Page 1
COMPACT DISC STEREO RADIO CASSETTE RECORDER RADIOCASETE ESTÉREO CON REPRODUCTOR DE DISCOS COMPACTOS RADIO-CASSETTE LECTEUR DE CD STEREO CSD-EL300 8A-CH2-903-01 000205ACK-I-FM OPERATING INSTRUCTIONS MANUAL DE INSTRUCCIONES MODE D’EMPLOI (English) (Español) (Français)
Page 2
For your convenience, record the model number and serial number (you will find them on the rear of your set) in the space provided below. Please refer to them when you contact your Aiwa dealer in case of difficulty. Model No.
TABLE OF CONTENTS PREPARATIONS POWER SUPPLY ... 4 REMOTE CONTROL ... 4 BEFORE OPERATION ... 5 SETTING THE CLOCK ... 5 SOUND ADJUSTING THE SOUND ... 6 TAPE PLAYBACK TAPE OPERATIONS ... 7 RADIO RECEPTION MANUAL TUNING ... 8 PRESETTING STATIONS ... 9 CD PLAYING CD OPERATIONS ...
PREPARATIONS POWER SUPPLY USING ON AC HOUSE CURRENT Connect the AC cord as illustrated below. 1 to the AC inlet of the unit AC cord (supplied) The OPE/BATT indicator lights up while the power is on. CAUTION Use only the supplied AC cord. Use with other cords may result in the risk of fire.
BEFORE OPERATION To turn the unit on Press one of the function buttons (TAPE/REV MODE, TUNER/BAND, CD). Playback of the inserted disc or tape begins, or the previously tuned station is received (Direct Play Function). The POWER button is also available. Pressing the z CD OPEN button turns the unit on as well.
SOUND ADJUSTING THE SOUND VOLUME CONTROL Turn the VOLUME/TIMER control on the main unit or press the VOLUME buttons on the remote control. The volume level is displayed as a number from 0 to MAX (31). The volume level is automatically set to 21 if the power is turned off when the volume level is set to 22 or more.
TAPE PLAYBACK TAPE OPERATIONS INSERTING A TAPE Use Type I (normal) tapes only. Press the TAPE/REV MODE button (or the TAPE button on the remote control) and press the OPEN mark to open the cassette holder. Insert a tape with the exposed side facing forward. Push the cassette holder to close.
RADIO RECEPTION MANUAL TUNING Press the TUNER/BAND button repeatedly to select the desired band. If the power is turned off, the previously tuned station will be played (Direct Play Function). Press the f or g button to select a station. Each time the button is pressed, the frequency changes.
PRESETTING STATIONS You can preset up to 15 stations in each band. When a station is stored, a preset number is assigned to the station. Use the preset number to tune in to a preset station directly. Press the TUNER/BAND button to select a band. Then, press the f or g button to select a station.
CD PLAYING CD OPERATIONS LOADING A DISC Press the CD button, press the CD OPEN button to open the disc compartment, and load a disc with a label side up. Then press the CD OPEN button again to close the disc compartment.
RANDOM PLAY All the tracks on the disc can be played randomly. In stop mode, press the MODE button on the remote control repeatedly until RANDOM lights up on the display. Press the c (d) button to start play. To cancel the random play Press the MODE button twice in stop mode.
RECORDING RECORDING This section explains how to record from the radio or CD player. Preparation • Set the tape to the point where recording will start. • Use Type I (normal) tapes only. Insert the tape to be recorded. Insert the tape with the side to be recorded on facing up and the exposed side facing forward.
TIMER TIMER PLAY/TIMER RECORDING The unit can be turned on at a specified time every day with the built-in timer. Preparation Make sure the clock is set correctly. Press the TIMER button once for timer play so that 5 flashes. Press the TIMER button twice for timer recording so that 5 and REC flash.
GENERAL CARE AND MAINTENANCE Occasional care and maintenance of the unit and the software are needed to optimize the performance of your unit. To clean the cabinet Use a soft and dry cloth. If the surfaces are extremely dirty, use a soft cloth lightly moistened with mild detergent solution.
SPECIFICATIONS FM tuner section Tuning range 87.5 MHz to 108 MHz Antenna Rod antenna AM tuner section Tuning range 530 kHz to 1710 kHz (10 kHz step) 531 kHz to 1602 kHz (9 kHz step) Antenna Ferrite bar antenna Cassette deck section Track format 4 tracks, 2 channels stereo Frequency response...
Page 16
(los encontrará en la parte posterior del aparato) en el espacio que se suministra en la caja de abajo. Cítelos siempre que se ponga en contacto con su proveedor de productos Aiwa en caso de cualquier dificultad. Nº Modelo Nº...
Page 17
ÍNDICE PREPARACIONES ALIMENTACIÓN ... 4 MANDO A DISTANCIA ... 4 ANTES DE LA OPERACIÓN ... 5 AJUSTE DEL RELOJ ... 5 SONIDO AJUSTE DEL SONIDO ... 6 REPRODUCCIÓN DE CINTAS OPERACIONES CON LAS CINTAS ... 7 RECEPCIÓN DE LA RADIO SINTONIZACIÓN MANUAL ...
