Panasonic Viera TH-37PH10 Operating Instructions Manual

High defi nition plasma display
Hide thumbs

Advertisement

Table of Contents

Operating Instructions

Manual de instrucciones
High Defi nition Plasma Display
2PS 9
TH-4
Pantalla de Plasma de Alta Defi nición
Model No.
TH-37PH10UK
Número de modelo.
TH-42PH10UK
TH-50PH10UK
TH-58PH10UK
TH-42PS 9
The illustration shown is an image.
Before connecting, operating or adjusting this product, please read these instructions completely.
Please keep this manual for future reference.
La ilustración mostrada es una imagen.
Antes de conectar, utilizar o ajustar este producto, lea completamente este manual de instrucciones;
y guárdelo para consultarlo en el futuro en caso de ser necesario.
English
Español
TQB2AA0802-1

Advertisement

Table of Contents
loading

  Also See for Panasonic Viera TH-37PH10

  Related Manuals for Panasonic Viera TH-37PH10

  Summary of Contents for Panasonic Viera TH-37PH10

  • Page 1: Operating Instructions

    Operating Instructions Manual de instrucciones High Defi nition Plasma Display 2PS 9 TH-4 Pantalla de Plasma de Alta Defi nición Model No. TH-37PH10UK Número de modelo. TH-42PH10UK TH-50PH10UK TH-58PH10UK TH-42PS 9 The illustration shown is an image. Before connecting, operating or adjusting this product, please read these instructions completely. Please keep this manual for future reference.
  • Page 2 CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: To reduce the risk of electric shock, do not remove cover or back. No user-serviceable parts inside. Refer servicing to qualifi ed service personnel. The lightning flash with The exclamation point within arrow-head within a triangle a t r i a n g l e i s i n t e n d e d t o is in tend ed to tell the user...
  • Page 3: Important Safety Instructions

    Important Safety Instructions 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with dry cloth. 7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifi...
  • Page 4: Table Of Contents

    Dear Panasonic Customer Welcome to the Panasonic family of customers. We hope that you will have many years of enjoyment from your new Plasma Display. To obtain maximum benefit from your set, please read these Instructions before making any adjustments, and retain them for future reference.
  • Page 5: Fcc Statement

    To assure continued compliance, use only shielded interface cables when connecting to computer or peripheral devices. Any changes or modifications not expressly approved by Panasonic Corporation of North America could cause harmful interference and would void the user’s authority to operate this device.
  • Page 6: Safety Precautions

    Safety Precautions CAUTION This Plasma Display is for use only with the following optional accessories. Use with any other type of optional accessories may cause instability which could result in the possibility of injury. (All of the following accessories are manufactured by Matsushita Electric Industrial Co., Ltd.) •...
  • Page 7: Maintenance

    Safety Precautions / Maintenance WARNING Securely insert the power cord plug as far as it will go. Setup • If the plug is not fully inserted, heat may be generated Do not place the Plasma Display on sloped or unstable which could cause fi...
  • Page 8: Accessories

    Accessories Accessories Supplied Check that you have the Accessories and items shown Operating Remote Control Batteries for the Instruction book Transmitter Remote Control EUR7636070R Transmitter (2 × AA Size) Fixing bands × 2 AC cord Remote Control Batteries Requires two AA batteries. 1.
  • Page 9: Connections

    Connections When connecting the speakers, be sure to use only the optional accessory speakers. Refer to the speaker’s Installation Manual for details on speaker installation. (Example: TH-42PH10UK) Speakers (Optional accessories) SPEAKERS Terminals (L) SPEAKERS AC cord connection (see page 13) Terminals (R) –...
  • Page 10: Pc Input Terminals Connection

    Connections PC Input Terminals connection (Example: TH-42PH10UK) COMPUTER AUDIO PC IN TH-42PS9 Conversion adapter (if necessary) Mini D-sub 15p PC cable Audio Stereo plug Connect a cable which matches the audio output terminal on the computer. Notes: • Due to space limitations, occasionally you may have trouble connecting Mini D-sub 15P cable with ferrite core to PC input Terminal.
  • Page 11: Serial Terminals Connection

