- Page 1 Mosaic P 6C/E1, Mosaic M 6C/E1 User Guide www.rexton.com...
-
Page 2: Table Of Contents
Content Welcome Your hearing instruments Instrument type Getting to know your hearing instruments Components and names Controls Settings Batteries Battery size and handling tips Replacing batteries Recharging rechargeable batteries Daily use Turning on and off Inserting and removing the hearing instruments 17 Adjusting the volume Changing the hearing program Further adjustments (optional) Special listening situations Setting the focus (optional) On the phone Audio induction loops Audio input (FM system) ... - Page 3 Maintenance and care Hearing instruments Ear pieces and tubes Professional maintenance Further information Safety information Wireless functionality Accessories Symbols used in this document Troubleshooting Country-specific information Service and warranty ...
-
Page 4: Welcome
Welcome Thank you for choosing our hearing instruments to accompany you through everyday life. Like anything new, it may take you a little time to become familiar with them. This guide, along with support from your Hearing Care Professional, will help you understand the advantages and greater quality of life your hearing instruments offer. To receive the most benefit from your hearing instruments, it is recommended that you wear them every day, all day. This will help you get adjusted to them. CAUTION It is important to read this user guide and the safety manual thoroughly and completely. Follow the safety information to avoid damage or injury. This user guide is valid for: Mosaic P 80/60/40 6C, Mosaic P 30/20 E1, Mosaic M 80/60/40 6C, Mosaic M 30/20/10 E1, Mosaic M NR 80/60/40 6C... -
Page 5: Your Hearing Instruments
Your hearing instruments This user guide describes optional features that your hearing instruments may or may not have. Ask your Hearing Care Professional to indicate the features that are valid for your hearing instruments. Instrument type Your hearing instruments are BTE (Behind-The-Ear) models. A tube delivers the sound from the hearing instrument into the ear. The instruments are not intended for children under the age of 3 years or persons with a developmental age of under 3 years. Getting to know your hearing instruments It is recommended to familiarize yourself with your new hearing instruments. With the instruments in your hand try using the controls and note their location on the instrument. This will make it easier for you to feel and press the controls while wearing the hearing instruments. If you have problems pressing the controls of your hearing instruments while wearing them, you can ask your Hearing Care Professional whether a remote control or a smartphone app to control your instruments is available. -
Page 6: Components And Names
Components and names This user guide describes several types of hearing instruments. Use the following pictures to identify the type of hearing instrument that you use. Your hearing instruments are either attached to an earhook and a custom-made ear piece or to a standard tube (ThinTube) and a standard ear piece (Open Tip). Mosaic M 6C, Mosaic M NR 6C, Mosaic M 30/20 E1 ➐ ➊ ➎ Ear piece (Open Tip) Microphone openings ➋ ➏ Retention strand Rocker switch (control) (optional) ➐ Battery compartment ➌ Tube (ThinTube) (on/off switch) ➍ ➑ Earhook Charging contacts (optional) - Page 7 M osaic M 10 E1 ➊ ➎ Ear piece (Open Tip) Earhook ➋ ➏ Retention strand Microphone openings (optional) ➐ Rocker switch (control) ➌ Tube (ThinTube) ➑ Battery compartment ➍ Adapter for ThinTube (on/off switch)
- Page 8 Mosaic P ➎ ➎ ➎ ➌ ➌ ➊ ➎ Ear piece (Open Tip) Microphone openings ➋ ➏ Retention strand Rocker switch (control) (optional) ➐ Battery compartment ➌ Tube (ThinTube) (on/off switch) ➍ Earhook...
- Page 9 You can use standard ear pieces together with a standard tube or custom-made ear pieces together with an earhook and tube. You can easily exchange the standard ear pieces and clean the standard tube. Read more in section "Maintenance and care". Standard ear pieces / tubes Size Open Tip open or closed Open Tip semi-open Open Tip double ThinTube Custom-made ear pieces Examples:...
-
Page 10: Controls
Controls With the rocker switch you can, for example, adjust the volume or switch hearing programs. Your Hearing Care Professional has programmed your desired functions to the rocker switch. You can also use a remote control or a smartphone app to control your instruments. Rocker switch function Press briefly: Program up/down Volume up/down Tinnitus Function: volume up/down Sound balance Focus selection (microphone-pattern adjustment) Sound mixer (audio input) Press long: Standby/turn on Program up/down Press very long: Standby/turn on L = Left, R = Right... -
Page 11: Settings
Settings Hearing programs Read more in section "Changing the hearing program". Features Power-on delay enables whistle-free insertion of hearing instruments. Read more in section "Turning on and off". Autophone™ automatically switches to the telephone program when the telephone receiver approaches the ear. Read more in section "On the phone". XPhone transmits the telephone call into both ears when the telephone receiver is held to either ear. Read more in section "On the phone". The Tinnitus Function generates a sound to distract you from your tinnitus. - Page 12 To recharge batteries in hearing instruments with charging contacts, simply place the instruments in the charger. After charging, the charger dehumidifies the hearing instruments. The wireless functionality enables simultaneous control of both hearing instruments. Read more in section "Wireless functionality".
