- Page 1 AGD 326 AGD 326 PRODUCT PEDESTRIAN ON-CROSSING DETECTOR MANUAL AGD 326 PEDESTRIAN ON-CROSSING DETECTOR New Longer Range AGD 326 PEDESTRIAN ON-CROSSING DETECTOR ✓...
-
Page 2: Table Of Contents
15-18 TROUBLESHOOTING Physical installation Connecting / commissioning RADAR CHARACTERISTICS Radar characteristics Frequency variants 326 Field pattern TECHNICAL SPECIFICATIONS Product specification CERTIFICATES END OF LIFE - DISPOSAL INSTRUCTIONS (EOL) IMPORTANT SAFETY INFORMATION Safety precautions Low power non-ionising radio transmission and safety... -
Page 3: Introduction
The 326 allows optimisation of the crossing phase, giving back more green time to traffic. AGD Touch-setup provides safe and easy setup via a smart phone or tablet. -
Page 4: Product Overview Image
Introduction AGD 326 PRODUCT OVERVIEW IMAGE AGD 326 PEDESTRIAN ON-CROSSING DETECTOR AGD 326 PEDESTRIAN ON-CROSSING DETECTOR Front AGD 326 (power on) detect LED PEDESTRIAN ON-CROSSING DETECTOR Rear (power on) Power detect LED Power and detect Switched relay / opto relay output... -
Page 5: Installation And Commissioning
Installation and Commissioning AGD 326 PHYSICAL INSTALLATION AGD 326 4m max STEP 1 - MOUNTING HEIGHT PEDESTRIAN ON-CROSSING DETECTOR The AGD326 radar has been designed to AGD 326 Detector mounted at 3m operate at a mounting height of between 2m-4m, with an unobstructed view of the... -
Page 6: Electrical Installation
Installation and Commissioning AGD 326 ELECTRICAL INSTALLATION AGD 326 12/24V ac/dc or 42V ac – Multi-pin Connector or 5m Flying Lead PEDESTRIAN ON-CROSSING DETECTOR The detector is powered using a 12/24V ac/dc (+/- 20%) or 42V ac supply. AGD 326 The power is applied to the detector using a multi-pin mating connector. - Page 7 The detector is supplied with two 5m flying leads. One is the power supply for the detector and the other is the signal output and the correct cables should be identified before connection. The 326 is classified as a double...
- Page 8 Installation and Commissioning AGD 326 ELECTRICAL INSTALLATION AGD 326 APPLYING POWER PEDESTRIAN ON-CROSSING DETECTOR • Make sure the power supply is the correct voltage, AGD 326 which can be found on the label on the unit. PEDESTRIAN ON-CROSSING DETECTOR • Connect the unit to the supply.
-
Page 9: Connecting
Launch a browser on your smartphone, tablet or laptop (Modern versions of: Internet Explorer, Google Chrome and Safari are all supported - 2016 onwards). In the address bar of your browser, enter the ‘IP Address’: http://192.168.4.1 You will be presented with your initial AGD Touch-setup page. -
Page 10: User Interface
Installation and Commissioning AGD 326 USER INTERFACE AGD 326 Detector Configuration PEDESTRIAN ON-CROSSING DETECTOR AGD 326 PEDESTRIAN ON-CROSSING DETECTOR AGD 326 PEDESTRIAN ON-CROSSING DETECTOR A - Detection Area Using the drop down menu’s within allows the user to adjust the size of the detection area to suit the size of the road (metres). - Page 11 WiFi deep sleep is adjusted here on the drop down list, the radars WiFi will switch off until a power cycle has been carried out C – Firmware Update The user can upload the latest radar/WiFi firmware here by uploading a zip file supplied by AGD. Please contact AGD for further information.
- Page 12 Installation and Commissioning AGD 326 USER INTERFACE AGD 326 Radar Alignment & Walk Test PEDESTRIAN ON-CROSSING DETECTOR AGD 326 Once you have fixed your radar to the mounting position correctly and PEDESTRIAN ON-CROSSING DETECTOR finished configuring the GUI it is...
-
Page 13: Technical Resource
Technical Resource AGD 326 PHYSICAL INSTALLATION AGD 326 The AGD326 has been designed to be installed as a pair to ensure coverage of the entire crossing is achieved. PEDESTRIAN ON-CROSSING DETECTOR Each detector covers the far side of the crossing which causes dead spots that the opposite detector must cover. - Page 14 Technical Resource AGD 326 PHYSICAL INSTALLATION AGD 326 Marked area shows the must detect zone that the pair of detectors must cover. PEDESTRIAN ON-CROSSING DETECTOR AGD 326 PEDESTRIAN ON-CROSSING DETECTOR AGD 326 PEDESTRIAN ON-CROSSING DETECTOR MUST DETECT ZONE Up to 10m Please note: The radars have a ‘may detect zone’...
