Summary of Contents for TVT Digital TD-5422E1
- Page 1 Thermal Network Camera User Manual Please read this instruction carefully before operating the unit and keep it for further reference...
- Page 2 Notes on Safety This product is intended to be supplied by a Listed Power Unit, marked with 'Limited Power Source', 'LPS' on unit, output rated minimum 12V/2 A or POE 48V/ 350mA or AC24V (depending on models), no more than 2000m altitude of operation and Tma=60 Deg.C.
- Page 3 Disclaimer With regard to the product with internet access, the use of product shall be wholly at your own risks. Our company shall be irresponsible for abnormal operation, privacy leakage or other damages resulting from cyber attack, hacker attack, virus inspection, or other internet security risks;...
- Page 4 Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
- Page 5 2012/19/EU (WEEE directive): The Directive on waste electrical and electronic equipment (WEEE Directive). To improve the environmental management of WEEE, the improvement of collection, treatment and recycling of electronics at the end of their life is essential. Therefore, the product marked with this symbol must be disposed of in a responsible manner.
-
Page 6: Table Of Contents
Table of Contents Introduction ........................1 Network Connection ...................... 2 LAN ........................2 2.1.1 Access through IP-Tool ................2 2.1.2 Directly Access through IE ............... 4 WAN ........................5 Live View ........................9 Fire Detection & Temp Measurement ................ 11 Fire Detection .................... - Page 7 Network Camera User Manual 5.5.2 Port ......................46 5.5.3 Server Configuration ................47 5.5.4 Onivf ....................... 47 5.5.5 DDNS ..................... 48 5.5.6 SNMP ..................... 49 5.5.7 802.1x ..................... 50 5.5.8 RTSP ....................... 51 5.5.9 UPNP ...................... 52 5.5.10 Email ...................... 52 5.5.11 FTP ......................
-
Page 8: Introduction
Network Camera User Manual 1 Introduction Main Features Thermal: Resolution: 256× 192 / 384× 288 Temperature range: -20°C~150°C Multi-palette: white hot, black hot, iron oxide red, etc. Sound and light warning, temperature exception alarm, fire detection Optical：... -
Page 9: Network Connection
Network Camera User Manual 2 Network Connection Available web browser: IE (plug-in required)/ Firefox/Edge/Safari/Google Chrome It is recommended to use the latest version of these web browsers. The menu display and operation of the camera may be slightly different by using the browser with plug-in or without plug-in. - Page 10 Network Camera User Manual ③ Double click the IP address and then the system will pop up the IE browser to connect IP-CAM. After you read the privacy statement, check and click “Already Read”. Then activate the device. Please self-define the password of admin according to the tip. If “Activate Onvif User”...
-
Page 11: Directly Access Through Ie
Network Camera User Manual If you forget the admin password, you can reset the password by clicking Forget Password on the login page. Then you can reset the password by the safety questions and answers you set. You can set the account safety question during the activation, or you can go to ConfigSecurityUser, click Safety Question, select the safety questions and input your answers. -
Page 12: Wan
Network Camera User Manual Select “Properties” and then select internet protocol according to the actual situation (for example: IPv4). Next, click the “Properties” button to set the network of the PC. ② Open the IE browser and enter the default address of IP-CAM and confirm. ③... - Page 13 Network Camera User Manual ① Make sure the camera is connected to the local network and then log in the camera via LAN and go to ConfigNetworkPort menu to set the port number. Port Setup ② Go to Config NetworkTCP/IP menu to modify the IP address. IP Setup ③...
- Page 14 Network Camera User Manual Router Setup ④ Open the IE browser and enter its WAN IP and http port to access. (for example, if the http port is changed to 81, please enter “192.198.1.201:81” in the address bar of web browser to access).
- Page 15 Network Camera User Manual Access through static IP Network connection The setup steps are as follow: ① Go to ConfigNetworkPort menu to set the port number. ② Go to Config NetworkTCP/IP menu to set the IP address. Check “Use the following IP address”...
-
Page 16: Live View
Network Camera User Manual 3 Live View After logging in, the following window will be shown. Plug-in free live view: when the main stream is set over 1080P, only the sub stream or third stream tab can be displayed on the above interface by default. The following table is the instructions of the icons on the live view interface. - Page 17 Network Camera User Manual *Those smart alarm indicators will flash only when the camera supports those functions and the corresponding events are enabled. *Plug-in free live view: Icon Description Icon Description Original size Auto (fill the window) Fit correct scale Full screen In full screen mode, double click on the mouse to exit or press the ESC key on the keyboard.