-
Page 13: Batteries
Batteries When the battery is low the sound becomes weaker or you will hear an alert signal. The battery type will determine how long you have to replace or recharge the battery. Battery size and handling tips Ask your Hearing Care Professional for recommended batteries. Battery size: ■ Always use the correct battery size for your hearing instruments. ■ Remove the batteries if you intend not to use the hearing instruments for several days. ■ Always carry spare batteries. ■ Remove empty batteries immediately and follow your local recycling rules for battery disposal. -
Page 14: Replacing Batteries
Replacing batteries Removing the battery: Open the battery compartment. Use the magnet stick to pull out the battery. The magnet stick is available as an accessory. Inserting the battery: If the battery has a protective film, remove it only when you are ready to use the battery. Insert the battery with the "+" symbol facing up (refer to the picture). Carefully close the battery compartment. If you feel resistance, the battery is not inserted correctly. Do not attempt to close the battery compartment by force. It can be damaged. -
Page 15: Recharging Rechargeable Batteries
Recharging rechargeable batteries Charge rechargeable batteries before first use. To charge the batteries, follow the instructions in the charger’s user guide. After many recharging cycles, the battery lifetime may reduce. In this case, replace the rechargeable battery with a new one. To do so, follow the instructions for replacing batteries. -
Page 16: Daily Use
Daily use Turning on and off You have the following options to turn your hearing instruments on or off. Via battery compartment: Turning on: Close the battery compartment. The default volume and hearing program are set. Turning off: Open the battery compartment to the first catch. Via rocker switch: Turning on or off: Press and hold the rocker switch for several seconds. Refer to section "Controls" for the settings of the rocker switch. After turning on, the previously used volume and hearing program remain set. When wearing the hearing instruments, an alert tone can indicate when an instrument is being turned on or off. When the power-on delay is activated, the hearing instruments turn on after a delay of several seconds. During this time you can insert the hearing instruments into your ears without experiencing unpleasant feedback ... -
Page 17: Inserting And Removing The Hearing Instruments
Inserting and removing the hearing instruments Your hearing instruments have been fine-tuned for your right and left ear. Colored markers indicate the side: ■ red marker = right ear ■ blue marker = left ear Mosaic P, Mosaic M 6C, Mosaic M 10 E1 Mosaic M NR 6C, Mosaic M 30/20 E1... - Page 18 Inserting a hearing instrument: Hold the tube close to the ear piece. Carefully push the ear piece ➊ into the ear canal Twist it slightly until it sits well. Open and close your mouth to avoid accumulation of air in the ear canal. Lift the hearing instrument and slide it over the top of ➋ your ear CAUTION Risk of injury! Insert the ear piece carefully and not too deeply into the ear. ■ It may be helpful to insert the right hearing instrument with the right hand and the left hearing instrument with the left hand. ■ If you have problems inserting the ear piece, use the other hand to gently pull your earlobe downwards. This opens the ear canal and eases insertion of the ear piece.
- Page 19 The optional retention strand helps to securely retain the ear piece in your ear. To position the retention strand: Bend the retention strand and position it carefully into the bottom of the bowl of your ear (refer to the picture).
- Page 20 Removing a hearing instrument: Lift the hearing instrument and slide it over the top of ➊ your ear Hold the tube close to the ear piece and pull the ➋ ear piece out carefully CAUTION Risk of injury! In very rare cases the ear piece could remain in your ear when removing the hearing instrument. If this happens, have the ear piece removed by a medical professional. Clean and dry your hearing instruments after usage. Read more in section "Maintenance and care".
