- Page 1 AGD645 Pedestrian Detector PRODUCT MANUAL AGD645 Pedestrian Detector AGD-SYSTEMS.COM...
-
Page 2: Table Of Contents
IMPORTANT SAFETY INFORMATION Ethernet Connector Type Safety precautions Opto-Coupler Ratings Power Up Sequence DISCLAIMER Connecting Warranty Connecting Wifi Contact Details Connecting device Set-up device using Wifi AGD Touch-setup Step 1 – Name site Step 2 – Set zone 8 - 9 Step 3 – Calibrate Home page 10 - 11 Optional Parameters AGD645 | PEDESTRIAN DETECTOR... -
Page 3: Introduction
AGD645 INTRODUCTION Pedestrian Detector PRODUCT AND TECHNOLOGY The AGD 645 Pedestrian Detector has been designed for the detection and monitoring of pedestrians waiting to cross the road to ensure the crossing phase is called only when pedestrians are present. The AGD 645 builds on the popular AGD 640 Pedestrian Detector which has successfully been deployed on over 15,000 sites worldwide. -
Page 4: Product Overview Image
Designed into the platform to cover the needs of ‘Smart City’ systems are IP, Power Over Ethernet, and real- time video capabilities which allow the 645 to feed data and pictures ‘down the wire’ straight into ITS control rooms – empowering truly informed decision making. AGD645 | PEDESTRIAN DETECTOR... -
Page 5: Installation And Commissioning
INSTALLATION AND AGD645 COMMISIONING Pedestrian Detector PHYSICAL INSTALLATION STEP 1 - MOUNTING STEP 2 - DETECTOR ALIGNMENT – The AGD 645 HEIGHT – The AGD 645 Pedestrian Detector should be mounted using the Pedestrian Detector has supplied hardware. Adjust the tilt angle so that excellent performance the arrow marking on the housing and mounting... -
Page 6: Electrical Installation
OPTO-COUPLER RATINGS • Max current 100mA • Max Voltage 100V • Max on-state impedance 25 Ohms POWER UP SEQUENCE After applying power to the unit, the front red LED will permanently illuminate for approximately 30 secs while the operating system loads. The LED will then start flashing and either extinguish if the detector has been previously set-up and revert to normal operation (illuminated if zone is in detect, not illuminated if zone is empty), or the LED will continue to flash until the unit has been set-up and commissioned. AGD645 | PEDESTRIAN DETECTOR... -
Page 7: Connecting
645:XXXXXX-XXXX-TBD (the ‘X’ denotes the S/N, TBD is a renamable field used to name the pole location the 645 is installed on) Click ‘connect’ and input the default password: Agd645:XXXXXX-XXXX (the ‘X’ denotes the S/N) AGD Systems recommend you change the password via the Advanced screen option. The LED on the front of the unit should now be illuminated blue to show WiFi is successfully connected and your device should show connected.`... -
Page 8: Set-Up Device Using Wifi Agd Touch-Setup
INSTALLATION AND AGD645 COMMISSIONING Pedestrian Detector SET-UP DEVICE USING AGD TOUCH SETUP The AGD 645 Pedestrian Detector has been designed with efficiency and ease of use in mind. It is connected to using a WiFi enabled device (laptop, tablet or phone) and setup simply using a browser window. This step-through process describes the actions required to setup the detector upon initial deployment when first removed from the box. - Page 9 0.6m threshold. Please note: The maximum range of the AGD645 will still be 10m, extending the zone helps the detector to see the body of a pedestrian. When the zone is set, click ‘Next’. 0.6m 0.6m AGD645 | PEDESTRIAN DETECTOR...
