- Page 1 Introduction Safety information Device description SIMATIC RTLS Installation and operation Localization systems SIMATIC RTLS4030T EX2 Technical specifications Approvals Operating Instructions 06/2024 C79000-G8976-C711-03...
- Page 2 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
-
Page 3: Table Of Contents
RTLS4030T EX2 order data ....................14 LED status indicator ......................14 Dimension drawing......................15 Installation and operation ........................17 Notes on installation ......................17 Cleaning and maintenance....................19 Technical specifications ........................21 Approvals ............................. 23 SIMATIC RTLS4030T EX2 Operating Instructions, 06/2024, C79000-G8976-C711-03... - Page 4 Table of contents SIMATIC RTLS4030T EX2 Operating Instructions, 06/2024, C79000-G8976-C711-03...
-
Page 5: Introduction
These operating instructions apply to the following transponder: • RTLS4030T EX2 (CE; article number: 6GT2700-3DA03-0EX2) Manufacturer The "SIMATIC RTLS4030T EX2" (Type 17-2233-S110) product has been developed as a cooperative effort between SIEMENS AG and BARTEC GmbH. The manufacturer is: BARTEC GmbH Max-Eyth-Straße 16... - Page 6 Introduction Industry Online Support In addition to the product documentation, the comprehensive online information platform of Siemens Industry Online Support offers support at the following Internet address: (https:// support.industry.siemens.com/cs/start?lc=en-US) Apart from news, there you will also find: • Project information: Manuals, FAQs, downloads, application examples etc.
-
Page 7: Security Recommendations
In order to protect plants, systems, machines, and networks against cyber threats, it is necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial cybersecurity concept. Siemens’ products and solutions form one element of such a concept. Customers are responsible for preventing unauthorized access to their plants, systems, machines and networks. - Page 8 Do not dispose of the products at public disposal sites. For environmentally compliant recycling and disposal of your electronic waste, please contact a company certified for the disposal of electronic waste or your Siemens representative. Note the different national regulations.
-
Page 9: Safety Information
Use the transponder only for its intended use under permissible ambient conditions. WARNING Permissible ambient conditions • Approved for Zone 2 • Ambient temperature range -10 °C to +50 °C • Operating temperature range -10 °C to +50 °C • Storage and transport temperature -10 °C to +50 °C SIMATIC RTLS4030T EX2 Operating Instructions, 06/2024, C79000-G8976-C711-03... - Page 10 • For applications in hazardous areas, only a device and an electronics module with corresponding Ex approval is permitted to be used. Order replacement parts from your authorized representative. You will find the serial number on the nameplate of the device inside the enclosure. SIMATIC RTLS4030T EX2 Operating Instructions, 06/2024, C79000-G8976-C711-03...
- Page 11 • With battery-operated devices, it must be ensured that the battery capacity is greater than 50% to be able to successfully complete the update process. You are advised to use a new and full battery in the device for the update process. SIMATIC RTLS4030T EX2 Operating Instructions, 06/2024, C79000-G8976-C711-03...
- Page 12 Safety information SIMATIC RTLS4030T EX2 Operating Instructions, 06/2024, C79000-G8976-C711-03...
-
Page 13: Device Description
RTLS localization system. It sends data packets to gateways for position determination. This processed data is then transmitted to the Lo‐ cating Manager server. The SIMATIC RTLS4030T EX2 transponder is suit‐ able for use in hazardous areas. SIMATIC RTLS4030T EX2 Operating Instructions, 06/2024, C79000-G8976-C711-03... -
Page 14: Rtls4030T Ex2 Order Data
Table 3-1 RTLS4030T EX2 order data National approvals Article number SIMATIC RTLS4030T EX2 6GT2700-3DA03-0EX2 including 1 CR123A-type battery Packaging unit: Pack of 1 LED status indicator The operating states of the transponder are indicated by the internal LED. This can assume the states from and briefly light up . -
Page 15: Dimension Drawing
Device description 3.4 Dimension drawing Dimension drawing Figure 3-1 Dimension drawing SIMATIC RTLS4030T EX2 - All dimensions are specified in millimeters SIMATIC RTLS4030T EX2 Operating Instructions, 06/2024, C79000-G8976-C711-03... - Page 16 Device description 3.4 Dimension drawing SIMATIC RTLS4030T EX2 Operating Instructions, 06/2024, C79000-G8976-C711-03...
-
Page 17: Installation And Operation
• Use only approved battery types for operating the transponder. • Operate the transponder in hazardous areas only with the battery holders. • Improper handling of batteries can lead to fire and skin injuries. SIMATIC RTLS4030T EX2 Operating Instructions, 06/2024, C79000-G8976-C711-03... - Page 18 Insertion of non-approved or damaged batteries may result in damage to the transponder or its surroundings. Only use batteries approved by the manufacturer, see section "Technical specifications (Page 21)". Before inserting the batteries, make sure that they are not damaged. SIMATIC RTLS4030T EX2 Operating Instructions, 06/2024, C79000-G8976-C711-03...
-
Page 19: Cleaning And Maintenance
Use only a moist cloth to clean the transponder. The enclosure may only be opened to change batteries. Improper opening or repair of the transponder may result in serious risks for the user. SIMATIC RTLS4030T EX2 Operating Instructions, 06/2024, C79000-G8976-C711-03... - Page 20 Installation and operation 4.2 Cleaning and maintenance SIMATIC RTLS4030T EX2 Operating Instructions, 06/2024, C79000-G8976-C711-03...
-
Page 21: Technical Specifications
Supply voltage Supply voltage 1 x CR123A-type 3 V lithium battery Brand: VARTA (1550 mAh) or Panasonic (1400 mAh) Service life (at 20 ℃) Standby: 1 year operation: 100% UWB localization with 1 second: 6 months SIMATIC RTLS4030T EX2 Operating Instructions, 06/2024, C79000-G8976-C711-03... - Page 22 Design, dimensions, weights and connectors Dimensions (L x W x H) 80 x 75 x 55.5 mm Weight 271 g (including battery) 254 g (without battery) Degree of protection IP66 Fastening method Four 5 mm holes Enclosure Glass-fiber reinforced polyester (UP-GF) Color Gray SIMATIC RTLS4030T EX2 Operating Instructions, 06/2024, C79000-G8976-C711-03...
-
Page 23: Approvals
You can find the current EU Declaration of Conformity for these products on the Internet at Siemens Industry Online Support. Link: (https://support.industry.siemens.com/cs/products? dtp=Certificate&mfn=ps&pnid=14970&lc=en-US) - Page 24 Industrial, scientific and medical equipment - Radio-frequency disturbance characteristics – Limits and methods of measurement • EN 55032 Class A, Class B Electromagnetic compatibility of multimedia equipment – Emission requirements • EN 55035 Electromagnetic compatibility of multimedia equipment - Immunity requirements SIMATIC RTLS4030T EX2 Operating Instructions, 06/2024, C79000-G8976-C711-03...
- Page 25 • ETSI EN 302 065-2 Short Range Devices (SRD) using ultra-wideband technology (UWB); Harmonized standard covering the essential requirements of article 3.2 of the Directive 2014/53/EU; Part 2: Requirements for UWB location tracking SIMATIC RTLS4030T EX2 Operating Instructions, 06/2024, C79000-G8976-C711-03...
- Page 26 Approvals SIMATIC RTLS4030T EX2 Operating Instructions, 06/2024, C79000-G8976-C711-03...
