High-Performance 1/2" Drill/Driver
241-0380
OPERATOR'S MANUAL
CAUTION: To Reduce The Risk Of Injury, User Must
Read And Understand Operator's Manual. Save These
Instructions For Future Reference.
For questions / comments, technical assistance or repair parts –
Please Call Toll Free: 1-866-917-4374 (M-F 8:30am-5:00pm EST).

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FLEXPOWER 241-0380 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MasterForce FLEXPOWER 241-0380

Summary of Contents for MasterForce FLEXPOWER 241-0380

  • Page 1 High-Performance 1/2" Drill/Driver 241-0380 OPERATOR’S MANUAL CAUTION: To Reduce The Risk Of Injury, User Must Read And Understand Operator’s Manual. Save These Instructions For Future Reference. For questions / comments, technical assistance or repair parts – Please Call Toll Free: 1-866-917-4374 (M-F 8:30am-5:00pm EST).

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Safety Symbols ............Page 2 Safety Instructions .

  • Page 3: Safety Symbols

    SAFETY SYMBOLS Some of these following symbols may be used on this tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and more safely. Symbol Designation / Explanation Name Volts Voltage...

  • Page 4: Safety Instructions

    SAFETY INSTRUCTIONS The purpose of safety symbols is to attract your attention to possible dangers. The safety symbols and the explanations with them deserve your careful attention and understanding. The symbol warnings do not, by themselves, eliminate any danger. The instructions and warnings they give are no substitutes for proper accident prevention measures.

  • Page 5: General Power Tool Safety Warnings

    SAFETY INSTRUCTIONS GENERAL POWER TOOL will increase the risk of electric shock. 4. Do not abuse the cord. Never use the SAFETY WARNINGS cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, WARNING: Read all safety sharp edges or moving parts.
  • Page 6 SAFETY INSTRUCTIONS Dress properly. Do not wear loose Keep cutting tools sharp and clean. clothing or jewelery. Keep your hair and Properly maintained cutting tools with sharp clothing away from moving parts. Loose cutting edges are less likely to bind and are clothes, jewelery or long hair can be caught easier to control.

  • Page 7: Important Safety Instructions

    SERVICE To reduce the risk of electric shock or damage to the chargers and batteries, only with MASTERFORCE ® Have your power tool serviced by a FLEXPOWER battery packs and chargers ® qualified repair person using only identical listed.
  • Page 8 SAFETY INSTRUCTIONS of work. To reduce your exposure to these WARNING: Some dust created by chemicals: power sanding, sawing, grinding, drilling, • Work in a well-ventilated area. and other construction activities contains • Work with approved safety equipment, chemicals known to the state of California such as dust masks that are specially to cause cancer, birth defects, or other designed to filter out microscopic particles.

  • Page 9: Assembly

    SPECIFICATIONS Rated Voltage 20 V d.c. Chuck 1/2" No-load Speed 0-420/0-1850 RPM Max. Torque 535 in lb Clutch 23+1 Position Weight (without battery) 1 lb. 3 oz. (1.2 kg) ASSEMBLY UNPACKING WARNING: If any part is broken or missing, DO NOT attempt to attach the 1.

  • Page 10: Operation

    OPERATION TO ATTACH BATTERY PACK 3. Pull forward on the battery pack to remove it from the drill/driver. (FIG. 2) TRIGGER SWITCH (FIG. 3) FIG. 2 FIG. 3 ATTACH DETACH Variable Direction- Speed of-Rotation Trigger Selector CAUTION: Switch Avoid the possibility of accidental starting.

  • Page 11: Electric Brake

    OPERATION ELECTRIC BRAKE The direction of rotation of the bit is reversible and is controlled with a selector located above the trigger switch. With the To stop the tool, release the trigger switch drill/driver held in normal operating position: and allow the chuck to come to a complete Position the direction-of-rotation selector to stop.
  • Page 12 OPERATION KEYLESS CHUCK (FIG. 7) TWO-SPEED GEAR BOX (FIG. 9) Release FIG. 7 FIG. 9 Low speed Slide Switch Keyless Chuck Grip High speed The arrows on the chuck indicate the The drill/driver has a two-speed gearbox for direction of rotation of the body of the chuck drilling or driving at low or high speeds.
  • Page 13 OPERATION INSTALLING A BIT (FIG. 11) ADJUSTABLE TORQUE CLUTCH (FIG. 10) Release FIG.11 Arrow FIG.10 Keyless Chuck Grip Torque-Adjustment Ring 1. Lock the trigger switch by placing the direction-of-rotation selector in the OFF The torque clutch can be adjusted to any (center) position.
  • Page 14 OPERATION WARNING: WARNING: Be sure to insert the Always wear safety drill bit straight into the jaws of the chuck. goggles or safety glasses with side shields Do not tighten the jaws of the chuck with during power tool operation or when the drill bit inserted at an angle, as shown blowing dust.
  • Page 15 OPERATION DRILLING MODE OPERATION SCREWDRIVER OPERATION For drilling in wood, use twist bits, spade 1. Select the desired speed/torque range bits, power auger bits or hole saws. to match the planned operation. 2. Attach the desired fastener accessory 1. When drilling “through” holes, place a into the chuck.

  • Page 16: Maintenance

    MAINTENANCE BEFORE EACH USE WARNING: To avoid serious personal injury, always detach the battery 1. Inspect the tool, the trigger switch and pack from the tool when cleaning or the accessories for damage. performing any maintenance. Contact a 2. Check for damaged, missing, or worn qualified service technician for all repairs.

  • Page 17: Troubleshooting

    TROUBLESHOOTING PROBLEM CAUSE SOLUTION The drill/driver does not work. Battery is depleted. Charge the battery. Chuck is not opened. Open the chuck. Bit cannot be installed. Bit does not fit the chuck. Use suitable bit. Clean, clear vents. Do not Be sure cooling vents are Motor overheating.
  • Page 18 NOTES Page 17...
