WSFM E31
WSFM E32
Fixed Speaker Wall Mount
For SONOS ® Era 300 ™
INSTRUCTION MANUAL
US: +1 (800) 359-5520 • EMEA: +31 (0) 495 580 852 • UK: +44 (0) 800 056 2853
Texto en español, página 16
Texte français page 18
We'll Make It Stress-Free
If you have any questions along the way, just give us a call.
We're ready to help!
Deutscher Text Seiten 20
Nederlandse tekst op pagina 22
中文文字说明请参见第 28 页
Svensk text sida 24
Русский текст: стр. 26
日本語は 30 ページ

Advertisement

loading
Need help?

Need help?

Do you have a question about the SANUS WSFME31 and is the answer not in the manual?

Questions and answers

Summary of Contents for LEGRAND SANUS WSFME31

  • Page 1 WSFM E31 WSFM E32 Fixed Speaker Wall Mount For SONOS ® Era 300 ™ INSTRUCTION MANUAL We’ll Make It Stress-Free If you have any questions along the way, just give us a call. US: +1 (800) 359-5520 • EMEA: +31 (0) 495 580 852 • UK: +44 (0) 800 056 2853 We’re ready to help! 中文文字说明请参见第...
  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS — PLEASE READ ENTIRE MANUAL PRIOR TO USE — SAVE THESE INSTRUCTIONS Before getting started, let’s make sure this product is perfect for you! This mount is designed to support only Sonos® Era 300™ speakers. CAUTION: Avoid potential personal injuries and property damage! ●...
  • Page 3 Supplied Parts and Hardware WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged parts! NOTE: Not all hardware included will be used.
  • Page 4: Attach Wall Plate To Wall

    STEP 1-A Attach Wall Plate to Wall Drywall Only Installation CAUTION: Avoid potential personal injury or property damage! ● Drywall covering the wall must not be less than 1/2 in. (12.7 mm) 1 in. (2.5 cm) Min. 1/2 in. (12.7 mm) 3/8 in.
  • Page 5 CAUTION: Avoid potential personal injury or property damage! DO NOT use power tools for this step. Both screws MUST BE firmly tightened to prevent unwanted movement of the wall plate . Ensure the wall plate is securely fastened to the wall before continuing on to the next step, but DO NOT overtighten the screws. Go to STEP 2, on PAGE 10...
  • Page 6: Wood Stud Installation

    STEP 1-B Attach Wall Plate to Wall Wood Stud Installation CAUTION: Avoid potential personal injury or property damage! ● Drywall covering the wall must not exceed 5/8 in. (16 mm) ● Minimum wood stud size: nominal 2 x 4 in. (51 x 102 mm) actual 1½ x 3½ in. (38 x 89 mm) ●...
  • Page 7 CAUTION: Avoid potential personal injury or property damage! DO NOT use power tools for this step. Both screws MUST BE firmly tightened to prevent unwanted movement of the wall plate . Ensure the wall plate is securely fastened to the wall before continuing on to the next step, but DO NOT overtighten the screws. Go to STEP 2, on PAGE 10...
  • Page 8 Solid Concrete or STEP 1-C Attach Wall Plate to Wall Concrete Block Installation CAUTION: Avoid potential personal injury or property damage! ● Mount the wall plate directly onto the concrete surface (no wall covering) ● Minimum solid concrete thickness: 8 in. (203 mm) ●...
  • Page 9 CAUTION: Avoid potential personal injury or property damage! DO NOT use power tools for this step. Both screws MUST BE firmly tightened to prevent unwanted movement of the wall plate . Ensure the wall plate is securely fastened to the wall before continuing on to the next step, but DO NOT overtighten the screws.
  • Page 10 STEP 2 Attach Bracket to Wall Plate...
  • Page 12 STEP 3 Attach Your Speaker...
  • Page 14 To Remove...
  • Page 15 Dimensions WALL PLATE TOP VIEW WALL IS ON TOP 0.20in 1.26in 5.2mm 32mm 4.91in 124.8mm 1.58in 40.1mm 2.36in 3.06in 60.1mm 77.7mm 1/4 - 20 TAP HOLE 0.20in 5.2mm FRONT VIEW SIDE VIEW 1.97in 50mm 1.92in 3.83in 48.7mm 97.3mm 0.26in 6.5mm 2.84in 72mm 4.57in...
  • Page 16 Nor does it provide for every possible contingency in connection with the installation or use of this product. The information contained in this document is subject to change without notice or obligation of any kind. Legrand AV makes no representation of warranty, expressed or implied, regarding the information contained herein.
