TVT Digital TD-9452A3-PA Quick Start Manual

Network Camera

Quick Start Guide
■ Please read this instruction carefully before operating the unit
and keep it for further reference.
■ All the examples and pictures used here are for reference only.
■ The contents of this manual are subject to change without
notice.
1

Warning and Caution

■ If the product does not work properly, please contact your dealer
or the nearest service center. Never attempt to disassemble the
camera yourself. (We shall not be responsible for any problems
caused by unauthorized repair or maintenance.)
■ In the use of the product, you must be strict compliance with the
electrical safety regulations of the nation and region. When the
product is mounted on wall or ceiling, the device shall be firmly
fixed.
■ Do not allow water or liquid intrusion into the camera.
■
Do not use camera beyond specified voltage range.
■ Do not drop the camera or subject it to physical shock.
■ Avoid touching the camera lens.
■ If cleaning is necessary, please use clean cloth to wipe it gently.
■ Do not aim the camera at the sun or extra bright place.
■ Do not place the camera in extremely hot, cold (the operating
temperature shall be -30˚C~60˚C), dusty or damp locations, and do
not expose it to high electromagnetic radiation.
■ To avoid heat accumulation, good ventilation is required for
operating environment.
2

Package

4 tapping screws PA 4×25
Camera Quick start guide
1 machine screw PWM3×5
CD Drill template
3

Overview

7
6
8
Ethernet connector 6
1
2 Audio input connector 7
Audio output connector 8
3
4 Alarm input/output
9
10
5 Power connector
DC12V
* 1 It is recommended to install the security cap for outdoor installation.
* 2 If the PoE switch is used to power the camera, DC12V power supply is not
required.

► Connecting Alarm Input/Output

Alarm Input:
IPC
× 4
Plastic plug
Alarm Output:
IPC
1
2

► Connecting Network Cable

3
4
5
9
10
1
Speaker
① Loosen the nut from the main element.
Mounting base ② Run the network cable (without RJ 45 connector) through the
Fixed ring both elements. Then crimp the cable with RJ 45 connector.
③ Connect the cable to the hermetic connector. Then tighten the
Micro SD card slot
nut and the main cover.
Reset
4

Installation

Please make sure that the wall or ceiling is strong enough to
withstand 3 times the weight of the camera. Please install the camera
1--ALARM-COM
under dry environment.
2--ALARM_OPEN
3--ALARM_INA
4--ALARM_GND
①
Open the cover of the camera and then insert a micro SD card.
Then install the cover back to the camera and fix it firmly with the
screws. (Note that the cover should not be installed unevenly.)
ALARM-INA 3
Sensor
4
ALARM-GND
+
ALARM-COM 1
Alarm
-
2
ALARM-OPEN
Power
+ -
2 3