-
Page 10: Step 3 - Calibrate
The image you see on the screen will be the detect area with any area excluded greyed out. Monitor the zone and check the detector triggers - the front LED will illuminate and extinguish when someone enters and leaves the zone. AGD645 | PEDESTRIAN DETECTOR... -
Page 11: Optional Parameters
This value denotes the amount of time the detection OPTO output is held AFTER a valid target leaves the area of detection. Input range = 0 - 60 seconds. Default = 2 seconds User notes An editable field to allow engineers to store notes in the device. Max characters = 64 bytes AGD645 | PEDESTRIAN DETECTOR... -
Page 12: Technical Resource
4.0 = 13.2 25 = 82.5 4.5 = 14.9 50 = 165.0 5.0 = 16.5 100 = 330.0 5.5 = 18.2 150 = 495.0 6.0 = 19.8 180 = 594.0 Please Note: The table above is a generic meters to feet conversion table to aid international customers. For product specific mounting heights and detection ranges, please refer to the relevant sections of this product manual. AGD645 | PEDESTRIAN DETECTOR... -
Page 13: Physical Installation
The diagram below shows a plan view of the expected coverage of the stereo cameras when the device is mounted at a height between 3.5-4.0 metres. 8 Metres 3.5 Metres 6.5 Metres 3 Metres 10m x 3m Zone - Illustrated using nominal mounting height of 3.5-4.0m AGD645 | PEDESTRIAN DETECTOR... -
Page 14: Electrical Installation
MATING CONNECTOR DETAILS Product mating connector: Binder 09-3782-91-08 FIELD INSTALLABLE CONNECTOR Cable mount connector: Binder 99-3787-810-08 *Connector is wired as per the manufacturers instructions* P.O.E - POWER OVER ETHERNET REQUIREMENTS AGD 645 P.O.E REQUIREMENTS Type 1 Class 3 Device 802.3at Compliant and Isolated 6.49W to 13W (7W nominal) 37.0v to 57.0v Supports Mode A and Mode B Wiring AGD645 | PEDESTRIAN DETECTOR... -
Page 15: Connecting Ethernet
This is the preferred method as it allows the use of standard tooling and allows testing and fault Standard RJ45 Plug finding to be carried out in an easy manner using regular RJ45 network test equipment. The part number for the pre-assembled cable is: Metz Connect - 142M2X15010 AGD645 | PEDESTRIAN DETECTOR... -
Page 16: Connecting / Commissioning
CONNECTING / COMMISSIONING ETHERNET SETTINGS The AGD 645 can be connected to a network and obtain an IP address through a DHCP server. Alternatively, the IP address, gateway and netmask may be set to customer specified values. The ethernet settings can be accessed under the ‘optional parameters’ in stage one of the setup process. When using static IP settings, please consult your networking professional for assistance. AGD645 | PEDESTRIAN DETECTOR... - Page 17 <15% Medium = 15-85% High >85% *The lowest the bottom slider may be set is 10%. *The highest the bottom slider may be set is 90%. *The gap between low and high must be >15%. AGD645 | PEDESTRIAN DETECTOR...
- Page 18 The state of the OPTO outputs in relation to the interest is occupancy is shown in the table below: depicted by the area inside Occupancy Opto 1 Opto 2 of the grey No-Detect mask. This image shows the detector Medium having a ‘HIGH’ High occupancy. AGD645 | PEDESTRIAN DETECTOR...
-
Page 19: Troubleshooting
Is the LED on the front of the unit you wish to connect to illuminated blue to show that the WiFi network is successfully connected? 2) Has the correct IP Address been entered into the browser address bar? 3) Have you followed the AGD Touch-setup stages correctly and verified correct operation? If trouble with any operations persist, please contact AGD Technical Support. AGD TECHNICAL SUPPORT eMail: technical@agd-systems.com Tel: +44-1452-557404 AGD645 | PEDESTRIAN DETECTOR... -
Page 20: Technical Specifications
Other: TOPAS 2507A, NEMA TS 2 2016 Patent No. GB 2448617 *For US special build variant required RoHS Registration Owing to the Company’s policy of continuous improvement, AGD Systems Limited Evaluation COMPLIANT Authorisation reserves the right to change their specification or design without notice. and Restriction of... -
Page 21: End Of Life Document
EPDM Stainless Steel Stainless Steel • Hazardous Recovery Nylon Steel Polyethylene Non -Recyclable Printed Stainless Steel Glass Circuitboard Mixed Metals, Nylon Neoprene Soft therm & PVC Printed Circuit Ceramic Powder Polyester board Filled Silicon Resin Polyester AGD645 | PEDESTRIAN DETECTOR... -
Page 22: Safety Precautions
Please contact AGD for further advice. This Product is Compliant with the European Radio Equipment Directive 2014/53/EU. There is no restrictions of use within any EU Member state for this product. This product is Receiver Category 2. AGD645 | PEDESTRIAN DETECTOR... -
Page 23: Disclaimer
12 month return to factory warranty. Products falling outside this period may be returned to AGD Systems for: evaluation, repair, update or re-calibration, any of which may be chargeable. Revision Issue 6 April 2021 AGD Systems Limited White Lion House, Gloucester Road, Cheltenham, GL51 0TF, UK Tel: +44 (0) 1452 854212 Email: info@agd-systems.com Web: agd-systems.com...