-
Page 18: Fire Detection & Temp Measurement
Network Camera User Manual 4 Fire Detection & Temp Measurement 4.1 Fire Detection Fire Detection: Alarms will be triggered when the camera detects the fire source. Click ConfigFire Detection to enter the following interface. 1. Click “Enable” and set the alarm holding time. 2. -
Page 19: Temperature Measurement
Network Camera User Manual sent into those addresses. Trigger FTP: If “Trigger FTP” and “Attach Picture” are checked, the captured pictures will be sent into FTP server address. Please refer to FTP configuration chapter for more details. 3. Click “Save” button to save the settings. 4. - Page 20 Network Camera User Manual Emissivity: Set the emissivity of the target. The emissivity of each object is different. Please refer to Common Material Emissivity for details. Distance: The distance between the target and the camera. Reflective: If there is any object with high emissivity in the scene, set the reflective temperature to correct the ambient temperature.
- Page 21 Network Camera User Manual Requirements of Fire detection and temperature measurement The thermal camera should be used in a stable indoor environment without wind. Please make sure the monitoring field is far away from any objects that could produce airflow. The lens of the camera shouldn’t face the sun to avoid the damage of the sensor.
-
Page 22: Other Configurations
Network Camera User Manual 5 Other Configurations In the Webcam client, choose “Config” to go to the configuration interface. Note: Wherever applicable, click the “Save” button to save the settings. 5.1 System Configuration 5.1.1 Basic Information In the “Basic Information” interface, the system information of the device is listed. 5.1.2 Date and Time Go to ConfigSystemDate and Time. -
Page 23: Local Config
Network Camera User Manual 5.1.3 Local Config Go to ConfigSystemLocal Config to set up the storage path of captured pictures and recorded videos on the local PC. There is also an option to enable or disable the bitrate display in the recorded files. Additionally, “Local smart snapshot storage”... - Page 24 Network Camera User Manual SD Card Management Click the “Format” button to format the SD card. All data will be cleared by clicking this button. Click the “Eject” button to stop writing data to SD card. Then the SD card can be ejected safely.
- Page 25 Network Camera User Manual Weekly schedule Set the alarm time from Monday to Sunday for a single week. Each day is divided in one hour increments. Green means scheduled. Blank means unscheduled. “Add”: Add the schedule for a special day. Drag the mouse to set the time on the timeline. “Erase”: Delete the schedule.
-
Page 26: Image Configuration
Network Camera User Manual Set the format, resolution and quality of the image saved on the SD card and the snapshot interval and quantity and the timing snapshot here. Snapshot Quantity: The number you set here is the maximum quantity of snapshots. The actual quantity of snapshots may be less than this number. - Page 27 Network Camera User Manual Brightness: Set the brightness level of the camera’s image. Contrast: Set the color difference between the brightest and darkest parts. Hue: Set the total color degree of the image. Saturation: Set the degree of color purity. The purer the color, the brighter the image is. WDR: WDR can adjust the camera to provide a better image when there are both very bright and very dark areas simultaneously in the field of the view by lowering the brightness of the bright area and increasing the brightness of the dark area.
- Page 28 Network Camera User Manual Off: disables the backlight compensation function. It is the default mode. HLC: lowers the brightness of the entire image by suppressing the brightness of the image’s bright area and reducing the size of the halo area. BLC: If enabled, the auto exposure will activate according to the scene so that the object ...
-
Page 29: Video / Audio Configuration
Network Camera User Manual Drag “ ” icons to set the time of day and night. Blue means day time and blank means night time. If the current mode of camera parameters is set to schedule, the image configuration mode will automatically switch between day and night according to the schedule. Thermal Parameter Settings: Click the “Thermal Parameters”... -
Page 30: Osd Configuration
Network Camera User Manual I Frame interval: It determines how many frames are allowed between a “group of pictures”. When a new scene begins in a video, until that scene ends, the entire group of frames (or pictures) can be considered as a group of pictures. If there is not much movement in the scene, setting the value higher than the frame rate is fine, potentially resulting in less bandwidth usage. -
Page 31: Video Mask
Network Camera User Manual Set time stamp, device name, OSD content and picture overlap here. After enabling the corresponding display and entering the content, drag them to change their position. Then click the “Save” button to save the settings. Picture Overlay Settings: Check “OSD Content1”, choose “Picture Overlay”... -
Page 32: Roi Configuration
Network Camera User Manual To set up video mask: 1. Enable video mask. 2. Click the “Draw Area” button and then drag the mouse to draw the video mask area. 3. Click the “Save” button to save the settings. 4. Return to the live to verify that the area have been drawn as shown as blocked out in the image. -
Page 33: Alarm Configuration
Network Camera User Manual 1. Check “Enable” and then click the “Draw Area” button. 2. Drag the mouse to set the ROI area. 3. Set the level. 4. Click the “Save” button to save the settings. 5.3 Alarm Configuration 5.3.1 Motion Detection Go to AlarmMotion Detection to set motion detection alarm. - Page 34 Network Camera User Manual 1. Check “Enable” check box to activate motion based alarms. If unchecked, the camera will not send out any signals to trigger motion-based recording to the NVR or CMS, even if there is motion in the video. Alarm Out: If selected, this would trigger an external relay output that is connected to the camera on detecting a motion based alarm (some models may support two alarm output interfaces.