- Page 15 Co-Location of AGD Detectors PEDESTRIAN ON-CROSSING DETECTOR Installing two or more AGD detectors e.g 306, 326 or 316, 326 on the same traffic signal pole can result in AGD 326 crosstalk and a degradation in performance if they are on the same frequency.
- Page 16 Technical Resource AGD 326 TRANSMIT CHANNELS - TYPICAL SCENARIOS AGD 326 Co-Location of AGD Detectors PEDESTRIAN ON-CROSSING DETECTOR Example 1: Standard crossing layout two AGD326 detectors alongside two radars AGD 326 PEDESTRIAN ON-CROSSING DETECTOR AGD 326 PEDESTRIAN ON-CROSSING DETECTOR The devices numbered 1 to 4 are...
-
Page 17: Transmit Channel - Typical Scenarios
Technical Resource AGD 326 TRANSMIT CHANNELS - TYPICAL SCENARIOS AGD 326 Co-Location of AGD Detectors Channel 4 PEDESTRIAN ON-CROSSING DETECTOR Example 2: Dual crossing layout four AGD326 detectors AGD 326 PEDESTRIAN ON-CROSSING DETECTOR AGD 326 PEDESTRIAN ON-CROSSING DETECTOR AGD Product... - Page 18 AGD 326 350-100:CH2 350-100:CH1 343-501:CH2 TRANSMIT CHANNELS - TYPICAL SCENARIOS 343-500:CH4 AGD 326 343-500:CH3 24.100G, 9M Table 1: AGD 24GHz Radar Channels 24.094G, 1M PEDESTRIAN ON-CROSSING DETECTOR AGD 326 24.200G, 13M 318 USA:CH2 318 USA:CH1 PEDESTRIAN ON-CROSSING DETECTOR 318 Europe:CH2...
-
Page 19: Troubleshooting
What height should the AGD326 be mounted at and what angle of declination is recommended? AGD 326 The 326 should be mounted at a nominal height of between 2-4 metres from ground level and have a clear view of the pedestrian crossing area to be covered with no obstructions from other street furniture for... -
Page 20: Connecting / Commissioning
What size zone of detection can be set on the AGD326? AGD 326 The 326 can have a single zone set up to 2 to 24 metres in length (user selectable via the maximum range adjustment on the GUI) and up to 10 metres wide depending upon the width setting. -
Page 21: Radar Characteristics
>20dB E-Field Vertical Plane polarised Operating Frequency Band and Power The 326 radar uses a temperature compensated transceiver design. The hardware of the transceiver has been uniquely designed to operate in the 24.050 to 24.250GHz Band Parameter Specified Notes Centre Frequency (channel 1 &2) 24.092 GHz... -
Page 22: Radar Characteristics
Licence Required for Use Frequency Allocated but EIRP too high It is important to note that this table is updated from time to time. Please contact AGD for latest information if your intended country of use is not currently represented. -
Page 23: 326 Field Pattern
Radar Characteristics AGD 326 326 FIELD PATTERN AGD 326 PEDESTRIAN ON-CROSSING DETECTOR TX - Antenna Pattern AGD 326 PEDESTRIAN ON-CROSSING DETECTOR AGD 326 PEDESTRIAN ON-CROSSING DETECTOR Angle (º) ------- Elevation ------- Horizontal... -
Page 24: Technical Specifications
Owing to the Company’s policy MTBF of continuous improvement, 20yrs based on field data of prior generation radar for AGD Systems Limited reserves 10,000 units installed over 3 years the right to change their specification or design without Complies with EN 301 489, EN 50293, AS/NZS 4268... - Page 25 Certification...
-
Page 26: End Of Life - Disposal Instructions (Eol)
End Of Life – Disposal Instructions (EOL) AGD 326 AGD326 PEDESTRIAN ON-CROSSING DETECTOR AGD 326 PEDESTRIAN ON-CROSSING DETECTOR AGD 326 PEDESTRIAN ON-CROSSING DETECTOR AGD 326 PEDESTRIAN ON-CROSSING DETECTOR • • Reuse / Recycle Item Qty Material Item Qty Material Polycarbonate Nitrile •... -
Page 27: Important Safety Information
20cm of the body. • The transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. • Changes or modifications not expressly approved by AGD Systems Ltd could void the user’s authority to operate the equipment. -
Page 28: Low Power Non-Ionising Radio Transmission And Safety
0.318mW/cm2) is at a point in the field where the radar beam is not properly formed. Note 4 Comparison for product model 326 operating in the 24GHz band. From the table it can be seen that it is extremely unlikely that a potentially hazardous situation could occur owing to the use of such low power devices. - Page 29 Notes...
- Page 30 Notes...
- Page 31 Notes...
- Page 32 WARRANTY All AGD products are covered by a 12 month return to factory warranty. Products falling outside this period may be returned to AGD Systems for: evaluation, repair, update or re-calibration, any of which may be chargeable. AGD Systems Limited White Lion House, Gloucester Road, Cheltenham, GL51 0TF, UK Tel: +44 (0) 1452 854212 Email: info@agd-systems.com Web: agd-systems.com...
