Table of Contents

DAILY REFERENCE
GUIDE
THANK YOU FOR BUYING A ARISTON PRODUCT.
In order to receive a more complete assistance,
please register your appliance on:
www.arist onchannel.com
PRODUCT DESCRIPTION
APPLIANCE
6
8
9
10
12
Service:
0000 000 00000
13
CONTROL PANEL
1
1. On-O / Reset button with indicator light
2. Program selection button with indicator light
3.
Zone Wash 3D button with indicator light / Keylock
4. Eco program indicator light
5. Keylock indicator light
6. Display
7. Program number and remaining time indicator
Before using the appliance carefully read Safety Instructions.
2
3
Y ou can download the Safety Instructions and the User
Manual, by visiting our website www.aristonchannel.com
and following the Instructions on the back of this booklet.
1. Upper rack
1
2. Foldable aps
3. Upper rack height adjuster
2
4. Upper spray arm
5. Lower rack
6. Space Zone
3
7. Cutlery basket
4
8. Lower spray arm
9. Filter Assembly
5
10. Salt reservoir
7
11. Detergent and Rinse Aid dispensers
12. Rating plate
11
13. Control panel
5
6
8
9 10
4
7
11
8. Tablet (Tab) indicator light
9. Closed water tap indicator light
10. Rinse Aid re ll indicator light
11. Salt re ll indicator light
12. Short Time button with indicator light / Tablet (Tab)
13. Delay button with indicator light
14. Start/Pause button with indicator light / Drain out
LFC 3T132 W X 60HZ
12
13
14
EN
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LFC 3T132 W X and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ariston LFC 3T132 W X

Summary of Contents for Ariston LFC 3T132 W X

  • Page 1 DAILY REFERENCE GUIDE LFC 3T132 W X 60HZ THANK YOU FOR BUYING A ARISTON PRODUCT. Y ou can download the Safety Instructions and the User In order to receive a more complete assistance, Manual, by visiting our website www.aristonchannel.com please register your appliance on: and following the Instructions on the back of this booklet.
  • Page 2 FIRST TIME USE SALT, RINSE AID AND DETERGENT ADVICE REGARDING THE FIRST TIMEUSE FILLING THE RINSE AID DISPENSER After installation, remove the stoppers from the racks and the retaining Rinse aid makes dish DRYING easier. The rinse aid dispenser A should be lled when the RINSE AID REFILL indicator light in the control elastic elements from the upper rack.

  • Page 3: Programs Table

    PROGRAMS TABLE Duration Water Energy of wash Program Available options consumption consumption program (litres/cycle) (kWh/cycle) (h:min) 1. Eco 50° 3:10 0.85 2. Auto Intensive 65° 2:00 - 3:10 14.0 - 17.0 1.50 - 1.85 3. Auto Mixed 55° 1:30 - 2:30 14.5 - 16.0 1.15 - 1.30 4.
  • Page 4 OPTIONS AND FUNCTIONS OPTIONS can be selected directly by pressing the corresponding button (see C ONTR OL P ANE L). If an option is not compatible with the selected program see PROGRAMS TABLE, the corresponding LED ashes rapidly 3 times and beeps will sound.

  • Page 5: Loading The Racks

    LOADING THE RACKS UPPER RACK LOWER RACK Load delicate and light dishes: For pots, lids, plates, salad bowls, cutlery etc. Large plates and lids should glasses, cups, saucers, low salad ideally be placed at the sides to avoid interferences with the spray arm. bowls.

  • Page 6: Daily Use

    DAILY USE 1. CHECK WATER CONNECTION MODIFYING A RUNNING PROGRAM Check that the dishwasher is connected to the water supply If a wrong program was selected, it is possible to change it, provid- and that the tap is open. ed that it has only just begun: press and hold the ON/OFF button, 2.

  • Page 7: Care And Maintenance

    CARE AND MAINTENANCE CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS Regularly clean the lter assembly so that the lters do not clog and that On occasions, food residue may become encrusted onto the spray arms the waste water ows away correctly. and block the holes used to spray the water.

  • Page 8: Troubleshooting

    TROUBLESHOOTING In case your dishwasher doesn’t work properly, check if the problem can be solved by going through the following list. For other errors or issues please contact authorized After-sales Service which contact details can be found in the warranty booklet. The manufacturer ensures the availability of spare parts for at least 10 years after production date of this appliance.
