. Caution: If used incorrectly, the user may be harmed, or the items may be harmed or damaged, which includes the damage to houses, household property, livestock, and... - Page 4 The following people should consult their doctor before using: • Patients with cancers • Pregnant or menstrual woman • High fever • Patients with acute illness pain • Patients with osteoporosis • Patients with perceptual disturbance • Heat problems,including pacemakers users •...
- Page 5 Before using, please make sure that you are not wearing any accessories to avoid injury. Please control the massage time within 15 minutes. In addition, please control the massage time of the same part within 5 minutes. Continuous massage for too long may cause muscle and nerve pain.
- Page 6 This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.
-
Page 7: Chair Installation
Chair Installation Remove main body and accessories from the packing box Accessories Main Body Left/Right Side Panel Remote Control Bracket (Inner and outer) Foot Massager Headrest Backrest Cover Manual Book Power Cord... - Page 8 Chair Installation Installation Guideline Installation of Foot Massager I, Installation of Foot Massager 1, Align the foot machine with the connecting holes on both sides of the seat and insert botls and cotter pins to secure. * Figure ① 2, Use bolt an cotter pin to dock the link rod under the seat to the foot machine. *Figure ② 3, Install air bags into the air inlet connector (TWO connectors) which must be connected with the corresponding colors and fix with wire harness.
- Page 9 Chair Installation Installation of side panels Step I 1, Align the holes of the inner panel with the mounting holes of the seat frame by locking 5 screws. Figure ① (M6x20 hexagon socket screw*1, M6x20 round head screw*4) 2, Install air bags into the air inlet connector which must be connected with the corresponding colors; then connect the wire to the air valve plate, and fix it tightly with a wire harness after the connection.
- Page 10 Chair Installation Step two 3, After the installation of the inner panel is completed, install the outer panel should push the fixed latch firstly from front to back, then use 3.5x16 round head pointed tail lock. sliding direction 3.5x16 round head pointed tail Step Three 4, When installing the upper cover of the left armrest, install the hand controller bracket first, and then slide into the fixed mortise.
- Page 11 Chair Installation Massage Chair Placement Please place the massage chair in a flat place. When placing the massage chair, be sure to leave enough space around the chair so that the legs and backrest of the chair can rise and fall freely. It is recommended to place a rug under the product to avoid damage to the floor or carpet.
-
Page 12: Names Of Parts And Function
Names of parts and function Massage chair Speaker and mood lighting Headrest Please turn to the back side Waist and back heating while massage Shoulder Armrest Air pressure massage for Air pressure massage for arms shoulder Backrest Quick Zoom Buttons massage the entire back Adjust the intensity quickly Quick Adjust Buttons... - Page 13 Hand Controller Key Functions Hand Controller Favourites Timing Display and adjustment Fault Number Display Setting 5 languages & Screen brightness adjustment Massage Mode Display Fixed Point Adjustment Neck & Shoulder Adjustment For Manual mode only Air Bag action real-time display Back and Waist Heat On/off...
-
Page 14: Before Each Massage
Before Each Massage Connect to the Power 1. Plug the power plug into the socket 2. Turn on the power switch (It is located below the back of the seat.) Items to Check 1. Check the surroundings • Confirm that there are no people, no pets, and no objects around the back of the massage chair or below the legrest. -
Page 15: Adjustment Method Of Chair
Adjustment method of Chair Sitting Posture Adjustment A. Hand Controller - Sitting Posture Adjustment Interface 1. Press to enter the sitting posture adjustment interface, there are 4 sitting modes: is Zero Gravity is Cradle is Lie Down is get up 2. -
Page 16: Quick Start
1. Touch the auto mode on the screen to select the preferred program. Neck & Shoulder Ogawa Special • 12 Automatic massage programs for choice: Ogawa special, Full body, Deep tissue, Japanese, Thai, Swedish, Neck & Shoulder, Seniors, Back Relax, Full Body Seniors Waist &... - Page 17 Automatic Massage Programs 3. After detection is complete. The touch screen will show your back curve as shown on the right. Then the chair will start the massage program. 4. The touch screen displays the automatic program currently in the massage. Timing Display and adjustment Favourites Setting...
- Page 18 • Brightness, for brightness settings, a total of 3 levels. • Speaker LED, to choose massage chair bluetooth lights and “Ogawa” logo lights. When touch this screen, bluetooth light and Logo light will be turned on, there are 3 kinds of bluetooth lights to choose.
-
Page 19: Basic Massage Methods
Ogawa options Touch the manual mode on the screen to select the preferred program. Ogawa Options Soft Power Bottom-up kneading massage From bottom to top massage muscles Relax Kneading Kneading massage from top to bottom Knead muscles powerfully from top to bottom... - Page 20 Ogawa options program. Soft Power Relax Kneeding 2. Manual mode has 10 Ogawa options, 3 special methods and optional massage speed and range options. Not all the massage Back Neck relax combinations will be available. Acupressure • If you do not touch the screen within 10 seconds, this page will exit.
-
Page 21: Manual Massage Mode
Manual Massage Mode 4. Under the manual program, the massage position can be selected from 4 options: full body(Full), shoulder & neck(Upper), waist & hip, Spot(Lower). 5. Massage speed adjustment: touch to select from three speed: "fast, medium, and slow". This function may be not available for all massage methods. •... -
Page 22: Air Pressure Mode
Ogawa Air Quick Start - Connecting the power of the chair. - Pressing the on/off button located on the back of the chair next to the electrical plug. - Remove shoes and sit in the chair. - Press the button, the initial touch screen displays as below. - Page 23 Air-Pressure Massage Mode 3. The touch screen displays the manual program currently in the massage. Timing Display and adjustment Favourites Setting Massage position Massage mode display Neck & Shoulder Massage Roller Position Adjustment Back & Hip heating Air pressure Calf & Feet heating inflation status Massage strength Air pressure adjustment...
-
Page 24: Other Functions
• Screen luminance, for brightness settings, a total of 3 levels. • Moodlight, to choose massage chair bluetooth lights and “OGAWA”logo lights. When touch this screen, bluetooth light Mood light Mode 3 and Logo light will be turned on, there are 3 kinds of bluetooth lights to choose. -
Page 25: Cleaning And Storage
Cleaning and Storage Cleaning Instructions Cleaning the Chair Synthetic Leather Wipe off the synthetic leather with a soft dry cloth. • Do not clean the product with chemicals such as thinners, gasoline and alcohol. • When using a leather maintenance product (i.e. cleaning cloths) sold on the market, follow its directions for use. -
Page 26: Troubleshooting
Troubleshooting Never disassemble, repair or modify the chair without permission. This may cause sparks or injuries due to abnormal operation. During the massage, the following sounds or feelings are caused by the structure, they are not abnormal, and they’ll have no effect on the service life. •... -
Page 27: Maintenance & Warranty&Product Specification
Maintenance & Warranty Maintenance Check if the following If you haven't phenomena occur? used it for To prevent malfunctions • Burnt smell or accidents, turn off the many years, • The power cord power and unplug the be sure to Stop and plug are power plug.
