Open Enclosure
Connect Your Switch Inputs
Switch I/P1
Switch I/P2
Switch I/P3
Switch I/P4
Note: Switch inputs are no-volt inputs
Operation
BOGEYBOX will remain in a "Deep Sleep"
mode at all times when no inputs are
active. When any of the No-Volt inputs
change state, (Closes or Opens)
BOGEYBOX will wake up and Transmit an
RF signal. The LED Flashes to indicates
RF Transmission.
BOGEYBOX Remote Transmitter
QS-BOGEYBOX-2
Quick Start Guide
RF
Ack
LED
RF T x
LED