-
Page 35: Other Alarms
Network Camera User Manual Move the “Sensitivity” scroll bar to set the sensitivity. Higher sensitivity value means that motion will be triggered more easily. Select “Add” and click “Draw”. Drag the mouse to draw the motion detection area; Select “Erase” and drag the mouse to clear motion detection area. After that, click the “Save”... - Page 36 Network Camera User Manual 2. Click “Enable” and set the alarm holding time. 3. Set alarm trigger options. Trigger alarm out, Email and FTP. The setup steps are the same as motion detection. Please refer to motion detection chapter for details. ...
-
Page 37: Alarm In
Network Camera User Manual 2. Click “Enable” and set the alarm holding time. 3. Trigger alarm out. When the camera is disconnected, the system will trigger the alarm out. 5.3.3 Alarm In To set sensor alarm (alarm in): Go to ConfigAlarmAlarm In interface as shown below. 1. -
Page 38: Alarm Out
Network Camera User Manual If there are two sensors, please select the sensor ID. Click “Apply settings to” to quickly apply the settings to the other alarm input. 5.3.4 Alarm Out This function is only available for some models. Go to ConfigAlarmAlarm Out. Alarm Out ID: Some models may support two alarm output interfaces. -
Page 39: Alarm Server
Network Camera User Manual Timing: Select the alarm type. Then click “Add” and drag the mouse on the timeline to set the schedule of alarm out; click “Erase” and drag the mouse on the timeline to erase the set time schedule. After this schedule is saved, the alarm out will be triggered in the specified time. -
Page 40: Light Alarm
Network Camera User Manual You can also record your own voice in the above interface and then upload. Insert the microphone into your PC. Click “Browse” to choose the save path of the audio you want to record. ... -
Page 41: Event Configuration
Network Camera User Manual 5.4 Event Configuration For more accuracy, here are some recommendations for installation. Cameras should be installed on stable surfaces, as vibrations can affect the accuracy of detection. Avoid pointing the camera at the reflective surfaces (like shiny floors, mirrors, glass, ... -
Page 42: Line Crossing
Network Camera User Manual Video Cast Detection: Alarms will be triggered if the video becomes obscured. 2. Set the alarm holding time and alarm trigger options. The setup steps are the same as motion detection. Please refer to motion detection chapter for details. 3. - Page 43 Network Camera User Manual 1. Enable line crossing detection and select the snapshot type and the detection target. Save Panoramic Picture to SD Card: If it is enabled, the detected panoramic pictures will be captured and saved to the SD card when the targets cross the alarm line. Save Target Cutout to SD Card: If it is enabled, the detected target cutout pictures will be captured and saved to the SD card when the targets cross the alarm line.
-
Page 44: Intrusion
Network Camera User Manual Set the alarm line number and direction. Up to 4 lines can be added. Multiple lines cannot be added simultaneously. Direction：A<->B, A->B and A<-B optional. This indicates the direction of someone or a vehicle crosses over the alarm line. A<->B: Alarms will be triggered when someone or a vehicle crosses over the alarm line from B to A or from A to B. - Page 45 Network Camera User Manual 1. Enable intrusion detection and select the snapshot type and the detection target. 2. Set the alarm holding time. 3. Set alarm trigger options. The setup steps are the same as fire detection. Please refer to Fire Detection chapter for details..
-
Page 46: Region Entrance
Network Camera User Manual 6. Set the schedule of the intrusion detection. The setup steps of the schedule are the same as schedule recording setup (See Schedule Recording). ※ Configuration requirements of camera and surrounding area 1. Auto-focusing function should not be enabled for intrusion detection. 2. - Page 47 Network Camera User Manual 2. Enable target counting and select the snapshot type and the detection target. Detection Target: Select the target to calculate. Human, motor vehicle and non-motor vehicle can be selected. Staying Threshold: When the targets (human/vehicle) staying in the specified area exceed the threshold, alarms will be triggered.
