INSTRUCTION VIDEO
M
CORMICK® DISPENSERS
C
User Manual
300400 - French's® Mustard Dispenser-US
300401 - French's® Ketchup Dispenser-US
300402 - Old Bay® Hot Sauce Dispenser-US
300406 - Frank's RedHot® Bu alo Wings Sauce Dispenser-US
300407 - Cattlemen's® Memphis Sweet BBQ Sauce Dispenser-US
300408 - French's® Mustard Dispenser-Canada (910012415)
300409 - French's® Ketchup Dispenser-Canada (910012404)
300410 - Frank's RedHot® Bu alo Wings Sauce Dispenser-Canada (910012405)
Advertisement
Related Manuals for ASEPT MCCORMICK 300400
Summary of Contents for ASEPT MCCORMICK 300400
- Page 1 INSTRUCTION VIDEO CORMICK® DISPENSERS User Manual 300400 - French’s® Mustard Dispenser-US 300401 - French’s® Ketchup Dispenser-US 300402 - Old Bay® Hot Sauce Dispenser-US 300406 - Frank’s RedHot® Bu alo Wings Sauce Dispenser-US 300407 - Cattlemen’s® Memphis Sweet BBQ Sauce Dispenser-US 300408 - French’s®...
- Page 2 UNI Dispensers Complete Pump 9851 Natural Dome 7299 Pump Housing 9720 Dome Clip 7868 Nozzle 8651 Valve 9683 Brush 7615 Designed for use with standard 1½ gallon pouched condiments and toppings. Pumps attach to 16mm tments in pouches.
-
Page 3: Pump Cleaning
Safety All components must be cleaned before rst use. According to food and safety regulations, most foods must be stored and/or served at certain temperatures or they could become hazardous. Check with local food and safety regulators for speci c guidelines. Be aware of the product you are serving and the temperature the product is required to maintain. - Page 4 Assembly Mount the nozzle onto the end of the pump housing. Bend the outer portion of the nozzle inside out. Insert into opening. Tab of nozzle faces towards housing. Flip the outer portion of the nozzle over the end of tube. Insert dome into the pump housing.
- Page 5 Insert valve into the bottom of the pump housing. Wrap the aps on the side of valve onto the pair of pegs on the pump housing. TIP: Lubricate parts with clean water to ease tting. Connect pump to pouch Put new pouch on countertop with tment facing up.
-
Page 6: Tips And Troubleshooting
Insert the lid Hold the lever up while inserting lid tabs into slots in back of dispenser shroud. Make sure lid SNAPS into place front and back. NOTE: To remove lid, hold by handle and lift lid straight up. Prime pump Press the pump lever several times until food is visible in discharge tube. - Page 7 Setting the Portion NOTE: Pump comes pre-set to dispense 1oz portion. Remove locking washer Use a athead screwdriver to pry o the locking washer from the pin at the end of the link arms. Keep locking washer for step 4. Remove pin Slide the pin out from the pair of link arms and handle holes.
- Page 8 ASEPT General Warranty Liability for defects The Supplier is liable only for defect Should the products, as delivered, which appear under the conditions within one (1) year from delivery of operation provided for in the be shown to be defective due to...
