Summary of Contents for Hyundai power products HPACK420V
-
Page 2: Table Of Contents
CONTENTS SAFETY INSTRUCTIONS ........................3 CORDLESS DRILL ..........................9 CORDLESS JIG SAW ........................16 CORDLESS RECIPROCATING SAW ....................20 CORDLESS SANDER ........................24 DISPOSAL…………………………………………………………………………………………………………………………………..…26 WARRANTY ..........................27 PRODUCT FAILURE ........................28 WARRANTY EXCLUSIONS ......................29... -
Page 3: Safety Instructions
1. SAFETY INSTRUCTIONS GENERAL POWER TOOL SAFETY WARNINGS WARNING Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term "power tool"... - Page 4 4) Power tool use and care a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed. b) Do not use the power tool if the switch does not turn it on and off.
- Page 5 accessory may contact hidden wiring. Cutting accessory contacting a "live" wire may make exposed metal parts of the power tool "live" and could give the operator an electric shock. SAFETY INSTRUCTIONS WHEN USING LONG DRILL BITS a) Never operate at higher speed than the maximum speed rating of the drill bit. At higher speeds, the bit is likely to bend if allowed to rotate freely without contacting the workpiece, resulting in personal injury.
- Page 6 b) Always immobilize the workpiece with a clamping device. Never hold the piece to work by hand. c) Use the type of abrasive sheet suitable for the type of work to be performed. d) Never use oversized sanding tools. e) Never use damaged or worn abrasive sheets, or sheets that do not adhere firmly to the sanding pad. Never place your hand or fingers near the sanding pad while the sander is running.
- Page 7 SAFETY INSTRUCTIONS FOR BATTERIES AND CHARGER Batteries Never attempt to open for any reason. Do not store in locations where the temperature may exceed 40°C (104°F). Charge only at ambient temperatures between 4°C and 40°C(39.2°F and 104°F). ...
- Page 8 instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
-
Page 9: Cordless Drill
2. CORDLESS DRILL PRODUCT DESCRIPTION Keyless chuck LED work light Torque adjustment ring Battery pack release button Two speed selector Battery capacity indicator On/off switch trigger 10) Button for battery capacity indicator Battery pack 11) Belt clip Forward/reverse knob 12) Charger FEATURES 1) Li-ion battery (5) Advantages of Li-ion batteries:... - Page 10 20 V d.c. Chuck mm keyless Gear Train 2 Speed No Load Speed 0-400/0-1600 min Clutch 19+1 Positions HPACK420V Charger type Input 100-240V~ 50-60Hz, 0.4A Output 20V d.c., 0.5A HPACK420V Battery type 20V d.c. 1.5Ah(30Wh) Lithium-ion Charging time 3-4 hours Torque...
-
Page 11: Operation
LpA =75dB(A) Sound pressure level LpA Uncertainty: K=5 dB(A) LWA =86dB(A) Sound power level LwA Uncertainty: K=5 dB(A) (Vibration) <2.5m/s , K=1.5m/s Information The declared vibration total value has been measured in accordance with a standard test method and may be used for comparing one tool with another; ... - Page 12 Note: If the battery does not fit properly, disconnect it and confirm that the battery pack is the correct model for this charger as shown on the specification chart. Do not charge any other battery pack or any battery pack that does not securely fit the charger. NOTE: If battery is hot after continuous use in the tool, allow it to cool down to room temperature before charging.
- Page 13 10) Adjusting the torque The torque is adjusted by rotating the torque setting ring; the torque is greater when the torque setting is set on a higher position. The torque is less when the torque setting ring is set on a low position“1”denotes lowest and “19”...
-
Page 14: Cleaning And Maintenance
selector on the drill mode “ ”. Begin drilling at a very low speed to prevent the bit from slipping off the starting point. Maintain a speed and pressure which allows cutting without overheating the bit. Applying too much pressure will: ... -
Page 15: Declaration Of Conformity
32, rue Aristide Bergès - ZI 31270 Cugnaux - France, declares that， Product: Cordless Drill 20V Trade mark: Hyundai Model: HPACK420V Serial number: 20211162850-20211163849 is in conformity with the essential requirements and other relevant provisions of the applicable European Directives, based on the application of European harmonized standards. Any unauthorized modification of the apparatus voids this declaration. -
Page 16: Cordless Jig Saw
19 mm Sound power level LwA 92 dB(A) K= 5 dB(A) Cutting steel capacity 6 mm Vibration: ah,M=7.27m/s , K=1.5m/s HPACK420V Cutting wood capacity Battery pack Input 100-240V~ 50-60Hz, 0.4A Output 20V d.c., 0.5A HPACK420V Inclination degree Charger 20V d.c. 1.5Ah(30Wh) - Page 17 Information The declared vibration total value has been measured in accordance with a standard test method and may be used for comparing one tool with another; The declared vibration total value may also be used in a preliminary assessment of exposure. Warning ...
