- Page 1 1-866-207-6631 sales@rackmountsolutions.net IP High Density Cat 5 KVM User Manual UIP-1602 / UIP-3202...
-
Page 2: Installation
UIP-1602 / UIP-3202 IP Cat5 KVM Installation screw A: M3.2 x 4.5 mm screw B: M4 x 10 mm ■ Install each bracket using screws pro- vided shown in Figure 1. Figure 1. Installing the bracket to the KVM. ■... -
Page 3: Package Content
UIP-1602 / UIP-3202 IP Cat5 KVM Package Content (only for rackmount KVM) KVM switch x 1 pc Screw M3.2 x 4.5mm x 4 pcs Screw M4 x 10mm x 8 pcs Bracket x 1 set (KVM x 1 set ; IP KVM + CD disc x 1 set) - Page 4 UIP-1602 / UIP-3202 IP Cat5 KVM Connection Dual power Local UIP-1602 with failover Console USB Serial Ethernet Cascade UIP-3202 Connection Rackmount KVM Internet hub Cat5 cable (up to 132 ft) Cat5 cable DG-100S dongle Connection KVM modules Internet hub back...
-
Page 5: Cascade Kvm Modules
Cascaded KVM ( Bank 2 to 8 ) must be single console Cat5 KVM - U-1601 / U-3201 ■ With the UIP-1602 cascade up to 128 servers. With the UIP-3202 cascade up to 256 servers. ■ Cascading multiple KVM by CBC-6 cable... -
Page 6: Dongle Connection
DG-100 / DG-100S Dongle Connection DG-100 PS/2 dongle ■ To connect DB-15 connector to the computer’s video card ■ To connect keyboard connector to the computer’s keyboard port ■ To connect mouse connector to the computer’s mouse port mouse Cat5 KVM switch Keyboard DB-15 Cat5 cable... - Page 7 KVM Membranes Power ON ■ Turn off all servers and KVM switches ■ Make sure all cables / connectors are properly connected ■ Recommend Power ON sequence is monitor, KVM switch fi nally computer Front Panel - Port LED Indications 16 ports Bank no.
- Page 8 Password The password is disabled by default ( i.e. There is no password required when you power on the KVM switch for the first time) ■ Enable password Scroll Lock + Scroll Lock + U Press the KVM hotkey Scroll Lock + Scroll Lock + P Logout the KVM by pressing the hotkey In SUPERVISOR level, enter “00000000”...
-
Page 9: Osd Operation
KVM OSD OSD Menu OSD operation next to the system name The PC is powered on next to the system name The PC is selected Access F1 MAIN MENU Logout the OSD menu Previous menu Cancel / Quit Enter Complete / Switch to selected port Switch to previous or next port PgUp/PgDn Switch to previous bank or next bank... -
Page 10: Kvm Hotkey
KVM Hotkey Local Console Hotkey Hotkey Function Scroll Lock + Scroll Lock + Space Bar Calling OSD menu Right-button mouse + Esc Calling OSD menu Scroll Lock + Scroll Lock + Switch to previous port Scroll Lock + Scroll Lock + Switch to next port Scroll Lock + Scroll Lock + PgUp / PgDn... -
Page 11: Initial Ip Confi Guration
UIP-1602 / UIP-3202 IP Remote Setup Quick Installation Guide of IP KVM for remote access Please perform the follow steps 1. Power off all KVM hardware and connected devices. 2. Connect the power supply to IP KVM 3. Connect the monitor, keyboard & mouse to console port of IP KVM (not applicable to integrated LCD drawer version ) 4. - Page 12 UIP-1602 / UIP-3202 IP Remote Setup 4. Remote access the IP-KVM switch via Web Using the HTTP protocol or a secure encrypted connection via HTTPS and entering the confi gured IP address of IP KVM switch into the web browser to remote access the IP KVM switch.
-
Page 13: Optional Accessories
Optional Accessories 1. Cat5 cable 1.1 CU-3 3 feet 1.2 CU-6 6 feet 1.3 CU-10 10 feet 1.4 CU-15 15 feet 1.5 CU-33 33 feet 1.6 CU-66 66 feet 2. Cat5 / USB KVM cascade cable 2.1 CBC-6 6 feet 3. -
Page 14: Dc Power 12V, 24V, 48V Input
DC Power 12V, 24V, 48V Input Input rating Input current l l u Output rating Ef? ciency Remarks: ■ Package does not include power cord... -
Page 15: Specification
Specifi cation UIP-1602 / UIP-3202 Cat5 KVM Port ▀ Number of ports: 16 or 32 Connector: RJ-45 Connectivity: DG-100S USB dongle / DG-100 PS/2 dongle up to 132 feet Local Console ▀ Graphic connector: HDDB15-pin Resolution: Up to 1600 x 1200 Input device: 2 x USB type A for keyboard &... - Page 16 General How do the KVM switches allow the user to switch ports? There are two ways to switch ports. One is the membrane buttons on the front and the other way is with Hot-key commands. What operating systems do the KVMs support? The KVMs support multi-platform support allows you to control Windows-based computers, Sun So- laris systems, Linux, or even Macs by a single KVM switch.
- Page 17 The server VGA resolution does not match the resolution of monitor ? The KVM supports DDC function which will dynamically detect and the DDC data. The problem may come from the power on sequence. For KVM switch The recommended power on sequence is - monitor, KVM switch and then servers. For remote console box It supports DDC function but does not support hot-plug, the recommend power on se quence is –...
-
Page 18: Troubleshooting
Troubleshooting There is no LED display on KVM membrane switch Make sure the power adapter plugged into the KVM Switch, if the LED’s still off, perform soft reset to KVM switch. Power cycle KVM switch. I can power on the KVM, but I am not getting any picture at all, how can I solve this? Switching to another port and checking if this port has the same problem If you switch to another port, please check the screen resolution is the same.
