12 Volt Lithium-Ion Cordless
Drill/Driver
241-0313
OPERATOR'S MANUAL
CAUTION:
To Reduce The Risk Of Injury, User Must Read And
Understand The Operator's Manual. Save These Instructions For
Future Reference.
For questions / comments, technical assistance or repair parts –
Please Call Toll Free: 1-866-917-4374. (M-F 8am – 6pm EST.)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for MasterForce 241-0313
Summary of Contents for MasterForce 241-0313
- Page 1 12 Volt Lithium-Ion Cordless Drill/Driver 241-0313 OPERATOR’S MANUAL CAUTION: To Reduce The Risk Of Injury, User Must Read And Understand The Operator’s Manual. Save These Instructions For Future Reference. For questions / comments, technical assistance or repair parts – Please Call Toll Free: 1-866-917-4374. (M-F 8am – 6pm EST.)
-
Page 2: Table Of Contents
TAbLE Of CONTENTS Safety Symbols ............Page 2 Safety Instructions . -
Page 3: Safety Symbols
SAfETy SyMbOLS Some of these following symbols may be used on this tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and more safely. Symbol Designation / Explanation Name Volts Voltage... -
Page 4: Safety Instructions
SAfETy INSTRUCTIONS The purpose of safety symbols is to attract your attention to possible dangers. The safety symbols and the explanations with them deserve your careful attention and understanding. The symbol warnings do not, by themselves, eliminate any danger. The instructions and warnings they give are no substitutes for proper accident prevention measures. -
Page 5: General Safety Rules
SAfETy INSTRUCTIONS GENERAL SAfETy RULES 3. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock. WARNING: Read all safety 4. Do not abuse the cord. Never use the warnings and instructions. - Page 6 SAfETy INSTRUCTIONS 5. Do not overreach. Keep proper footing 6. keep cutting tools sharp and clean. and balance at all times. This enables Properly maintained cutting tools with better control power tool sharp cutting edges are less likely to bind unexpected situations.
- Page 7 SAfETy INSTRUCTIONS SPECIfIC SAfETy RULES fOR CORDLESS DRILL DRIVER 1. Use the tool only with the battery and charger listed below: Battery pack Charger 252-8016 252-8020 252-8017 WARNING: Hold power tools by their insulated gripping surfaces when performing an operation where the cutting tool may contact hidden wiring or its own cord.
-
Page 8: Overview/Specifications
OVERVIEW Torque adjustment ring Two-speed gearbox switch Vents LED worklight Direction of rotation Trigger switch selector (Forward/Center Lock/ Reverse) SPECIfICATIONS Motor 12 Volt DC Switch VSR (Variable Speed Reversible) No-load speed LO 0–400 / HI 0–1400 RPM Clutch 17+1 Torque 260 in.lbs. -
Page 9: Assembly
SPECIfICATIONS kEyLESS CHUCk WARNING: The safe use of this keyless chuck allows product requires an understanding of the hand-tighten or release the drill bit in the information on the tool and in this chuck jaws. operator’s manual, as well as knowledge fORWARD/CENTER LOCk/REVERSE of the project you are attempting. -
Page 10: Operation
OPERATION TO ATTACH bATTERy PACk CAUTION: When placing the (fIG. 1) battery pack in the tool, be sure that the raised rib on battery pack aligns with the groove inside the drill and that the latches FIG. 1 snap into place properly. Improper attachment of the battery pack can cause damage to internal components. - Page 11 OPERATION DIRECTION-Of-ROTATION ELECTRIC bRAkE SELECTOR (fORWARD/ To stop the drill/driver, release the trigger CENTER LOCk/REVERSE) switch and allow the tool to come to a (fIG. 3) complete stop. The electric brake quickly stops the rotation. This feature engages automatically when release FIG.
- Page 12 OPERATION TWO-SPEED GEAR bOX (fIG. 5) NOTICE: Never change gears while the tool is running. failure to obey this caution could result in serious damage to the drill/driver. FIG. 5 ADJUSTAbLE TORQUE CLUTCH (fIG. 6) FIG. 6 To decrease torque Two-speed gearbox switch The drill/driver has a two-speed gear box To increase...
- Page 13 OPERATION NOTICE: when adjusting the torque clutch The LED worklight, located on the front make sure that the speed switch is either of the drill/driver, will illuminate when the completely in the LO or HI position. trigger switch is depressed. This provides additional light on the surface of the CAUTION: Do not change the...
-
Page 14: Removing Bits
OPERATION NOTICE: Rotate the chuck body in the 1. Check the direction-of-rotation selector direction of the arrow marked GRIP to for the correct setting. 2. Secure the material to be drilled in close the chuck jaws. Do not use a a vise or with clamps to keep it from wrench to tighten or loosen the chuck turning as the drill bit rotates. -
Page 15: Maintenance
OPERATION 3. When drilling “through” holes, place a 3. Maintain a speed and pressure which block of wood behind the workpiece allows cutting without overheating the to prevent ragged or splintered edges on bit. Applying too much pressure will: the back side of the hole. - Overheat the drill/driver. -
Page 16: Troubleshooting
MAINTENANCE CHUCk REMOVAL (fIG. 11) 2. Open chuck jaws. Using screwdriver, remove the chuck screw by turning it in a clockwise direction. 3. Insert a 5/16-in. or larger hex key into FIG. 11 the chuck of the drill/driver and tighten the chuck jaws securely. - Page 17 NOTES Page 16...
- Page 18 NOTES Page 17...
-
Page 19: Warranty
90-DAy MONEy bACk GUARANTEE: This MASTERFORCE brand power tool carries our 90-DAY Money Back ® Guarantee. If you are not completely satisfied with your MASTERFORCE brand ® power tool for any reason within ninety (90) days from the date of purchase, return... - Page 20 © 2013 Menard, Inc., Eau Claire, WI 54703 09/2013 Page 20...