-
Page 21: Adjusting The Volume
Adjusting the volume Your hearing instruments automatically adjust the volume to the listening situation. If you prefer manual volume adjustment, press the rocker switch. Refer to section "Controls" for the setting of the rocker switch. An optional signal tone can indicate the volume change. Once the maximum or minimum volume has been reached, you may hear an optional signal tone. -
Page 22: Changing The Hearing Program
Changing the hearing program Depending on the listening situation, your hearing instruments automatically adjust their sound. Your hearing instruments may also have several hearing programs which allow you to change the sound, if needed. An optional signal tone can indicate the program change. To change the hearing program, press the rocker switch. Refer to section "Controls" for the setting of the rocker switch. Refer to section "Settings" for a list of your hearing programs. If the Autophone or the XPhone function is activated, the hearing program switches automatically to a telephone program when the telephone receiver is close to the ear. Read more in section "On the phone". Further adjustments (optional) The controls of your hearing instruments can also be used to change, for example, the sound balance or the volume of the Tinnitus Function. Sound balance allows you to adjust the bass and treble to your preferences. Refer to section "Controls" for the setting of your controls. -
Page 23: Special Listening Situations
S pecial listening situations Setting the focus (optional) If you want to focus more directly on your conversation partner in front of you, or if you want to listen to the broader environment – the microphone-pattern adjustment gives you control over your listening preference. You can select different levels – from "focus to frontal position" (left picture) to "middle position" (center picture) to "hear all around" (right picture). Prerequisites: ■ You need to wear two hearing instruments. ■ On one of your hearing instruments the rocker switch needs to be set for the microphone-pattern adjustment by your Hearing Care Professional. Refer to section "Controls" for the setting of the rocker switch. With a suitable remote control and smartphone app you have even more control options. - Page 24 Setting the focus manually: If you have several hearing programs, change to hearing program 1. Press the rocker switch that is set for this function. The mid level is active by default. Press the upper rocker switch to focus more to the front, or the lower rocker switch to listen to the broader environment. Exiting microphone-pattern adjustment mode: Toggle to the minimum or maximum level. An optional signal tone can indicate the minimum and maximum level. Toggle one step further. The same signal tone as for changing the hearing program is played, indicating that you have exited the microphone-pattern adjustment mode.
-
Page 25: On The Phone
On the phone When you are on the phone, hold the telephone receiver slightly above your ear. The hearing instrument and telephone receiver have to be aligned. Turn the receiver slightly so that the ear is not completely covered. T elephone program You may prefer a certain volume when using the phone. Ask your Hearing Care Professional to configure a telephone program. Switch to the telephone program whenever you are on the phone or use the automatic program switch. If a telephone program or the automatic program switch are configured for your hearing instruments, it is listed in section "Settings". ... - Page 26 Automatic program switch (Autophone or XPhone) Your hearing instrument can automatically select the telephone program when you bring the telephone handset close to the hearing instrument. XPhone even transmits the call into both ears. When you are finished speaking on the phone, move the handset away from the hearing instrument and microphone mode will re-engage. If you want to use this function, ask your Hearing Care Professional to do the following: ■ Activate the Autophone or the XPhone function. ■ Check the telephone receiver’s magnetic field. For the automatic program switch, your hearing instrument detects the telephone receiver’s magnetic field. Not all telephones produce a magnetic field strong enough to activate this function. In this case, you can use the Autophone magnet, which is available as an accessory, and attach it to the telephone receiver. See the Autophone magnet user guide for instructions on how to position the magnet. NOTICE Use the approved Autophone magnet only. Ask your Hearing Care Professional for this accessory.
-
Page 27: Audio Induction Loops
Audio induction loops Some telephones and public places like theatres offer the audio signal (music and speech) via an audio induction loop. With this system, your hearing instruments can directly receive the desired signal – without distracting noise in the environment. You can usually recognize audio induction loop systems by certain signs. Ask your Hearing Care Professional to configure a telecoil program. Switch to the telecoil program whenever you are in a place with an audio induction loop. If a telecoil program is configured for your hearing instruments, it is listed in section "Settings". T elecoil program and remote control NOTICE For instruments with wireless connectivity: When the telecoil program is active, the remote control may cause a pulsing noise. Use the remote control with a distance greater than 10 cm (4 inches). -
Page 28: Audio Input (Fm System)
Audio input (FM system) With an audio input you can connect your hearing instruments to an FM system. An FM system consists of a transmitter and a receiver. It gathers speech at the voice source (via a separate microphone) and transmits the sound directly to the hearing instruments. The signal is clearer and unaffected by poor room acoustics. This can be useful for adults in difficult listening situations and for children in classrooms. Most FM systems allow for coupling with audio devices like an MP3 player. Notes: ■ The battery compartment with audio input is available as an accessory only for certain instrument types. As an alternative, you may use an audio streaming device (accessory) with a plug for FM receivers. Consult your Hearing Care Professional for further information. ■ Ask your Hearing Care Professional to configure your hearing instruments, for example: □ Adjust the mix of the audio input signal with surrounding sounds. □ Configure the controls so that you can select between audio input signal only, surrounding sound only, or a mix of both signals. - Page 29 WARNING Risk of electric shock! Connect audio input only to a device conforming to IEC 60065, the IEC-Norm for audio, video and other electronic devices.
