- Page 1 AGD326 Pedestrian On-Crossing Detector PRODUCT MANUAL AGD326 Pedestrian On-Crossing Detector New Longer Range AGD-SYSTEMS.COM...
-
Page 2: Table Of Contents
User interface 10-12 TECHNICAL RESOURCE IMPORTANT SAFETY INFORMATION Conversion Table Safety precautions Physical installation 14-15 Low power non-ionising radio Transmit channel - typical scenarios 16-19 transmission and safety TROUBLESHOOTING DISCLAIMER Physical installation Warranty Connecting / commissioning AGD326 | PEDESTRIAN ON-CROSSING DETECTOR... -
Page 3: Introduction
AGD326 INTRODUCTION Pedestrian On-Crossing Detector PRODUCT AND TECHNOLOGY The AGD326 Pedestrian Detector is a smart, dynamic environment detector that makes crossings safer and more efficient by delivering robust detection day and night on wide crossings. The AGD326 radar has been designed for... -
Page 4: Product Overview Image
On-crossing radar/42Vac/24 GHz/Single Opto output/5m Flying Leads PRODUCT OVERVIEW This AGD326 on-crossing detector features a custom designed 24GHz planar antenna coupled with advanced radar processing in a modular design. The unit is compact in size and lightweight for ease of installation in a robust polycarbonate housing. -
Page 5: Installation And Commissioning
Detector PHYSICAL INSTALLATION 4m max STEP 1 - MOUNTING HEIGHT The AGD326 radar has been designed to operate at a mounting height of between 2m-4m, with an Detector mounted at 3m unobstructed view of the detection zone (optional height extension bracket BR-129 is available if required). -
Page 6: Electrical Installation
The detector is powered using a 12/24V ac/dc (+/- 20%) or 42V ac supply. The power is applied to the detector using a multi-pin mating connector. The AGD326 On Crossing Detector is provided with a Buccaneer Series PX0728/S 9 pole connector to enable direct connection to the traffic control system. The pin outs of the connector and detector function are shown below. - Page 7 It should be noted that the relays are rated at Max 230Vac and 0.5Amp but also must have a minimum whetting load of 12Vdc 100mA. In addition, the relay outputs are protected by a protection device which limits current to 0.5A and has a serial impedance of approximately 15 Ohms. AGD326 | PEDESTRIAN ON-CROSSING DETECTOR...
-
Page 8: Applying Power
• 24Vac - 66mA (peak 115mA) • 42Vac - 50mA (peak 90mA) • 230Vac - 10.1mA (peak 20mA) The installation of this equipment MUST conform to the latest edition of the IEE Wiring Regulations (BS7671). AGD326 | PEDESTRIAN ON-CROSSING DETECTOR... -
Page 9: Connecting
(Modern versions of: Internet Explorer, Google Chrome and Safari are all supported - 2016 onwards). In the address bar of your browser, enter the ‘IP Address’: http://192.168.4.1 You will be presented with your initial AGD Touch- setup page. AGD326 | PEDESTRIAN ON-CROSSING DETECTOR... -
Page 10: User Interface
Mounting Position The user has to change the mounting position within the GUI to align it with the mounting location on the crossing. Left or Right as if you were looking across the crossing from the mounted side AGD326 | PEDESTRIAN ON-CROSSING DETECTOR... - Page 11 WiFi deep sleep is adjusted here on the drop down list, the radars WiFi will switch off until a power cycle has been carried out C – Firmware Update The user can upload the latest radar/WiFi firmware here by uploading a zip file supplied by AGD. Please contact AGD for further information. AGD326 | PEDESTRIAN ON-CROSSING DETECTOR...
- Page 12 The radar should start to detect you as soon as you step on the opposite side of the road. If it does not go into detect, it is advised you add 1m onto the length and width you have measured. Figure 2 AGD326 | PEDESTRIAN ON-CROSSING DETECTOR...
-
Page 13: Technical Resource
Please Note: The table above is a generic meters to feet conversion table to aid international customers. For product specific mounting heights and detection ranges, please refer to the relevant sections of this product manual. Power connection to existing traffic cabinet AGD326 | PEDESTRIAN ON-CROSSING DETECTOR... - Page 14 Detector PHYSICAL INSTALLATION The AGD326 has been designed to be installed as a pair to ensure coverage of the entire crossing is achieved. Each detector covers the far side of the crossing which causes dead spots that the opposite detector must cover.
- Page 15 Please note: The radars have a ‘may detect zone’ surrounding the must detect zone to avoid false DETECT DETECT detections from the kerb edge and vehicles encroaching on the stop line. The AGD326 also has a ZONE ZONE ±1meter accuracy due to the calibration encoded on the detector. This is more noticeable on the extremities of the radars range E.g.