    • SL1A, SL1B, SL2A and SL2B of Command IMS are FULL FULL available only when a dual input terminal board is JUST JUST attached. SELF Panasonic AUTO • With the power off, this display responds to PON ∗ SLOT3 cannot be selected on TH-37PH10UK. command only.
  • Page 12: Av & Component / Rgb Connection

    Connections AV & COMPONENT / RGB connection This unit has terminal boards equivalent to BNC Dual Video Terminal Board (TY-FB9BD) and BNC Component Video Terminal Board (TY-42TM6A) as standard equipment. COMPONEN T VIDEO OU T Example of input signal source Y , P RCA-BNC adapter...
  • Page 13: Power On / Off

    Power ON / OFF Connecting the AC cord plug to the Plasma Display. Fix the AC cord plug securely to the Plasma Display. (see page 9) Connecting the plug to the Wall Outlet Note: When disconnecting the AC cord, be absolutely sure to disconnect the AC cord plug at the socket outlet fi...
  • Page 14: Basic Controls

    Basic Controls Remote control sensor Volume Adjustment Volume Up “+” Down “–” W h e n t h e m e n u s c r e e n i s displayed: “+” : press to move the cursor up “–”...
  • Page 15 Basic Controls Standby (ON / OFF) button The Plasma Display must fi rst be plugged into the wall outlet and turned on at the power switch (see page 13). Press ON to turn the Plasma Display On, from Standby mode. Press OFF to turn the Plasma Display Off to Standby mode.
  • Page 16: On-Screen Menu Displays

    On-Screen Menu Displays The MENU button on the unit can also be Press to select . To PICTURE adjust menu pressed. (see page 23) PICTURE NORMALIZE NORMAL INPUT MENU ENTER/ PICTURE MENU STANDARD PICTURE Each time the MENU button is pressed, the [ from the unit ] BRIGHTNESS menu screen will switch.
  • Page 17 AUTO COLOR SYSTEM VIDEO NR 3 : 2 PULLDOWN VIDEO NR 3 : 2 PULLDOWN VIDEO NR H-FREQ. 33.8 Panasonic AUTO (4 : 3) NORMAL H-FREQ. 33.8 V-FREQ. 60.0 VIDEO NR V-FREQ. 60.0 Note: “SIGNAL” setup menu displays a different setting condition for each input signal. (see page 18)
  • Page 18: Initial Selections

    Initial selections Selecting the input signal Select the input signals to be connected by installing the optional Terminal Boards. Press to select the input signal to be played back from the equipment which has been connected to the Plasma Display. Input signals will change as follows: •...
  • Page 19: Aspect Controls

    (see screen will return to a former adjustment. page 37). • Panasonic AUTO can not be selected while equivalent board of BNC For a 4:3 image Dual Video Terminal Board (TY-FB9BD) is installed. Note: Do not allow the picture to be displayed in NORMAL mode for an extended period, as this can cause a permanent...
  • Page 20: Adjusting Pos. /Size

    This picture position movement cannot be controlled by the H-POS POS. /SIZE function. H-SIZE • If adjusting the PICTURE V-POS / V-SIZE in Panasonic AUTO with FULL mode, V-POS the adjustment is not memorized. When exiting the mode, the screen will return V-SIZE CLOCK PHASE to a former adjustment.
  • Page 21: Multi Pip

    MULTI PIP Press repeatedly. Each time pressing this button main picture and sub picture will be displayed as follows below. [Picture and Picture] [Picture out Picture] [Picture in Picture] Main picture Sub picture Main picture Sub picture Main picture Sub picture Normal Viewing Press to swap main...
  • Page 22: Advanced Pip

    Advanced PIP Press to display the Setup menu. Press to select “OSD Language”. Press and hold until the Options menu is displayed. Press to select Advanced PIP. Options Weekly Command Timer Onscreen display Press to adjust the menu. Initial INPUT Initial VOL level Off : Sets normal two screen display mode Maximum VOL level...
  • Page 23: Picture Adjustments