- Page 18 Make sure that the item is clamped tight, and that the saw line is clearly marked. Connect the vacuum extractor nozzle to an extractor system where possible. Start the saw. Place the soleplate on the item, and let the saw blade touch the saw line. ...
-
Page 19: Delaration Of Conformity
Product: Cordless Jigsaw 20V Trade mark: Hyundai Model: HPACK420V Serial number: 20211162850-20211163849 is in conformity with the essential requirements and other relevant provisions of the applicable European Directives, based on the application of European harmonized standards. Any unauthorized modification of the apparatus voids this declaration. -
Page 20: Cordless Reciprocating Saw
4) Lock-off button for ON/OFF switch TECHNICAL DATA Tension 20V d.c. No load speed 0-2800/min Cutting capacity 65mm in wood / 6mm in metal HPACK420V Charger type Input 100-240V~ 50-60Hz, 0.4A Output 20V d.c., 0.5A HPACK420V Battery type 20V d.c. 1.5Ah(30Wh) Lithium-ion Sound power level LwA: 92.93dB(A) K=5dB(A) - Page 21 that the vibration emission during actual use of the power tool can differ from the declared total value depending on the ways in which the tool is used; and of the need to identify safety measures to protect the operator that are based on an estimation of exposure in the actual conditions of use (taking account of all parts of the operating cycle such as the times when the tool is switched off and when it is running idle in addition to the trigger time).
- Page 22 3) Starting and stopping a) The reciprocating saw is equipped with a lock button (3) which reduces the possibility of accidental starting. The lock button (3) is located on the handle above the on/off switch trigger. You must depress the lock button in order to pull the switch trigger. The lock button resets each time the trigger is released.
-
Page 23: Maintenance And Storage
50◦c. Put it out of the reach of children. DECLARATION OF CONFORMITY BUILDER SAS 32, rue Aristide Bergès - ZI 31270 Cugnaux – France declare that the machine Designation: Cordless Reciprocating saw Model: HPACK420V Serial number: 20211162850-20211163849 Is in conformity with the European Directives: Machine Directive 2006/42/EC... -
Page 24: Cordless Sander
TECHNICAL DETAILS Power supply 20 V d.c. No Load Speed 12000 min Sanding plate dimensions 125 mm Charger type HPACK420V Input 100-240V~ 50-60Hz, 0.4A Output 20V d.c., 0.5A Battery type HPACK420V 20V d.c. 1.5Ah(30Wh) Lithium-ion Charging time 3-4 hour Acoustic pressure level LpA... -
Page 25: Maintenance
of the need to identify safety measures to protect the operator that are based on an estimation of exposure in the actual conditions of use (taking account of all parts of the operating cycle such as the times when the tool is switched off and when it is running idle in addition to the trigger time). ... -
Page 26: Disposal
32, rue Aristide Bergès - ZI 31270 Cugnaux - France, declares that， Product:CORDLESS ORBITAL SANDER 20V Trade mark: Hyundai Model: HPACK420V Serial number: 20211162850-20211163849 is in conformity with the essential requirements and other relevant provisions of the applicable European Directives, based on the application of European harmonized standards. Any unauthorized modification of the apparatus voids this declaration. -
Page 27: Warranty
7. WARRANTY The manufacturer guarantees the product against defects in material and workmanship for a period of 2 years from the date of the original purchase. The warranty only applies if the product is for household use. The warranty does not cover breakdowns due to normal wear and tear. The manufacturer agrees to replace parts identified as defective by the designated distributor. -
Page 28: Product Failure
8. PRODUCT FAILURE WHAT TO DO IF MY MACHINE BREAKS DOWN? If you bought your product in a store: • Make sure that your machine is complete with all accessories supplied, and clean! If this is not the case, the repairer will refuse the machine. •... -
Page 29: Warranty Exclusions
9. WARRANTY EXCLUSIONS THE WARRANTY DOES NOT COVER: • Start-up and setting up of the product. • Damage resulting from normal wear and tear of the product. • Damage resulting from improper use of the product. • Damage resulting from assembly or start-up not in accordance with the user manual. •...
