Panasonic TH-42PH10UKA Service Manual

Please file and use this manual together with the service manual for Model No.
TH-42PH10UK, ORDER NO. MTNC070412CE.

Specifications

Power Source
Power Consumption
Power on
Stand-by condition
Power off condition
Plasma Display panel
Contrast Ratio
Screen size
(No. of pixels)
Operating condition
Temperature
Humidity
Applicable signals
Scanning format
PC signals
Connection terminals
HDMI A-B
COMPONENT / RGB IN
PC IN
110 - 127 V AC, 50 / 60 Hz
380 W
Save OFF 0.7 W, Save ON 0.5 W
0.2 W
Drive method: AC type 42-inch,
16:9 aspect ratio
Max 10000:1
36.3" (922 mm) (W) × 20.4" (518 mm) (H) × 42" (1,057 mm) (diagonal)
786,432 (1,024 (W) × 768 (H))
[3,072 × 768 dots]
32 °F - 104 °F (0 °C - 40 °C)
20 % - 80 %
525 (480) / 60i 60p, 625 (575) / 50i
30p 24sF .... SMPTE274M, 1250 (1080) / 50i
VGA, SVGA, XGA,
SXGA, UXGA ..... (compressed)
Horizontal scanning frequency 15 - 110 kHz
Vertical scanning frequency 48 - 120 Hz
TYPE A Connector × 2
Y / G (BNC)
P /B (BNC), P /R (BNC)
B R
AUDIO IN (RCA PIN JACK × 2)
(HIGH-DENSITY Mini-D-SUB 15PIN)
High Definition Plasma Display
TH-42PH10UKA
GPH10D Chassis
50p, 750 (720) / 60p 50p, 1125 (1080) / 60i
with / sync 1.0 Vp-p (75-ohm)
0.7 Vp-p (75-ohm)
0.5 Vrms (high impedance)
Y or G with / sync 1.0 Vp-p (75-ohm)
Y or G without / sync 0.7 Vp-p (75-ohm)
B / P / C :0.7 Vp-p (75-ohm)
B B
R / P / C :0.7 Vp-p (75-ohm)
R R
© 2007 Matsushita Electric Industrial Co., Ltd. All
rights reserved.
distribution is a violation of law.
ORDER NO.MTNC070932AE
50i 24p 25p
Unauthorized copying and
Ver.1