    PICTURE Adjustments Press to display the PICTURE menu. Select to adjust each item. Press to select the menu to adjust. Select the desired level by looking at the picture behind the menu. Note: Menu that cannot be adjusted is grayout. Adjustable menu changes depending on signal, input and menu setting.
  • Page 24: Advanced Settings

    PICTURE Adjustments Notes: Item Effect Adjustments • “COLOR” and “TINT” settings cannot be adjusted for “RGB/PC” and “Digital” input PICTURE Adjusts the proper picture contrast. Less More signal. • You can change the level of each function Adjusts for easier viewing of dark (PICTURE, BRIGHTNESS, COLOR, TINT, BRIGHTNESS pictures such as night scenes and...
  • Page 25: Sound Adjustment

    SOUND Adjustment Press to display the SOUND menu. Select to adjust each item. Press to select the menu to adjust. Select the desired level by listening to the sound. BASS SOUND Emits the original sound. STANDARD Adjusts low pitch sounds NORMALIZE NORMAL AUDIO MENU...
  • Page 26: Digital Zoom

    Digital Zoom This displays an enlargement of the designated part of the displayed image. Display the operation guide. EXIT Press to access Digital Zoom. The operation guide will be displayed. During Digital Zoom, only the following buttons can be operated. [Remote control] [Unit] POSITION /...
  • Page 27: Present Time Setup / Set Up Timer

    PRESENT TIME SETUP / SET UP TIMER The timer can switch the Plasma Display ON or OFF. Before attempting Timer Set, confi rm the PRESENT TIME OF DAY and adjust if necessary. Then set POWER ON TIME / POWER OFF TIME. Press to display the SET UP menu.
  • Page 28: Set Up Timer

    PRESENT TIME SETUP / SET UP TIMER SET UP TIMER Display the SET UP TIMER SCREEN. Press to select SET UP TIMER POWER ON TIME / POWER OFF TIME. PRESENT TIME OF DAY 10:00 Press to set up POWER ON TIME / POWER OFF POWER ON FUNCTION TIME.
  • Page 29: Screensaver (For Preventing Image Retention)

    SCREENSAVER (For preventing image retention) Do not display a still picture, especially in NORMAL mode, for any length of time. If the display must remain on, a SCREENSAVER should be used. SET UP Press to display the SET UP menu. SCREENSAVER MULTI DISPLAY SETUP SET UP TIMER...
  • Page 30: Setup Of Screensaver Time

    SCREENSAVER (For preventing image retention) Setup of SCREENSAVER Time After selecting TIME OF DAY or INTERVAL, the relevant Time Setup will become available for selection and the Operating Time may be set. (Time cannot be set when “MODE” is “ON” or “OFF”.) SCREENSAVER SCREENSAVER SCREENSAVER...
  • Page 31: Side Bar Adjust

    SCREENSAVER (For preventing image retention ) SIDE BAR ADJUST side bars Do not display a picture in NORMAL mode for an extended period, as this can cause an image retention to remain on the side bars on either side of the display fi eld. To reduce the risk of such an image retention, change the NORMAL mode brightness of the side bars.
  • Page 32: Reduces Power Consumption

    Reduces power consumption • POWER SAVE: When this function is turned ON, luminous level of the Plasma Display is suppressed, so power consumption is reduced. • STANDBY SAVE: When this function is turned ON, power consumption of the microcomputer is reduced during power supply standby (see page 13-15), so standby power of the set is reduced.
  • Page 33: Set Up For Multi Display

