Device description
3.3 LED status indicator
3.2

RTLS4030T EX2 order data

Table 3-1
SIMATIC RTLS4030T EX2
including 1 CR123A-type battery
Packaging unit: Pack of 1
3.3

LED status indicator

The operating states of the transponder are indicated by the internal LED. This can assume the
states from and briefly light up .
LED
14
RTLS4030T EX2 order data
Meaning
Red LED is off when the transponder is in operation
Red LED lights up once for 1.5 seconds at system startup
Flashes red (user LEDs flash) if you trigger flashing via the Locating Manager. You
can configure the duration and frequency of flashing via the Locating Manager.
National approvals
CE
Operating Instructions, 06/2024, C79000-G8976-C711-03
Article number
6GT2700-3DA03-0EX2
SIMATIC RTLS4030T EX2