- Page 48 Network Camera User Manual Set the alarm line number and direction. Only one alarm line can be added. Direction：A->B and A<-B can be optional. The direction of the arrow is entrance. Statistics: If enabled, you can see the statistical information in the live view interface. If disabled, the statistical information will not be displayed in the live view interface.
-
Page 49: Face Detection
Network Camera User Manual the following interface. Select the report type. Daily report, weekly report, monthly report and annual report are selectable. Select the count type. Enter or leave can be optional. Select the start time and then click “Count”. Then the counting result will display in the statistic result area. - Page 50 Network Camera User Manual 2. Enable the face detection function. Save Source Information: if checked, the whole picture will be saved to the SD card when detecting a face. Save Face Information: if checked, the captured face picture will be saved to the SD card when detecting a face.
- Page 51 Network Camera User Manual Click “Draw Area” and drag the border lines of the rectangle to modify its size. Move the rectangle to change its position. Click “Stop Draw” to stop drawing the area. Click “Clear” to clear the area. Then set the detectable face size by defining the maximum value and the minimum value (The default size range of a single face image occupies from 3% to 50% of the entire image).
-
Page 52: Network Configuration
Network Camera User Manual 1. Cameras must be installed in the area with stable and adequate light sources. 2. The installation height ranges from 2.0m to 3.5m, adjustable according to the focal-length of different lenses and object distances. 3. The depression angle of the camera shall be less than or equal to 15° . 4. -
Page 53: Port
Network Camera User Manual PPPoE and then enter the user name and password from your ISP. Either method of network connection can be used. If PPPoE is used to connect internet, the camera will get a dynamic WAN IP address. This IP address will change frequently. To be notified, the IP change notification function can be used. -
Page 54: Server Configuration
Network Camera User Manual occupied. Data Port: The default data port is 9008. Please change it as necessary. RTSP Port: The default port is 554. Please change it as necessary. Persistent Connection Port: The port is used for a persistent connection of the third-party platform to push smart data, like face pictures. -
Page 55: Ddns
Network Camera User Manual Note: when adding the device to the third-party platform with ONVIF/RTSP protocol, please use the onvif user in the above interface. 5.5.5 DDNS If the camera is set up with a DHCP connection, DDNS should be set for the internet. 1. -
Page 56: Snmp
Network Camera User Manual Create domain name. After the domain name is successfully applied for, the domain name will be listed as below. 3. Enter the username, password, domain you apply for in the DDNS configuration interface. 4. Click the “Save” button to save the settings. 5.5.6 SNMP To get camera status, parameters and alarm information and remotely manage the camera, the SNMP function can be used. -
Page 57: 802.1X
Network Camera User Manual 2. Check the corresponding version checkbox (Enable SNMPv1, Enable SNMPv2, Enable SNMPv3) according to the version of the SNMP software that will be used. 3. Set the values for “Read SNMP Community”, “Write SNMP Community”, “Trap Address”, “Trap Port”... -
Page 58: Rtsp
Network Camera User Manual To use this function, the camera shall be connected to a switch supporting 802.1x protocol. The switch can be reckoned as an authentication system to identify the device in a local network. If the camera connected to the network interface of the switch has passed the authentication of the switch, it can be accessed via the local network. -
Page 59: Upnp
Network Camera User Manual “rtsp://IP address: rtsp port/profile2?transportmode=mcast”. Third stream: The address format is “rtsp://IP address: rtsp port/profile3?transportmode=mcast”. Thermal stream: The address format is “rtsp://IP address: rtsp port/profile4?transportmode=mcast”. Audio: Having entered the main/sub stream in a VLC player, the video and audio will play automatically. -
Page 60: Ftp
Network Camera User Manual Sender Address: sender’s e-mail address. User name and password: sender’s user name and password (you don’t have to enter the username and password if “Anonymous Login” is enabled). Server Address: The SMTP IP address or host name. Select the secure connection type at the “Secure Connection”... - Page 61 Network Camera User Manual 2. Click “Add” to add the information of the FTP. After that, click “Save” to save the settings. Server Name: The name of the FTP server. Server Address: The IP address or domain name of the FTP. Upload Path: The directory where files will be uploaded to.
- Page 62 Network Camera User Manual File Name Event Type IP address change MOTION Motion Detection SENSOR Sensor Alarm TRIPWIRE Line Crossing Detection PERIMETER Region Intrusion Detection Object Left/Missing Video Exception Crowd Density Detection Face Recognition VEHICE License Plate Recognition AOIENTRY Region Entering AOILEAVE Region Exiting Target Counting by Line...
