Setup Procedure
1. Open enclosure
2. Connect your Switch inputs
3. Activate sensor (from Standby)
4. Learn sensor to RIoT-Hub
5. Learn sensor to your smartphone/device
6. Deploy
Connect No-Volt switches to the Screw Terminal
Switch I/P1
Switch I/P2
Switch I/P3
Switch I/P4
Inputs are No-Volt switches
Transmitter will remain in a "Deep Sleep" mode. When any of the No-Volt inputs
change state, (Closes or Opens) Transmitter will wake-up and Transmit an RF sig-
nal. The LED Flashes to indicates RF Transmission.
RIoT 4 x Switch RF Transmitter
DS-SENW-SWT-a
Quickstart Guide
Supply Selector
Optional
External
Supply I/P
5-15Vdc
Jumper Link
2 x AAA
Batteries