-
Page 30: Maintenance And Care
Maintenance and care To prevent damage it is important that you take care of your hearing instruments and follow a few basic rules, which will soon become a part of your daily routine. Hearing instruments D rying and storage Dry your hearing instruments overnight. Ask your Hearing Care Professional for recommended drying products. For longer periods of non-use, store your hearing instruments with open battery compartment and batteries removed in a drying system to avoid the adverse effects of moisture. Cleaning Your hearing instruments have a protective coating. However, if not cleaned regularly you may damage the hearing instruments or cause personal injury. Clean your hearing instruments daily with a soft, dry tissue. Never use running water or immerse the devices in water. Never apply pressure while cleaning. -
Page 31: Ear Pieces And Tubes
Ask your Hearing Care Professional for recommended cleaning products, special care sets, or more information on how to keep your hearing instruments in good condition. Ear pieces and tubes Cerumen (ear wax) may accumulate on the ear pieces. This may affect sound quality. ■ For hearing instruments with a standard tube (ThinTube): Clean the ear pieces daily, clean the tubes as required. Exchange the ear pieces and tubes approximately every three to six months, or sooner if you notice cracks or other changes. ■ For hearing instruments with earhook: Clean the ear pieces daily. Ask your Hearing Care Professional to clean the tubes or to exchange the ear pieces and tubes as needed. - Page 32 C leaning ear pieces Clean the ear piece upon removal with a soft and dry tissue. This prevents cerumen becoming dry and hardening. Never use running water or immerse the ear piece in water. ...
- Page 33 Cleaning standard tubes Never use running water or immerse the tube in water. You can clean standard tubes (ThinTube) using a special cleaning wire. Ask your Hearing Care Professional for suitable cleaning wires. Remove tube and adapter by unscrewing the adapter from the hearing instrument. ➊ Carefully insert the cleaning wire into the adapter ➋ Push the cleaning wire all the way through the tube ➊ ➋ Wipe away any cerumen or debris that is dislodged. Completely remove the cleaning wire. Re-attach tube and adapter to the hearing instrument.
-
Page 34: Professional Maintenance
E xchanging standard ear pieces (Open Tip) Pull off the used ear piece and plug on the new ear piece. E xchanging standard tubes (ThinTube) Unscrew the used tube and screw the new tube on. Professional maintenance Your Hearing Care Professional can perform a thorough professional cleaning and maintenance. Custom-made ear pieces and wax filters should be exchanged as needed by your Hearing Care Professional. Ask your Hearing Care Professional for your individual recommendation of maintenance intervals and for support. -
Page 35: Further Information
Further information Safety information For more safety information, refer to the safety manual supplied with the device. Wireless functionality Your hearing instruments are equipped with wireless functionality. This provides synchronization between your two hearing instruments: ■ If you change the program or volume on one instrument, the other one is automatically changed, too. ■ Both hearing instruments automatically adapt to the listening situation simultaneously. Wireless functionality enables the use of a remote control. Accessories The type of available accessories depends on the instrument type. Examples are: a remote control, an audio streaming device, or a smartphone app for remote control. Some hearing instrument types support CROS and BiCROS solutions for people with single-sided deafness. Consult your Hearing Care Professional for further information. -
Page 36: Symbols Used In This Document
Symbols used in this document Points out a situation that could lead to serious, moderate, or minor injuries. Indicates possible property damage. Advice and tips on how to handle your device better. Troubleshooting Problem and possible solutions Sound is weak. ■ Increase the volume. ■ Replace or recharge the empty battery (depending on the battery type). ■ Clean or exchange the tube and the ear piece. Hearing instrument emits whistling sounds. ■ Reinsert the ear piece until it fits securely. ■ Decrease the volume. ■ Clean or exchange the ear piece. Sound is distorted. ■ Decrease the volume. ■ Replace or recharge the empty battery (depending on the battery type). ■ ... - Page 37 Problem and possible solutions Hearing instrument does not work. ■ Turn the hearing instrument on. ■ Gently close battery compartment completely. ■ Replace or recharge the empty battery (depending on the battery type). ■ Make sure the battery is inserted correctly. ■ Power-on delay is active. Wait several seconds and check again. Consult your Hearing Care Professional if you encounter further problems.
-
Page 38: Country-Specific Information
Country-specific information... -
Page 39: Service And Warranty
Service and warranty Serial numbers Left: Right: Service dates Warranty Date of purchase: Warranty period in months: Your Hearing Care Professional... - Page 40 Legal Manufacturer Sivantos GmbH Henri-Dunant-Strasse 100 91058 Erlangen Germany Phone +49 9131 308 0 Document No. 02994-99T03-7600 EN Order/Item No. 109 407 18 Master Rev04, 11.2017 © 12.2017, Sivantos GmbH. All rights reserved 0123 www.rexton.com...
