- Page 1 Installation Instructions 10107002 Xiros Mikro Freeze Dryer Installation Instructions Version 1.0...
-
Page 2: Unpack The Equipment
Installation Instructions Users are advised to carefully read the Xiros Mikro User Manual prior to operating the freeze dryer so that they are aware of all precautions outlined and to ensure operation is in accordance with the instructions contained within the user manual. - Page 3 Installation Instructions Components Main Unit vacuum pump touch screen connector KF25 chamber door vent vacuum pump door lock power connector main unit power power switch connector vent drain valve Version 1.0...
- Page 4 Installation Instructions Other Components • Vacuum hose and KF 25 connectors • Clamps and sealing rings • Vacuum pump Anemos Or Aether 8 Eco Version 1.0...
- Page 5 Installation Instructions • Trays • Drain hose Assembling the Freeze Dryer 2.3.1 Connect the vacuum pump to the freeze dryer • The connector for the vacuum pump is located at the upper right corner at the back of the freeze dryer (Figure 1). ①...
- Page 6 Installation Instructions • Insert the sealing ring into the vacuum pump connector and place the clamp around the vacuum pump connector but do not tighten the clamp (Figure 2). Figure 2 • Connect the vacuum pump hose to the connector and then tighten the clamp as shown is Figure 3.
- Page 7 Installation Instructions 2.3.2 Connect the water drain hose to the freeze dryer • The connector for the drain hose is located to the left side of the freeze dryer (Figure 5). ① Figure 5 • Connect the drain hose to the connector and as shown in Figures 6, 7. ②...
- Page 8 Installation Instructions 2.3.3 Connect the freeze dryer to the power supply Figure 8 • Locate the power connectors for the main unit and the vacuum pump at the right side of the freeze dryer (Figure 8). • Connect the vacuum pump power plug to the vacuum pump power connector. •...
