- Page 1 Service Manual 10107002 Xiros Mikro Freeze Dryer Shelf Stack Installation Instructions Version 1.0...
- Page 2 Service Manual Xiros Mikro Freeze Dryer – Removing/Installing Shelf Stack Step 1 • Open the chamber door and confirm there is no ice build-up that will prevent removing the shelf stack. Carefully pull out the shelf stack. • Place the stack on the table next to the freeze dryer (see Figure 1). Ensure the connecting cable is not strained.
- Page 3 Service Manual Step 2 • Locate the plug assembly and press the release tabs to unplug the shelf stack from the freeze dryer. (See Figure 3) Figure 3 Version 1.0...
- Page 4 Service Manual Step 3 • When installing the shelf stack, identify the top and bottom of the plug before attempting to plug it in. Make sure to remove any moisture from the connection points. • Figure 4 and Figure 5 demonstrate the male plug. Figure 4 Figure 5 Version 1.0...
- Page 5 Service Manual • Figure 6 demonstrates the inside of a male plug. Figure 6 • Figure 7 demonstrates the female plug. Figure 7 Version 1.0...
- Page 6 Service Manual Step 4 • When reinstalling the shelf stack, ensure the connecting cable is not coiled underneath as in Figure 8. Figure 8 Step 5 • When reinstalling the shelf stack, gently push the shelving stacks halfway and ensure the connecting cable is behind the shelf stack, in a coiled format, so as to not affect the ice condensers efficiency (see Figure 9 and 10).
- Page 7 Service Manual Figure 9 Figure 10 Version 1.0...
