Jacking and Lifting

Jacking Procedure
Follow the steps below to lift Model X. Ensure that any non-Tesla repair facility is aware of these lifting points.
1. Position Model X centrally between the lift posts.
2. If your Model X is equipped with air suspension, it automatically self-levels, even when the vehicle is "asleep" and
the touchscreen is powered off (see
follows:
◦ Touch Controls > Suspension.
◦ Press the brake pedal, then touch Very High to maximize the height of the suspension.
◦ Touch Controls > Service > Jack Mode to disable self-leveling.
3. Close the falcon wing doors.
4. Position the lift arm pads under the designated body lift points at the locations shown.
WARNING: DO NOT position the lift arm pads under the Battery or side rails.
5. Adjust the height and position of the lift arm pads to ensure that they are correctly located.
6. With assistance, raise the lift to the desired height, ensuring the lift arm pads remain in their correct positions.
7. Engage any lift safety locks. Follow the lift manufacturer's instructions. To disengage Jack Mode, disable it in
Controls > Service.
NOTE: Jack mode may be unexpectedly enabled in situations where an object is supporting the vehicle's weight (for
example the bumper of the vehicle is resting on a curb).
WARNING: The air suspension system automatically self-levels, even when the vehicle is "asleep" and the
touchscreen is powered off. You MUST disable this system by engaging Jack mode before lifting or jacking. If
you do not disable the air suspension, Model X can attempt to self-level, causing serious damage, bodily injury,
or death.
WARNING: Never raise Model X when the charge cable is connected, even if charging is not in progress.
WARNING: Do not work on an incorrectly supported vehicle. Doing so can cause serious damage, bodily injury,
or death.
269
Jack Mode on page 270). Use the touchscreen to set the suspension as