    SET UP for MULTI DISPLAY By lining up Plasma Displays in groups, for example, as illustrated below, an enlarged picture may be displayed across all screens. For this mode of operation, each plasma display has to be set up with a Display number to determine its location. (Example) group of 4 (2 ×...
  • Page 34 SET UP for MULTI DISPLAY Press to select SEAM HIDES VIDEO. MULTI DISPLAY SETUP MULTI DISPLAY SETUP Press to select “OFF”, “ON”. HORIZONTAL SCALE × 2 × 2 VERTICAL SCALE SEAM HIDES VIDEO LOCATION POWER ON SCREEN DELAY Press to select LOCATION. MULTI DISPLAY SETUP MULTI DISPLAY SETUP HORIZONTAL SCALE...
  • Page 35: Seam Hides Video Setting

    SET UP for MULTI DISPLAY SEAM HIDES VIDEO Setting To show joints between displays. To hide joints between displays. Reference Suitable for moving image display. Suitable for still image display. Step 6, Page 34 ID Remote Control Function You can set the remote control ID when you want to use this remote control on one of several different displays. Switch on the right side.
  • Page 36: Set Up For Input Signals

    Press ACTION ( ) button Press to exit from adjust mode. [ VIDEO ] SIGNAL 3D Y/C FILTER (NTSC) COLOR SYSTEM AUTO 3 : 2 PULLDOWN Panasonic AUTO (4 : 3) NORMAL Note: VIDEO NR When ON, this setting only affects NTSC input signals.
  • Page 37: Color System / Panasonic Auto

    SECAM M.NTSC NTSC Panasonic AUTO Set to “NORMAL” to view 4:3 images in an unchanged format when Panasonic AUTO is (4 : 3 ) selected. If you would like to view 4:3 images in Just format, set to “JUST”. Note: Panasonic AUTO does not function when BNC Dual Video Terminal Board (TY-FB9BD) is used.
  • Page 38: Sync

    3D Y/C FILTER (NTSC) SYNC AUTO Press to adjust. COLOR SYSTEM AUTO 3 : 2 PULLDOWN 3 : 2 PULLDOWN VIDEO NR 100 Hz Panasonic AUTO (4 : 3) NORMAL REFRESH RATE VIDEO NR H-FREQ. 33.8 REFRESH RATE 100 Hz V-FREQ. 60.0...
  • Page 39: Options Adjustments

    Options Adjustments Press to display the Setup menu. Press to select “OSD Language”. Press and hold until the Options menu is displayed. Press to select your preferred menu. Press to adjust the menu. Options Weekly Command Timer Onscreen display O f f Initial INPUT Initial VOL level Maximum VOL level...
  • Page 40 Options Adjustments Options Weekly Command Timer Onscreen display Initial INPUT Initial VOL level Maximum VOL level INPUT lock Button lock Remocon User level Advanced PIP Item Effect Adjustments Press button to adjust the volume when the unit is turned on. Off: Sets normal volume.
  • Page 41 Options Adjustments Options Off-timer function Enable Initial Power Mode Normal ID select Remote ID Serial ID Display size Studio W/B Studio Gain Item Effect Adjustments Enable: Enables the “Off-timer function”. Off-timer Disable: Disables the “Off-timer function”. function Enable Disable Note: When “Disable”...
  • Page 42 Options Adjustments Options Slot power V. lnstallation Rotate Serial Slot Select Slot1 Item Effect Adjustments Auto Off: Power is not transmitted to the slot power. Auto: Power is transmitted to the slot power only when main power is on. Slot Power Power is transmitted to the slot power when main power is on or in the standby state.
  • Page 43: Weekly Command Timer

    Options Adjustments Weekly Command Timer You can set 7-day timer programming by setting time and command. Note: Before setting Weekly Command Timer, set PRESENT TIME SETUP. (see page 27) Press to select Function. Options Press to select “On”. Weekly Command Timer Onscreen display Note: Press ACTION ( ) button...
  • Page 44 Options Adjustments Press to select a command number. Press to show the previous / next command pages (1-8) of the selected program. Press to show the command setting screen. Weekly Command Timer Weekly Command Timer Program Program AVL:00 8:00 20:00 DAM:NORM 10:30 IMS:SL1...
  • Page 45: Shipping Condition