PREPARACIONES ALIMENTACIÓN USO CON ALIMENTACIÓN DE UNA TOMA ELÉCTRICA EN EL PROPIO HOGAR Conecte el cable de alimentación de CA como puede apreciar en la siguiente ilustración. 1 a la entrada CA de la unidad Cable de CA (se suministra con el aparato) El indicador OPE/BATT se enciende cuando el aparato está...
ANTES DE LA OPERACIÓN Cómo encender la unidad Pulse uno de los botones (TAPE/REV MODE, TUNER/ BAND, CD). Comenzará la reproducción del disco o de la cinta que se haya cargado o de la cinta, o se escuchará la emisora previamente sintonizada (Función de Reproducción Directa).
SONIDO AJUSTE DEL SONIDO CONTROL DEL VOLUMEN Gire el control VOLUME/TIMER que verá en la unidad principal o pulse los botones VOLUME del mando a distancia. El nivel de volumen se indica en la pantalla en forma numérica desde 0 hasta MAX (31). Cuando se apaga el aparato el nivel del volumen se ajusta automáticamente en 21 si se ajustó...
REPRODUCCIÓN DE CINTAS OPERACIONES CON LAS CINTAS CÓMO INSERTAR UNA CINTA Use únicamente cintas del Tipo I (normales). Oprima el botón TAPE/REV MODE (o el botón TAPE del mando a distancia) y presione sobre la marca OPEN para abrir el portacasete. Inserte una cinta con la cada expuesta mirando hacia arriba.
RECEPCIÓN DE LA RADIO SINTONIZACIÓN MANUAL Pulse repetidamente el botón TUNER/BAND para seleccionar la banda deseada. Si se apaga el aparato, se escuchará la emisora previamente sintonizada (Función de Reproducción Directa). Pulse el botón f o g para seleccionar una emisora.
PRESINTONIZACIÓN DE EMISORAS Puede presintonizar hasta 15 emisoras en cada banda. Cuando se guarda una emisora, se le asigna un número de presintonía a esa emisora. Use el número de presintonía para sintonizar directamente una presintonía. Oprima el botón TUNER/BAND para seleccionar una banda.
REPRODUCCIÓN DE DISCOS COMPACTOS OPERACIONES CON LOS DISCOS COMPACTOS CÓMO CARGAR UN DISCO Pulse el botón CD, pulse el botón CD OPEN para abrir el compartimento del disco y cargue un disco con el lado de la etiqueta mirando hacia arriba. Seguidamente, pulse el botón CD OPEN otra vez para cerrar el compartimento del disco.
Page 25
REPRODUCCIÓN ALEATORIA Todas las pistas del disco pueden ser reproducidas aleatoriamente. En la modalidad de parada, pulse repetidamente el botón MODE del mando a distancia hasta que se ilumine RANDOM en la pantalla. Pulse el botón c (d) para iniciar la reproducción.
GRABACIÓN GRABACIÓN Esta sección le explica cómo grabar desde la radio o el reproductor de discos compactos. Preparación • Ponga la cinta en el punto en el cual comenzará la grabación. • Use únicamente cintas del Tipo I (normales). Cargue la cinta en la que desea grabar. Cargue la cinta con la cara a grabar mirando hacia arriba y la cara expuesta mirando hacia abajo.
TEMPORIZADOR REPRODUCCIÓN/GRABACIÓN CON EL TEMPORIZADOR El aparato puede encenderse a una hora predeterminada cada día gracias al temporizador que lleva incorporado. Preparación Asegúrese de que el reloj está configurado correctamente. Pulse el botón TIMER una vez para ajustar la reproducción del temporizador, acción que hará...
GENERAL CUIDADOS Y MANTENIMIENTO Se necesita un cuidado y mantenimiento ocasionales del aparato y del software para aprovechar al máximo su rendimiento. Cómo limpiar el cabinete Use un paño seco y suave. Si las superficies están extremadamente sucias, utilice un paño blando humedecido ligeramente con una solución de detergente suave.
ESPECIFICACIONES Sección del sintonizador de FM Gama de sintonización 87,5 a 108 MHz Antena Antena de varilla Sección del sintonizador de AM Gama de sintonización 530 kHz a 1710 kHz (incrementos de 10 kHz) 531 kHz a 1602 kHz (incrementos de 9 kHz) Antena Antena de barra de ferrita Sección de la platina...
Page 30
Pour votre facilité, consignez la désignation du modèle et le numéro de série de cet appareil (qui se trouvent à l’arrière) dans les cases ci-dessous. Signalez ces numéros de référence lorsque vous prenez contact avec votre revendeur Aiwa en cas de problème. Désignation du modèle N° de série (N° lot)
Page 31
TABLE DES MATIÈRES PRÉPARATIFS ALIMENTATION FOURNIE ... 4 TÉLÉCOMMANDE ... 4 AVANT LA MISE EN SERVICE ... 5 RÉGLAGE DE L'HORLOGE ... 5 RÉGLAGE DU SON ... 6 LECTURE DE CASSETTE OPÉRATIONS DE BASE ... 7 RÉCEPTION RADIO ACCORD MANUEL ... 8 PRÉRÉGLAGE DE STATIONS ...
