All manuals and user guides at all-guides.com CSD-ES977 HR(S) HA(S) SERVICE MANUAL BASIC TAPE MECHANISM : TN-51RV-240 COMPACT DISC STEREO RADIO BASIC CD MECHANISM : KSM-213 CDM CASSETTE RECORDER This Service Manual is the “Revision Publishing” and replaces “Simple Manual” (S/M Code No.09-995-331-6T1).
All manuals and user guides at all-guides.com SPECIFICATIONS HR MODEL HA MODEL • • Design and specifications are subject to change without Design and specifications are subject to change without notice notice ACCESSORIES/PACKAGE LIST REF. NO PART NO. KANRI DESCRIPTION 1 87-A80-119-010 AC CORD SET ASSY,AZ<HA>...
All manuals and user guides at all-guides.com PROTECTION OF EYES FROM LASER BEAM DURING SERVICING This set employs laser. Therefore, be sure to follow carefully the CAUTION instructions below when servicing. Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous WARNING! radiation exposure.
All manuals and user guides at all-guides.com ELECTRICAL MAIN PARTS LIST REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION 87-010-545-080 CAP, ELECT 0.22-50V 87-010-545-080 CAP, ELECT 0.22-50V 87-A20-955-010 IC,LA1828 87-018-208-080 CAP 0.047-50F 87-A20-946-040 C-IC,MM1434XF 87-018-208-080 CAP 0.047-50F 87-A20-591-010 IC,BA5417 87-010-248-080...
Page 5
All manuals and user guides at all-guides.com REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION C314 87-010-248-080 CAP, ELECT 220-10V PVC1 87-A91-167-010 TUN-CAP,20P-160P FA-22125 N000 C315 87-010-197-080 CAP, CHIP 0.01 DM <HASC> C321 87-010-190-080 S CHIP F 0.01 C322 87-010-263-080 CAP, ELECT 100-10V...
Page 6
All manuals and user guides at all-guides.com REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION CN402 8Z-CH4-614-010 CONN ASSY, 6P CD-ME S613 87-A90-696-080 SW,TACT TS2103-03-430 CN403 87-099-195-010 CONN,7P 6216 V X601 87-A70-070-080 VIB,CER 5.76MHZ CRHF L401 87-003-102-080 COIL, 10UH X602...
All manuals and user guides at all-guides.com TRANSISTOR ILLUSTRATION • Regarding connectors, they are not stocked as they are not the initial order items. The connectors are available after they are supplied from connector manufacturers upon the order is received. CHIP RESISTOR PART CODE 2SA933 2SA1296...
Page 8
All manuals and user guides at all-guides.com WIRING-1 (MAIN)
All manuals and user guides at all-guides.com PRACTICAL SERVICE FIGURE <TUNER SECTION> <DECK SECTION> <FM SECTION> Tape speed : 3000Hz +90 / -60Hz IHF Sensitivity : Less than 19dB Wow & flutter : Less than 0.4% (R.M.S) (THD 3%) [at 88.0MHz] Take-up torque : 30 ~ 60g-cm (FWD) Less than 18dB...
Page 17
All manuals and user guides at all-guides.com IC DESCRIPTION IC, LC78622ED Pin No. Pin Name Description DEFI Defect sense signal (DEF) input pin. (Connect to 0V when not used). Test signal input pin with built-in pull-down resistor. Be sure to connect to 0V. Phase comparator output pin to control external VCO.
Page 18
All manuals and user guides at all-guides.com Pin No. Pin Name Description XVDD — Crystal oscillator power supply pin. XOUT Pin to which external 16.9344 MHz crystal oscillator is connected. XVSS — Crystal oscillator GND pin. Be sure to connect to 0V. SBSY Subcode block sync signal output pin.
Page 19
All manuals and user guides at all-guides.com IC, LA9241ML Pin No. Pin Name Description Pin to which external pickup photo diode is connected. RF signal is created by adding FIN2 with the FIN1 pin signal. FE signal is created by subtracting from the FIN1 pin signal. FIN1 Pin to which external pickup photo diode is connected.
Page 20
All manuals and user guides at all-guides.com Pin No. Pin Name Description Pin from which TES signal is output to DSP. “High Frequency Level” is used to judge whether the main beam position is on top of bit or on top of mirror. SLOF Sled servo off control input pin.
Page 21
All manuals and user guides at all-guides.com IC, LC867132V Pin No. Pin Name Description O-RMC CD read/write control output. O-DATA Data output to sound processor IC (M62495FP). O-CLK(NC) Clock output to sound processor IC (M62495FP). (Not connected.) — Not Connected. O-CKSFT Clock shift output of the microcomputer.
Page 22
All manuals and user guides at all-guides.com Pin No. Pin Name Description O-CD LED LED ON/OFF control output for CD functions. O-TU LED LED ON/OFF control output for TU functions. O-TA LED (NC) LED ON/OFF control output for TAPE functions. (Not Connected) O-ROCK LED LED ON/OFF control output for ROCK.
All manuals and user guides at all-guides.com MECHANICAL EXPLODED VIEW 1/1 CAP, TWEETER CUSHION, CUSHION, LCD601 HLDR, TWEETER CUSHION, P.C.B P.C.B P.C.B P.C.B PWB, COVER TN-51RV-240 PLATE,LED CAP, TWEETER P.C.B HLDR, TWEETER CHAS,TUN...
Page 28
All manuals and user guides at all-guides.com TAPE MECHANISM EXPLODED VIEW 1/2 TAPE MECHANISM PARTS LIST 1/2 REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION 1 S1-851-023-190 REC BUTTON LEVER ASSY 41 S1-851-040-290 PINCH ROLLER SPRING (R) 2 S1-851-020-620 E-LOCK ARM SPRING 42 S1-800-110-230...
Page 29
All manuals and user guides at all-guides.com TAPE MECHANISM EXPLODED VIEW 2/2 TAPE MECHANISM PARTS LIST 2/2 REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION 1 S1-851-070-040 FF GEAR ARM SPR(F) 26 S1-800-100-220 ANTI-VIBRATION FELT 2 S1-851-070-050 FF GEAR ARM COLLAR 27 S1-851-140-150 MOTOR PULLEY...
All manuals and user guides at all-guides.com CD MECHANISM EXPLODED VIEW 1/1 COVER SPINDLE MOTOR (M1) (M2) MOTOR C.B CD MECHANISM PARTS LIST 1/1 REF. NO PART NO. KANRI DESCRIPTION 1 9X-262-620-210 MOTOR CHASSIS ASSY 2 92-626-907-010 GEAR(A) 3 87-A90-468-010 PICK UP KSS-213C 4 92-626-908-010 SHAFT SLED...
