TRIBIT StormBox - Speaker Manual

What's in the Box

Overview Buttons & Indicators

Connections

Bluetooth Pairing

Wireless Daisy Chain with Two StormBox

Connect the Speaker A and B

Keep Speaker A and B power on
Press the Bluetooth button on Speaker A at least 5s till the tone comes up
Wait for the Speaker A and B connecting success with tone

Pair/Connect the Speaker A
Note: Same as normal Bluetooth pairing
Enjoy music with two StormBox

Buttons

Function	Button	Operation
Power ON/OFF	Power Button	Press the button to turn on/off the speaker
Pair a Bluetooth Device	Bluetooth Button	Press the button to manually enter pairing mode
Volume Up	Volume +	Press the button to increase the volume level
Volume Down	Volume -	Press the button to decrease the volume level
Play/pause	MFB	Press once the button
Next track	MFB	Double press the button
Previous track	MFB	Press the button for 3 times
answer/end the incoming call	MFB	Press once the button
Reject an incoming call	MFB	Press and hold the button for 2s
Voice dial function	MFB	Press and hold the button for 2s to activate (your device must support this function)
XBASS	XBASS	Press the button to switch Bass and normal mode

Indicators

Indicator	Status
Power indicator	Blue indicator flashes slowl	Reconnection mode
	Blue indicator flashes quickly	Bluetooth pairing mode
	Blue indicator keeps sturdily o	Connected
XBASS indicator	White indicator lights up	Bass mode is activated
Battery indicator	Four white indicators light up	Remaining battery power: 71% 100%
	Three white indicators light up	Remaining battery power: 51% - 70%
	Two white indicators light up	Remaining battery power: 26% - 50%
	One white indicator lights up	Remaining battery power: 10% - 25%
	A red indicator lights up	Low battery power (<10%), Please recharge the speaker.

Reset

If this speaker has any problem, you can try to press and hold Volume + and Volume - buttons simultaneously for 5s to reset this speaker and remove the old pairing in your Bluetooth device, and then pair again.

Customer Service

18-month limited warranty
For FAQS and more information, please visit:
Email: support@tribitaudio.com
www.tribitaudio.com

Specifications

Bluetooth version: V4.2
Bluetooth profile: A2DP, AVRCP, HFP, HSP
Driver: 2 x 045mm, 2 x Passive radiator
Output power: 2 x 12W
Signal-to-noise ratio 2 80dB
Frequency response: 70-20KHz
Battery: ( 3.7V 2600mAh ) x 2
Music play time: Up to 20 hours (varies by volume level and music files)
Charging time: 4 hours @ 5V/2A

Dimensions: 68x180x68mm/2.68x7.09x2.68 in

Weight: 545g /19.20z

Safety Precautions

Avoid dropping the speaker on the floor. Do not try to disassemble or repair the speaker unless you are a technician.
Never expose the speaker to extreme high or low temperatures.
Stop use immediately if thunderstorm happens.
Do not clean its surface with any corrosive cleanser or other chemical solutions.
