- Page 1 HD NETWORK FISHEYE CAMERA QUICK START GUIDE ■ Please read this instruction carefully before using the product and keep it for further reference. ■ All the examples and pictures used here are for reference only. ■ The contents of this manual are subject to change without notice.
-
Page 2: Warning And Caution
Warning and Caution ■ If the product does not work properly, please contact your dealer or the nearest service center. Never attempt to disassemble the camera yourself. (We shall not be responsible for any problems caused by unauthorized repair or maintenance.) ■... - Page 3 Package Water-proof Quick start guide Camera Drill template connector kit Plastic screw Tapping screws ×3 (optional) × 3 anchor Overview 1 Ethernet Connector 2 MIC-Audio Input 3 HP-Audio Output 4 Video Output 5 Alarm Input/Output 6 RS485 7 DC12V Power Supply 8 SD Card Slot 9 Reset...
- Page 4 ALM-COM ALM-OPEN ALM-INA ALM-GND RS485T+ RS485T- DC12V ● Alarm Connection Alarm Input: Join the grounding ends of the sensor and the camera and then connect the signal cable of the sensor to the alarm input port (ALM-INA) of the camera. Alarm Output: Loosen the screws in the alarm output port.
-
Page 5: Installation
* If the RJ 45 connector of the network cable has a jacket and cannot be threaded through the kit, remove the jacket. If the jacket cannot be removed, cut off the connector and install an RJ 45 connector without the jacket. Installation Please install and use the camera in a dry environment. - Page 6 Install Camera ● Before installation, please make sure that the wall is strong enough to withstand 3 times the weight of the camera. ① Remove the trim ring from the gap of the camera (see Install SD Card ① ). ②...
- Page 7 ⑤ Install the trim fring back to the camera. Install Camera with Junction Box ● ① Remove the trim ring from the gap of the camera (see Install SD Card ① ). ② Install the junction box onto the wall. ③...
-
Page 8: Network Connection
Rubber plug ④ Install the trim ring back to finish the installation. Network Connection Here we take accessing the device via LAN for example. - Page 9 ● Access through IP-Tool ① Make sure that the camera and the PC are well connected to the LAN. ② Get the IP-Tool from the supplier and then install it in the computer. After that, run the IP-Tool as shown below. Device Network Search About Immediate Refresh...
- Page 10 ⑤ Follow directions to download and install the plugin if prompted. Available Web Browser: IE(plug-in required) /Google Chrome/ Firefox/Safari/Edge It is recommended to use the latest version of the above browsers.
