- Page 1 AGD650 AI Multi Modal Detector PRODUCT MANUAL AGD650 AI Multi Modal Detector AGD-SYSTEMS.COM...
-
Page 2: Table Of Contents
Safety precautions Connecting Connecting Wifi DISCLAIMER Connecting device Set-up device using Wifi AGD Touch-setup Warranty Step 1 – Name site Contact Details Step 2 – Set zones 10 - 12 Change masks Detection zones Step 3 – Choose settings Example image 1 Example image 2 AGD650 | AI MULTI MODAL DETECTOR... -
Page 3: Introduction
AGD650 INTRODUCTION AI Multi Modal Detector PRODUCT OVERVIEW AND TECHNOLOGY The AGD650 employs high grade optics and deep learning image recognition to detect The AGD650 AI Multi Modal detector is a stationary and moving targets as they approach smart optical detector designed for use the stop-line. The neural net has undergone in dynamic environments. It makes... -
Page 4: Product Overview Image
(blue) PRODUCT VARIANTS 650-400-022 AI Multi Modal Detector/24-42V/Dual Opto Output/1m + mating lead 650-401-022 AI Multi Modal Detector/24-42V/Dual Opto Output/5m flying lead 650-402-022 AI Multi Modal Detector/24-42V/Dual Opto Output/5m flying lead/NEMA AGD650 | AI MULTI MODAL DETECTOR... -
Page 5: Physical Installation
Mounting position in different environments When installing the AGD650 on the traffic head, please use the 6” extension bracket supplied to allow it to see over the backing boards and detect traffic at the stop-line. If the stop-line is 1.4m or less from the mounting pole, then a 90º bracket looking around the traffic head is recommended. 1.4m or closer Greater than 1.4m AGD650 | AI MULTI MODAL DETECTOR... -
Page 6: Installation And Commissioning
STEP 3 - FINAL ADJUSTMENT & VERIFICATION Confirm the detector is correctly aligned. The entire stop-line should be visible when looking at the detector’s live view within the GUI. Where possible, the field of view should include at least one full vehicle length before and after each detection zone. The horizon should be out of view to reduce sun glare. Once complete, please monitor traffic to ensure zones are correctly placed. AGD650 | AI MULTI MODAL DETECTOR... -
Page 7: Electrical Installation
Not Connected Brown Opto 2 N/O Zone 2 Pink Opto 2 N/C Zone 2 Opto-coupler ratings The voltage tolerances of supply 24V ac/dc, 42V ac ±20% Max current 60mA Max Voltage 60V Max on-state impedance 25 Ohms AGD650 | AI MULTI MODAL DETECTOR... -
Page 8: Power Up Sequence
650:XXXXXX-XXXX-TBD (the ‘X’s denote the S/N, TBD is a renamable field used to name the pole location the 650 is installed on) Click ‘connect’ and input the default password: Agd650:XXXXXX-XXXX (the ‘X’s denote the S/N) For security reasons, AGD Systems strongly recommends changing the password during step 1 of the set-up process. Please note that, if the password is changed and the new password is lost, the product will need to be returned to AGD to be reset. The LED on the underside of the unit should now be illuminated blue to show WiFi is successfully connected and your device should show connected. -
Page 9: Set-Up Device Using Wifi Agd Touch-Setup
New password/Confirm password - To keep reconnect to the new SSID after clicking “next” the default password, leave these fields blank. User notes - An editable field to allow engineers To change you must enter an identical password to store notes in the device. Max characters = 110. in both fields. Characters = 8 minimum, 63 maximum. AGD650 | AI MULTI MODAL DETECTOR... -
Page 10: Step 2 - Set Zones
Zone 1 - Detection area linked to OPTO 1 output. Custom: Select from available classification Add / Undo / Redo buttons for quick set-up. filter options, eg: buses Zone 2 - Detection area linked to OPTO 2 output. Add / Undo / Redo buttons for quick set-up. AGD650 | AI MULTI MODAL DETECTOR... -
Page 11: Change Masks
It is important to note that not report targets. Masks should be used vehicles moving through a masked region might sparingly. It can be prudent to mask any not be detected. foreground street furniture such as a close-up AGD650 | AI MULTI MODAL DETECTOR... -
Page 12: Detection Zones
A gap between each lane is required to stop false the direction of traffic and be parallel with the detections of adjacent lane traffic. road layout. Lane differentiation can be achieved Select the correct option from the drop-down list for your intended application. Each zone operates independently. Note: If no zones have been defined, the red LED will be on and both outputs will be in the detect state. AGD650 | AI MULTI MODAL DETECTOR... -
Page 13: Step 3 - Choose Settings
1 or 2. Percentage figures can be seen on the home screen when looking at the live traffic view. Input range = 0 - 60,000ms. Default = 0ms Input range = 0 - 100%. Timeout (mins) - The amount of time the detection output is permitted to stay ON. Default = 30 (recommended) AGD650 | AI MULTI MODAL DETECTOR... -
Page 14: Example Image 1
INSTALLATION AND AGD650 COMMISSIONING COMMISSIONING AI Multi Modal Detector SET-UP DEVICE USING AGD TOUCH-SETUP After configuring settings and clicking the Finish button, it is recommended to power cycle or reboot (via the ADVANCED tab) the device, reconnect and confirm that all zones and settings are configured as required. EXAMPLE IMAGE 1 An example of what you will see once all steps have been completed correctly. AGD650 | AI MULTI MODAL DETECTOR... - Page 15 INSTALLATION AND INSTALLATION AND AGD650 COMMISSIONING COMMISSIONING AI Multi Modal Detector EXAMPLE IMAGE 2 An example of what you will see once all steps have been completed correctly. AGD650 | AI MULTI MODAL DETECTOR...