-
Page 16: Transmit Channel - Typical Scenarios
TRANSMIT CHANNELS - TYPICAL SCENARIOS Co-Location of AGD Detectors Installing two or more AGD detectors e.g 306, 326 or 316, 326 on the same traffic signal pole can result in crosstalk and a degradation in performance if they are on the same frequency. - Page 17 Pedestrian On-Crossing Detector TRANSMIT CHANNELS - TYPICAL SCENARIOS Co-Location of AGD Detectors Example 1: Standard crossing layout two AGD326 detectors alongside two radars Example 1: Standard crossing layout two AGD326 detectors The devices numbered 1 to 4 are representative AGD Product...
- Page 18 TECHNICAL RESOURCE Pedestrian On-Crossing Detector TRANSMIT CHANNELS - TYPICAL SCENARIOS Co-Location of AGD Detectors Channel 4 Example 2: Dual crossing layout four AGD326 detectors AGD Product Channel AGD326 Pedestrian Detector AGD326 Pedestrian Detector AGD326 Pedestrian Detector AGD326 Pedestrian Detector Up to 10m...
- Page 19 350-100:CH4 350-100:CH3 Pedestrian On-Crossing 350-100:CH2 Detector 350-100:CH1 343-501:CH2 343-500:CH4 TRANSMIT CHANNELS - TYPICAL SCENARIOS 343-500:CH3 24.100G, 9M Table 1: AGD 24GHz Radar Channels 24.094G, 1M 24.200G, 13M 318 USA:CH2 318 USA:CH1 318 Europe:CH2 318 Europe:CH1 326:CH4 326:CH3 326:CH2 326:CH1 306:CH2 306:CH1 24.05...
-
Page 20: Troubleshooting
Detector PHYSICAL INSTALLATION What height should the AGD326 be mounted at and what angle of declination is recommended? The 326 should be mounted at a nominal height of between 2-4 metres from ground level and have a clear view of the pedestrian crossing area to be covered with no obstructions from other street furniture for correct operation. -
Page 21: Connecting / Commissioning
GUI) and up to 10 metres wide depending upon the width setting. I’ve noticed that the AGD326 has a front detect LED. Can this front LED be switched off? Yes, the front LED can be switched off via the GUI. -
Page 22: Radar Characteristics
ITU Code 70MOFXN Centre Frequency for USA & Canada FCC variant 24.125 GHz (2 channels) The WiFi frequency and power is as follows: Frequency range (MHz): 2412 -2472 Highest EIRP power in the range (dBm): 18.52 AGD326 | PEDESTRIAN ON-CROSSING DETECTOR... -
Page 23: Frequency Variants
Licence Required for Use Frequency Allocated but EIRP too high It is important to note that this table is updated from time to time. Please contact AGD for latest information if your intended country of use is not currently represented. -
Page 24: 326 Field Pattern
AGD326 RADAR CHARACTERIISTICS Pedestrian On-Crossing Detector 326 FIELD PATTERN TX - Antenna Pattern Angle (º) ------- Elevation ------- Horizontal AGD326 | PEDESTRIAN ON-CROSSING DETECTOR... -
Page 25: Technical Specifications
Health & Safety: BS EN 62368, EN 60950-22, EN 50556, EN 62311 notice. Spectrum: EN 300 328, EN 300 440 RoHS RoHS: EN 50581 Other: TOPAS 2506A, AS/NZS 4268 NEMA TS 2 2016 COMPLIANT Specification TOPAS 2506A Restriction on Hazardous Substances AGD326 | PEDESTRIAN ON-CROSSING DETECTOR... -
Page 26: Certificates
AGD326 CERTIFICATION Pedestrian On-Crossing Detector AGD326 | PEDESTRIAN ON-CROSSING DETECTOR... -
Page 27: End Of Life - (Eol)
• Separate & Recycle Stainless Steel Metals, PVC, Nylon • A2 Stainless Steel Downcycle Metals, PVC, Nylon Polycarbonate EDPM • Hazardous Recovery Neoprene / SBR Rubber Polyester Aluminium Non -Recyclable Polyester Stainless Steel Polyester Polycarbonate AGD326 | PEDESTRIAN ON-CROSSING DETECTOR... -
Page 28: Safety Precautions
Under no circumstances should a product suspected of damage be powered on. Internal damage may be suggested by unusual behaviour, an unusual odour or damage to the outer casing. Please contact AGD for further advice. AGD326 | PEDESTRIAN ON-CROSSING DETECTOR... - Page 29 • The transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. • Changes or modifications not expressly approved by AGD Systems Ltd could void the user’s authority to operate the equipment. This Product is Compliant with the European Radio Equipment Directive 2014/53/EU.
-
Page 30: Important Safety Information
It is considered to be good practice not to subject humans to radiation levels higher than is necessary. In a works environment where multiple equipment on soak test are to be encountered then it is considered good practice to contain the equipment in an appropriate enclosure lined with radar absorbing material. AGD326 | PEDESTRIAN ON-CROSSING DETECTOR... -
Page 31: Disclaimer
Warranty All AGD products are covered by a 12 month return to factory warranty. Products falling outside this period may be returned to AGD Systems...