-
Page 63: Https
Network Camera User Manual 5.5.12 HTTPS HTTPs provides authentication of the web site and protects user privacy. Go to Config NetworkHTTPS as shown below. There is a certificate installed by default as shown above. Enable this function and save it. Then the camera can be accessed by entering https://IP: https port via the web browser (eg. -
Page 64: Qos
Network Camera User Manual Click “Create” to create the certificate request. Then download the certificate request and submit it to the trusted certificate authority for signature. After receiving the signed certificate, import the certificate to the device. 5.5.13 QoS QoS (Quality of Service) function is used to provide different quality of services for different network applications. - Page 65 Network Camera User Manual 2. Enter user name in “User Name” textbox. 3. Enter the password in the “Password” and “Confirm Password” textbox. Please set the password according to the requirement of the password security level (Go to ConfigSecuritySecurity ManagementPassword Security interface to set the security level).
-
Page 66: Online User
Network Camera User Manual Admin can modify its password and change the user type and permission of other users here. Other users only can modify their password in this interface. Delete user: 1. Select the user to be deleted in the user configuration list box. 2. -
Page 67: Block And Allow Lists
Network Camera User Manual 5.6.3 Block and Allow Lists Go to ConfigSecurityBlock and Allow Lists as shown below. The setup steps are as follows: Check the “Enable address filtering” check box. Select “Block/Allow the following address”, IPv4/IPv6 and then enter IP address in the address box and click the “Add”... -
Page 68: Maintenance Configuration
Network Camera User Manual Please set the password level and expiration time as needed. Password Level: Weak, Medium or Strong. Weak level: Numbers, special characters, upper or lower case letters can be used. You can choose one of them or any combination of them when setting the password. Medium Level: 8~16 characters, including at least two of the following categories: numbers, special characters, upper case letters and lower case letters. -
Page 69: Reboot
Network Camera User Manual Import & Export Settings Configuration settings of the camera can be exported form a camera into another camera. 1. Click “Browse” to select the save path for import or export information on the PC. 2. Click the “Import Setting” or “Export Setting” button. Running Log Settings ... -
Page 70: Upgrade
Network Camera User Manual Click the “Reboot” button to reboot the device. Timed Reboot Setting: If necessary, the camera can be set up to reboot on a time interval. Enable “Time Settings”, set the date and time and then click the “Save” button to save the settings. 5.7.3 Upgrade Go to ConfigMaintenanceUpgrade. -
Page 71: Search
Network Camera User Manual 6 Search 6.1 Image Search Click Search to go to the interface as shown below. Images that are saved on the SD card or saved locally to the PC can be found here. Local Image Search Choose “Picture”—“Local”. - Page 72 Network Camera User Manual Click to return to the previous interface. Note: When using the plug-in free browser, the local images cannot be searched. SD Card Image Search Choose “Picture”—“SD Card”. Set time: Select date and choose the start and end time. Choose the alarm events at the bottom of the interface.
-
Page 73: Video Search
Network Camera User Manual Icon Description Icon Description Close: Select an image and Close all: Click this button click this button to close to close all images. the image. Save: Click this button to Save all: Click this button to select the path for saving select the path for saving all the image on the PC. -
Page 74: Sd Card Video Search
Network Camera User Manual Icon Description Icon Description Play button. After pausing video, Pause button click this button to continue playing. Stop button Speed down Speed up Watermark display Enable / disable audio; drag the slider to adjust the volume after enabling audio. Note: When using the plug-in free browser, the local videos cannot be searched. - Page 75 Network Camera User Manual Select the alarm events at the bottom of the interface. Select mix stream (video and audio stream) or video stream as needed. Double click on a file name in the list to start playback. Note: cannot be displayed when videos are played via the plug-in free browser.
- Page 76 Network Camera User Manual Click to download the video file in the PC. Click “Set up” to set the storage directory of the video files. Click “Open” to play the video. Click “Clear List” to clear the downloading list. Click “Close” to close the downloading window.
-
Page 77: Appendix
Network Camera User Manual Appendix Appendix 1 Troubleshooting How to find the password? A：A：Click “Forget Password” and then answer the security questions to reset the password. Fail to connect devices through IE browser. A: Network is not well connected. Check the connection and make sure it is connected well. B: IP address is not available. -
Page 78: Appendix 2 Common Material Emissivity
Network Camera User Manual No sound can be heard. A：Audio input device is not connected. Please connect and try again. B: Audio function is not enabled at the corresponding channel. Please enable this function. Appendix 2 Common Material Emissivity Material Emissivity Material Emissivity...