    Shipping condition This function allows you to reset the unit to the factory setting. Press to display the SET UP menu. Press to select “OSD LANGUAGE”. Press and hold till the SHIPPING menu is SET UP displayed. SIGNAL COMPONENT/RGB-IN SELECT INPUT LABEL POWER SAVE STANDBY SAVE...
  • Page 46: Troubleshooting

    Troubleshooting Before you call for service, determine the symptoms and make a few simple checks as shown below. Symptoms Checks Picture Sound Electrical Appliances Interference Noisy Sound Cars / Motorcycles Fluorescent light Volume Normal Picture No Sound (Check whether the mute function has been activated on the remote control.) Not plugged into AC outlet Not switched on No Picture...
  • Page 47: Video/Component/Rgb/Pc Input Signals

    VIDEO/COMPONENT/RGB/PC input signals VIDEO input Horizontal Vertical Signal name frequency(kHz) frequency(Hz) NTSC 15.73 59.94 15.63 50.00 PAL60 15.73 59.94 SECAM 15.63 50.00 Modifi ed NTSC 15.73 59.94 Applicable input signals for Component / Mini D-sub 15P (Component) / RGB / Mini D-sub 15P (RGB) (* Mark) Horizontal Vertical Dot clock...
  • Page 48: Command List Of Weekly Command Timer

    Audio Volume (60) DAM:FULL Aspect (FULL) DAM:JUST Aspect (JUST) DAM:NORM Aspect (NORMAL) DAM:SELF Aspect (Panasonic Auto) DAM:ZOOM Aspect (ZOOM) DWA:OFF Dual Picture mode (OFF) DWA:OVL1 Advanced PIP mode (1) (see page 22) DWA:OVL2 Advanced PIP mode (2) (see page 22)
  • Page 49: Specifi Cations

    Specifi cations TH-37PH10UK TH-42PH10UK Power Source 120 V AC, 50/60 Hz Power Consumption Power on 340 W 380 W Stand-by condition Save OFF 0.7 W, Save ON 0.5 W Save OFF 0.7 W, Save ON 0.5 W Power off condition 0.2 W 0.2 W Plasma Display panel...
  • Page 50 Specifi cations TH-50PH10UK TH-58PH10UK Power Source 120 V AC, 50/60 Hz Power Consumption Power on 505 W 660 W Stand-by condition Save OFF 0.6 W, Save ON 0.4 W Save OFF 0.6 W, Save ON 0.4 W Power off condition 0.1 W 0.1 W Plasma Display panel...
  • Page 51: Panasonic Plasma Screen Limited Warranty

    Limited Warranty Panasonic Broadcast & Television Systems Company or inadequate signal pickup, maladjustment of consumer Panasonic Puerto Rico, Inc. (collectively referred to as controls, improper operation, power line surge, improper “the Warrantor”) will repair this product and all included voltage supply, lighting damage, or service by anyone...
  • Page 52: Limited Warranty Statement

    Broadcast & Television Systems Division 5770 Ambler Drive, Mississauga, Ontario L4W 2T3 LIMITED WARRANTY STATEMENT Panasonic Canada Inc. (also known as PCI) warrants this product to be free of WARRANTY COVERAGE PERIOD EXCEPTIONS defects in material and workmanship under normal use during the applicable...
  • Page 53 Executive Offi ce : One Panasonic Way 4E-7, Secaucus, NJ 07094 (201) 348-7000 EASTERN ZONE : One Panasonic Way 4E-7 Secaucus, NJ 07094 (201) 348-7621 Mid-Atlantic/New England : One Panasonic Way 4E-7 Secaucus, NJ 07094 (201) 348-7621 Southeast Region : 1225 Northbrook Parkway, Ste 1-160 Suwanee GA 30024 (770)338-6835 Central Region : 1707 N Randall Road E1-C-1, Elgin, IL 60123 (847)468-5200 WESTERN ZONE : 3330 Cahuenga Blvd W., Los Angeles, CA 90068 (323) 436-3500...