-
Page 16: Enabling Bus-Only Detection
As part of the pre-release data collection and testing, we have identified certain circumstances where classification filtering performance may fall short of what it expected of an AGD product. This guidance is designed to provide information on how to minimise any incorrect class identification that may occur. AGD650 | AI MULTI MODAL DETECTOR... - Page 17 AGD650 DETECTION AI Multi Modal Detector CONSIDERATIONS FOR BEST PERFORMANCE Ambient Lighting Levels The minimum recommended light level for the AGD650 is 20 Lux. This should be taken into consideration when choosing an appropriate mounting location. The AGD650 also incorporates an IR lens filter (to assist performance in bright/sunny conditions) so additional IR illumination is not available with this product. Even in low natural light and poor weather conditions, with the correct ambient lighting, accurate detections can be achieved. AGD650 | AI MULTI MODAL DETECTOR...
- Page 18 ENABLING BUS-ONLY AGD650 DETECTION AI Multi Modal Detector Location of Detector and Detection Area Correct location and alignment are crucial to the correct operation of the AGD650. Firstly, the mounting location must be chosen carefully. Below is an example of incorrect mounting location. The intrusion of the lamp head into the area immediately after the detection zone ‘blocks’ the detector’s view of targets, causing issues with certain vehicles being incorrectly classified when they are partially obscured. AGD650 | AI MULTI MODAL DETECTOR...
- Page 19 The below picture shows changes required. a) Detector mounting location adjusted to remove lamp head obstruction b) Detection zone moved away from stop line to give a clear area between the detection zone and the edge of the field of view of the detector As a rule of thumb, the ideal detection area will be between 10m and 20m from the detector. AGD650 | AI MULTI MODAL DETECTOR...
- Page 20 ENABLING BUS-ONLY AGD650 DETECTION AI Multi Modal Detector Visibility of Whole Target Visibility of the entire target within the detector field of view is desirable. If the entire target is not visible, this can lead to low confidence levels, or incorrect classification of targets. Ideally a full vehicle length will be visible before and after each detection zone. AGD650 | AI MULTI MODAL DETECTOR...
-
Page 21: Troubleshooting
Is the LED on the underside of the unit you wish to connect to illuminated blue to show that the WiFi network is successfully connected? Has the correct IP Address been entered into the browser address bar? 3) Have you followed the AGD Touch-setup stages correctly and verified correct operation? If trouble with operation persists please contact AGD Technical Support. AGD Technical Support Email: technical@agd-systems.com Tel: +44 (0) 1452 557404 AGD650 | AI MULTI MODAL DETECTOR... -
Page 22: Technical Specifications
EN IEC 63000:2018 Other: TOPAS 2505B Appendix E Patent No. Patent Pending - GB2619098 Registration Owing to the Company’s policy of continuous improvement, AGD Systems Limited RoHS Evaluation Authorisation reserves the right to change their specification or design without notice. COMPLIANT and Restriction of Chemicals Restriction on Hazardous Substances AGD650 | AI MULTI MODAL DETECTOR... -
Page 23: End Of Life - Disposal Instructions (Eol)
Non -Recyclable Aluminium & Nylon Stainless Steel Stainless Steel Nitrile PCB Assembly Polycarbonate Nylon Stainless Steel Glass Nitrile Stainless Steel ABS & Glass Aluminium Oxide Stainless Steel Polycarbonate & Steel Nitrile Stainless Steel PCB Assembly HSAP AGD650 | AI MULTI MODAL DETECTOR... -
Page 24: Important Safety Information
Radio Equipment Regulations 2017 (SI2017/1206) There is no restrictions of use within any EU Member state for this product. This product is Receiver Category 2. Indicates compliance with all applicable Australian ACMA technical standards and associated record keeping (including testing) arrangements. /contd AGD650 | AI MULTI MODAL DETECTOR... - Page 25 20cm of the body. • The transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. • Changes or modifications not expressly approved by AGD Systems Ltd could void the user’s authority to operate the equipment. AGD650 | AI MULTI MODAL DETECTOR...
-
Page 26: Disclaimer
Warranty All AGD products are covered by a 12 month return to factory warranty. Products falling outside this period may be returned to AGD Systems for: evaluation, repair, update or re-calibration, any of which may be chargeable. Revision Issue 6 May 2024 AGD Systems Limited White Lion House, Gloucester Road, Cheltenham, GL51 0TF, UK Tel: +44 (0) 1452 854212 Email: info@agd-systems.com Web: agd-systems.com...
