Summary of Contents for Kicker MWLE10
- Page 1 Owner’s Manual Manual del Propietario Manuel d’utilisatio Benutzerhandbuch select language MWLE10 Loaded Enclosure seleccione MWLE10 Caja de Subwoofer el idioma choisir la Caisson de Graves MWLE10 langue sprache MWLE10 Tieftönergehäuse auswählen...
- Page 2 Contents Overview ......3 Specifi cations ......4 Installation ......5 Wiring Confi guration ....5 Mounting ........8 Warranty ......10 Garantía | Garantie ....English 51MWLE-a...
- Page 3 VENTILATION. SUBWOOFERS SHOULD BE MOUNTED WITH AT LEAST 1 INCH (2.5CM) CLEARANCE BETWEEN THE FRONT OF THE SPEAKER AND ANY SURFACE. KICKER PRODUCTS ARE CAPABLE OF PRODUCING SOUND LEVELS THAT CAN PERMANENTLY DAMAGE YOUR HEARING! TURNING UP A SYSTEM TO A LEVEL THAT HAS AUDIBLE DISTORTION IS MORE DAMAGING TO YOUR EARS THAN LISTENING TO AN UNDISTORTED SYSTEM AT THE SAME VOLUME LEVEL.
- Page 4 Enclosure Width [in, cm] 25-9/16, 65 Note: All specifi cations and performance fi gures are subject to change. Please visit www.kicker. com for the most current information. To get the best performance from your new KICKER speakers, we recommend using genuine KICKER accessories and wiring.
- Page 5 1. Connect the MWLE plug to the MWLE enclosure Pro Tip: You’re a KICKER KXM amplifi er a few cables away from a full system upgrade that will dominate out on the water! Also, ask your KICKER Dealer about KICKER Premium Marine speaker & amplifi er upgrades! English...
- Page 6 1. Speaker + 2. Speaker - 3. White LED (negative) 4. Blue LED (negative) 5. Red LED (negative) 6. Green LED (negative) 7. Black LED (positive) 2. Connect the positive and negative wires to your amplifi er. 3. Connect the LED wires to your battery. Splice and combine the negative wires to yield a different color.
- Page 7 When wiring the LED lighting, the black lead is +12V and the blue, red, green and white leads are ground. 1. Connect the black LED wire to the positive terminal of the battery. a. Place a 2-amp fuse (not included) no further than 7”...
- Page 8 Mounting To avoid potential injury or possible death from forward movement of the enclosure during abrupt stops or accidents, the enclosure must be properly installed and securely fastened. You are solely responsible for securely fastening the enclosure. Make sure the mounting screws will not puncture the gas tank, wiring or interfere with any mechanical parts on the underside of the mounting surface.
- Page 9 Up-Firing Down-Firing English...
- Page 10 Should service be necessary under this warranty for any reason due to manufacturing defect or malfunction during the warranty period, KICKER will repair or replace (at its discretion) the defective merchandise with equivalent merchandise. Warranty replacements may have cosmetic scratches and blemishes.
- Page 11 Service performed by anyone other than KICKER HOW LONG WILL IT TAKE? KICKER strives to maintain a goal of one-week service for all acoustics (subwoofers, midrange drivers, tweeters, crossovers, etc) returns. Delays may be incurred if lack of replacement inventory or parts is encountered.
- Page 12 (“a todo volumen”) en todo sentido. La línea de altavoces y amplifi cadores KICKER es la mejor del mercado de audio de automóviles y por lo tanto representa el “combustible” para vivir a todo volumen en el área de “estéreos de automóvil” de la vida de nuestros clientes.
