DAILY REFERENCE
GUIDE
THANK YOU FOR BUYING A ARISTON PRODUCT.
In order to receive a more complete assistance, please
register your appliance on: www.aristonbrand.com
Before using the appliance carefully read Health and Safety guide.
PRODUCT DESCRIPTION
APPLIANCE
7
8
9
11
Service:
0000 000 00000
12
CONTROL PANEL
1
1. On-Off/Reset button with indicator light
2. Program selection button with indicator light
3. Half Load button with indicator light
4. Salt refill indicator light
5. Rinse Aid refill indicator light
2
3
4
5
You can download the Safety Instructions and the Use
and Care Guide, by visiting our website
www.aristonbrand.com and following the Instructions
on the back of this booklet.
1
1.
Upper rack
2.
Foldable flaps
2
3.
Upper rack height adjuster
4.
Upper spray arm
5.
Lower rack
6.
Cutlery basket
3
7.
Lower spray arm
8.
Filter Assembly
4
9.
Salt reservoir
10. Detergent and Rinse Aid dispensers
5
11. Rating plate
6
12. Control panel
10
8
6
7
6. Program indicator lights
7. Delay indicator light
8. Delay button with indicator light
9. Tablet (Tab) button with indicator light
10. Start/Pause button with indicator light / Drain out
9
10
EN
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ariston LFC2C19
Summary of Contents for Ariston LFC2C19
- Page 1 DAILY REFERENCE GUIDE THANK YOU FOR BUYING A ARISTON PRODUCT. You can download the Safety Instructions and the Use In order to receive a more complete assistance, please and Care Guide, by visiting our website register your appliance on: www.aristonbrand.com www.aristonbrand.com and following the Instructions...
-
Page 2: First Time Use
FIRST TIME USE SALT, RINSE AID AND DETERGENT ADVICE REGARDING THE FIRST TIME USE FILLING THE RINSE AID DISPENSER After installation, remove the stoppers from the racks and the retaining Rinse aid makes dish DRYING easier. The rinse aid dispenser A should elastic elements from the upper rack. -
Page 3: Programs Table
PROGRAMS TABLE Detergent Duration of Water Energy dispenser Program Available options wash program consumption consumption (h:min) (litres/cycle) (kWh/cycle) 1. Eco 50° 2:40 0.86 2. Intensive 65° 2:30 16.5 1.65 3. Everyday 55° 2:00 1.35 4. Express 30’ 50° 0:30 0.50 5. - Page 4 OPTIONS AND FUNCTIONS OPTIONS can be selected directly by pressing the corresponding button (see CONTROL PANEL). If an option is not compatible with the selected program see PROGRAMS TABLE, the corresponding LED flashes rapidly 3 times and beeps will sound. The option will not be enabled. HALF LOAD TABLET (Tab) If there are not many dishes to be washed, a half load...
-
Page 5: Daily Use
DAILY USE MODIFYING A RUNNING PROGRAM 1. CHECK WATER CONNECTION Check that the dishwasher is connected to the water supply and If a wrong program was selected, it is possible to change it, provided that the top is open. that it has only just begun: press and hold the ON/OFF button, the 2. -
Page 6: Loading The Racks
LOADING THE RACKS UPPER RACK LOWER RACK For pots, lids, plates, salad bowls, cutlery etc. Large plates and lids should Load delicate and light dishes: glasses, cups, saucers, low salad bowls. ideally be placed at the sides to avoid interferences with the spray arm. The lower rack has tip-up supports which can be used in a vertical position when arranging plates or in a horizontal position (lower) to load pans and salad bowls easily. -
Page 7: Care And Maintenance
CARE AND MAINTENANCE CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS Regularly clean the filter assembly so that the filters do not clog and On occasions, food residue may become encrusted onto the spray arms that the waste water flows away correctly. and block the holes used to spray the water. -
Page 8: Troubleshooting
TROUBLESHOOTING Your dishwasher may not work properly. Before contacting the Service Centre check if the problem can be solved by going through the following list. PROBLEMS POSSIBLE CAUSES SOLUTIONS The dishwasher The appliance has not been plugged in Insert the plug into the socket. won’t start or does properly.