PRÉPARATIFS ALIMENTATION FOURNIE UTILISATION SUR COURANT SECTEUR Raccordez le cordon secteur comme indiqué sur 1 À la prise secteur de l'appareil Cordon secteur (fourni) L’indicateur OPE/BATT s’allume lorsque l’appareil est sous tension. PRÉCAUTION Utilisez uniquement le cordon secteur fourni. L'utilisation d'autres cordons peut provoquer un risque d'incendie.
AVANT LA MISE EN SERVICE Pour mettre sous tension Appuyez sur l'une des touches de fonction (TAPE/REV MODE, TUNER/BAND, CD). La lecture du disque inséré ou la cassette commence, ou la station précédemment accordée est reçue (fonction de lecture directe). La touche POWER est également validée.
RÉGLAGE DU SON COMMANDE VOLUME Tournez la commande VOLUME/TIMER sur l'unité principale ou appuyez sur les touches VOLUME sur la télécommande. Le niveau du volume s’affiche sous forme de chiffre de 0 à Max (31). Le volume se règle automatiquement au niveau 21 si l’on met l’appareil hors tension alors que le volume réglé...
LECTURE DE CASSETTE OPÉRATIONS DE BASE INSERTION D'UNE CASSETTE Utilisez seulement des cassettes de Type I (normal). Appuyer sur la touche TAPE/REV MODE (ou sur la touche TAPE de la télécommande) et appuyer sur la marque OPEN pour ouvrir le porte-cassette. Insérez une cassette avec le côté...
RÉCEPTION RADIO ACCORD MANUEL Appuyez plusieurs fois sur la touche TUNER/ BAND pour sélectionner la bande souhaitée. Si l'appareil est hors tension, c'est la station antérieurement captée qui s'écoutera (fonction de lecture directe). Appuyez sur la touche f ou g pour sélectionner une station.
PRÉRÉGLAGE DE STATIONS Vous pouvez prérégler jusqu'à 15 stations dans chaque bande. Chaque station mémorisée est dotée d'un numéro de préréglage. Utilisez ce numéro pour accorder directement une station préréglée. Appuyer sur la touche TUNER/BAND pour sélectionner la gamme. Puis, appuyer sur la touche f ou g pour sélectionner la station.
LECTURE DE CD OPÉRATIONS DE BASE CHARGEMENT DE DISQUES Appuyez sur la touche CD, appuyez sur la touche CD OPEN pour ouvrir le logement à disque et chargez un disque avec l'étiquette dirigée vers le haut. Puis appuyez à nouveau sur la touche CD OPEN pour refermer le logement à...
Page 39
LECTURE ALÉATOIRE Toutes les pistes du disque peuvent être lues de manière aléatoire. En mode d’arrêt, appuyez plusieurs fois sur la touche MODE sur la télécommande jusqu'à ce que RANDOM s'allume dans l'afficheur. Appuyez sur la touche c (d) pour démarrer la lecture.
ENREGISTREMENT ENREGISTREMENT Cette section vous explique comment enregistrer depuis la radio ou le lecteur de CD. Préparatifs • Réglez la cassette à l'endroit où l'enregistrement démarrera. • Utilisez seulement des cassettes de Type I (normal). Insérez la cassette à enregistrer. Insérez la cassette avec la face à...
MINUTERIE LECTURE ET ENREGISTREMENT TEMPORISÉS L'appareil peut être mis sous tension à une heure spécifiée tous les jours avec la minuterie intégrée. Préparatifs Vérifiez que l'horloge est à l'heure. Appuyez une fois sur la touche TIMER pour la lecture temporisée afin que 5 clignote. Appuyez deux fois sur la touche TIMER pour l'enregistrement temporisé...
GÉNÉRALITÉS ENTRETIEN ET MAINTENANCE L'entretien et la maintenance périodiques de l'appareil et des disques sont requis pour optimiser les performances de l'appareil. Nettoyage du coffret Utilisez un chiffon doux et sec. Si les surfaces sont très sales, utilisez un chiffon doux légèrement humidifié...
SPÉCIFICATIONS Section tuner FM Plage d'accord 87,5 MHz à 108 MHz Antenne Antenne à tige Section tuner AM Plage d'accord 530 kHz à 1710 kHz (pas de 10 kHz) 531 kHz à 1602 kHz (pas de 9 kHz) Antenne Antenne à barre en oxyde de fer Section platine cassette Format des pistes 2 canaux stéréo, 4 pistes...
Page 44
PARTS INDEX / ÍNDICE DE LOS COMPONENTES / INDEX 1 QSURROUND ... 6 T-BASS ... 6 3-MODE EQ ... 6 2 POWER 6 STANDBY/ON ... 5, 8, 13, 14 3 w REC/REC MUTE ... 12 4 f/r, t/g TUNING -/+ ... 5, 7, 8, 9, 10, 12, 13 5 PHONES ...
