- Page 1 MULTIDRESS 77000 DUAL KETCHUP/MUSTARD DISPENSER User Manual...
- Page 2 ASEPT Multidress 77000 The Multidress is used to dispense any combination of ketchup and mustard onto a bun, both at the same time or individually. You can set all combinations with a swift movement of your thumb during operation. To dress a bun, hold the Multidress with both hands above the center of the bun, choose the desired setting and squeeze.
- Page 3 Assembly IMPORTANT Clean, rinse, sanitize, and dry parts at a minimum of every 24 hours. Always comply with local sanitization requirements. Assemble the Product Control, Lid, and Portion Selector. Attach complete Lid Assembly to Container. Gently flex Lid edge if necessary.
- Page 4 Assembly (cont.) Place Assemble Funnel over the Small Spring. the piston. Rotate one half turn. Insert the "wings" into the grooves with the hopper towards the Lid. Insert Large Spring and Piston into funnel. Press Piston so that it slides into the Valve and locks.
- Page 5 Filling Place Multidress into Holder. Pour mustard into the sloped bottom of the funnel (NOT over the Piston) to avoid air bubbles forming. Fill the cylindrical part of the Funnel. Fill the ketchup container. Maximum level is 2.5 cm (1 inch) from the top.
- Page 6 SMALL SETTING LARGE SETTING Move Portion Control and Product Control to desired setting. Hold the Multidress with both hands, with cylinder centered about 4 cm (1½ inches) above 1/3 fl oz (10 ml) 1/2 fl oz (15 ml) the bun. Ketchup Ketchup 1.1 ml Mustard...
- Page 7 Disassembly (cont.) Remove Hold Funnel Assembly from the Funnel Assembly with opening Container. Flex sides of Container resting on bottom of sink. to remove. Remove Valve and Spring Support. Rotate Unscrew and pull Piston from the Funnel. and remove cylinder. Disassemble the two parts of the Piston by rotating one half turn.
- Page 8 Check with local food and safety regulators for specific guidelines. Be aware of the product you are serving and the temperature the product is required to maintain. ASEPT General Warranty Liability for defects Supplier’s liability does not cover defect...
