- Page 1 AGD 641 PEDESTRIAN DETECTOR AGD 641 PEDESTRIAN DETECTOR PRODUCT MANUAL ✓...
-
Page 2: Table Of Contents
Power Up Sequence Low power non-ionising radio transmission Connecting and safety Connecting Wifi Connecting device CERTIFICATES Set-up device using Wifi AGD Touch-setup Step 1 – Name site DISCLAIMER Step 2 – Set zone Step 3 – Calibrate Warranty Home page... -
Page 3: Introduction
AGD 3D optical stereo vision technology provides greater performance even at low light levels. • WiFi AGD Touch-setup technology with 3 step browser setup speeds up installation and reduces installer risk. • Flexible polygon tool allows easy configuration of curved or irregular detection zones saving time on site. -
Page 4: Product Overview Image
Introduction AGD 641 PEDESTRIAN DETECTOR PRODUCT OVERVIEW IMAGE AGD 641 PEDESTRIAN DETECTOR Right Camera Left Camera Right Camera Left Camera Power-Up & Detect LED (red) and WiFi Low voltage Mains voltage indicator (blue) supply and opto supply and opto isolator detect... -
Page 5: Installation And Commissioning
If you have an application whereby you wish to mount the detector outside of these heights, then please contact AGD. Min 3m 45º STEP 3 - DETECTOR VIEW – View the zone-area from the detector, including the area directly in front of the push button. -
Page 6: Electrical Installation
Installation and Commissioning AGD 641 PEDESTRIAN DETECTOR ELECTRICAL INSTALLATION AGD 641 The detector is powered using a 12-24V ac/dc (±20%) or 230Vac supply. For the PEDESTRIAN DETECTOR non mains units the power is applied to the detector using the multi-pin mating connector. -
Page 7: Connecting
The LED on the front of the unit should now be illuminated blue to show WiFi is successfully connected and your device should show connected. AGD Systems recommend you change the password via the Advanced screen option. CONNECTING DEVICE Complete Wifi connection step as above. -
Page 8: Set-Up Device Using Wifi Agd Touch-Setup
Installation and Commissioning SET-UP DEVICE USING AGD TOUCH-SETUP When logged in to the device for the first time you click set-up. This is the AGD Touch-Setup, a three stage process that allows installers to configure the device quickly and efficiently. -
Page 9: Step 3 - Calibrate
Installation and Commissioning STEP 3 – CALIBRATE The third and final stage in the set-up is ‘Calibration’. Check the selected zone-area, ensure the zone is empty, then click ‘On-Site Calibration’. Successful completion of the calibration will result in the detector returning to the ‘Home’... -
Page 10: Optional Parameters
Installation and Commissioning OPTIONAL PARAMETERS OPTIONAL PARAMETERS • Wifi off after 24 hours Select this box to disable the WiFi after 24 hours. The device will need to be power cycled to have the WiFi network viewable after this period ... -
Page 11: Pedestrian Detector
Technical Resource AGD 641 PEDESTRIAN DETECTOR PHYSICAL INSTALLATION AGD 641 TYPICAL INSTALLATION PARAMETERS PEDESTRIAN DETECTOR The AGD641 operates with a high degree of accuracy when mounted inside normal parameters. The diagram below shows a plan view of the expected coverage of the stereo cameras when the detector device is mounted at a height between 3 - 4metres. -
Page 12: Troubleshooting
Is the LED on the front of the unit you wish to connect to illuminated blue to show that the WiFi network is successfully connected? Has the correct IP Address been entered into the browser address bar? Have you followed the AGD Touch-setup stages correctly and verified correct operation? If trouble with operation persists please contact AGD Technical Support. AGD TECHNICAL SUPPORT eMail: technical@agd-systems.com... -
Page 13: Technical Specifications
Health & Safety: EN 60950-1, EN 60950-22, EN 50556, EN 62311 Spectrum: EN 300 328. RoHS: EN 50581, TOPAS 2507A Patent No. GB 2448617 Owing to the Company’s policy of continuous improvement, AGD Systems Limited reserves the right to change their specification or design without notice. RoHS Registration... -
Page 14: End Of Life Document
End Of Life – Disposal Instructions (EOL) AGD 641 PEDESTRIAN DETECTOR AGD641 PEDESTRIAN DETECTOR AGD 641 PEDESTRIAN DETECTOR • • Reuse / Recycle Item Qty Material Item Qty Material Item Qty Material Aluminium Polycarbonate Stainless Steel • Separate & Recycle... -
Page 15: Safety Precautions
Under no circumstances should a product suspected of damage be powered on. Internal damage may be suggested by unusual behaviour, an unusual odour or damage to the outer casing. Please contact AGD for further advice. -
Page 16: Certificates
Certification... - Page 17 Notes...
- Page 18 Notes...
- Page 19 Notes...
-
Page 20: Disclaimer
WARRANTY All AGD products are covered by a 12 month return to factory warranty. Products falling outside this period may be returned to AGD Systems for: evaluation, repair, update or re-calibration, any of which may be chargeable. AGD Systems Limited White Lion House, Gloucester Road, Cheltenham, GL51 0TF, UK Tel: +44 (0) 1452 854212 Email: info@agd-systems.com Web: agd-systems.com...
