- Page 1 User Manual 10107002 Xiros Mikro Freeze Dryer User Manual Version 1.0...
-
Page 2: Table Of Contents
User Manual Table of Contents Disclaimer & Warranty ..................... 3 LIMITED WARRANTY & DISCLAIMER ................3 LIMITATION OF LIABILITY ....................5 Safety ........................6 III. Introduction ......................7 After Sales Support ....................7 Proper Use ......................7 Technical Specifications ..................8 Inspection ......................... -
Page 3: Disclaimer & Warranty
User Manual Disclaimer & Warranty • The intellectual property rights for this manual belongs to Holland Green Science Corporation (hereinafter referred to as “the Company”). • Products of the company are under the patent protection of China and other countries and regions (inclusive of obtained patents and patents currently under application). - Page 4 User Manual & Conditions agreed to by the purchase of this product. Consumables are expressly excluded from this warranty. Notwithstanding the foregoing, Products supplied by the Company but not manufactured by the Company are not warranted by the Company, and the Company disclaims all warranties associated with the accuracy of any original manufacturer or third-party supplier Product information, but the Company agrees to assign to Buyer any warranty rights in such Product that the Company may have from the original manufacturer or third-party supplier, to the...
-
Page 5: Limitation Of Liability
User Manual DEALING, OR USAGE OF TRADE). THIS WARRANTY IS NOT TRANSFERABLE FROM THE ORIGINAL PURCHASER TO A SUBSEQUENT OWNER. FURTHER, THE COMPANY IS NOT LIABLE IN CASES OF DELIBERATE, NEGLIGENT OR ACCIDENTAL MISUSE OF THE PRODUCTS, USE WITH INAPPROPRIATE REAGENTS OR CONSUMABLES, DAMAGE CAUSED BY DISASTER, REPAIR OR MODIFICATIONS DONE BY ANYONE OTHER THAN THE COMPANY. -
Page 6: Safety
User Manual Safety ! DANGER (may cause serious damage to property and or casualties) Please carefully read this User Manual prior to operating the instrument and observe and verify that all connections are properly secured. Utility requirements: Please ensure that the electrical connections meet the local standards and that the power supply is compatible with the Instrument nameplate. -
Page 7: Introduction
User Manual III. Introduction Users are advised to carefully read this manual prior to operating the freeze dryer so that they are aware of all precautions outlined and to ensure operation is in accordance with the instructions contained within this manual. After Sales Support If problems are encountered or technical support is required when installing or using the instrument, please contact serviceusa@hollandgreenscience.com... -
Page 8: Technical Specifications
User Manual Technical Specifications Model 10107002 Product Name Xiros Mikro Product Weight 80 kg Rated Voltage 110 v/Single Phase Rated Frequency 60 Hz Rated Power 1550 W ≤ -40 °C Cooling Temperature ≤ 25 Pa (empty load) Final Vacuum Maximum Water Capacity... -
Page 9: Inspection
User Manual Inspection Packing List Unpack the equipment carefully and check for any damage which may have arisen during transport. In the event of identified damage, please contact serviceusa@hollandgreenscience.com The package includes the following items Item Description Quantity Main Unit Vacuum Hose Clamps Sealing Ring... -
Page 10: Precautions
User Manual Precautions • The power supply should be connected to the electrical outlets safely. It is important that anyone using this equipment do so with dry hands and dry shoes to minimize the risk of electric shock. • A 120VAC 60Hz power supply is required for the freeze dryer operation. Any alternative supply voltage or frequency may damage the freeze dryer reduce its working lifespan. -
Page 11: Components
User Manual VII. Components Main Unit vacuum pump touch screen connector KF25 vent chamber door vacuum pump door lock power connector main unit power power switch connector vent drain valve Version 1.0... -
Page 12: Other Components
User Manual Other Components • Vacuum hose and KF 25 connectors • Clamps and sealing rings • Vacuum pump • Tray Version 1.0... -
Page 13: Assembling The Freeze Dryer
User Manual • Drain hose Assembling the Freeze Dryer 7.3.1 Connect the vacuum pump to the freeze dryer • The connector for the vacuum pump is located at the upper right corner at the back of the freeze dryer (Figure 1). ①... - Page 14 User Manual • Connect the vacuum pump hose to the connector and then tighten the clamp as shown is Figure 3. Please note that the clamp only needs to be done up finger tight – excessive tightening may cause damage to the fittings. ③...
-
Page 15: Connect The Water Drain Hose To The Freeze Dryer
User Manual 7.3.2 Connect the water drain hose to the freeze dryer • The connector for the drain hose is located to the left side of the freeze dryer (Figure 5). ① Figure 5 • Connect the drain hose to the connector and as shown in Figures 6, 7. ②... -
Page 16: Connect The Freeze Dryer To The Power Supply
User Manual 7.3.3 Connect the freeze dryer to the power supply Figure 8 • Locate the power connectors for the main unit and the vacuum pump at the right side of the freeze dryer (Figure 8). • Connect the vacuum pump power plug to the vacuum pump power connector. •... -
Page 17: Operation Instructions
User Manual VIII. Operation Instructions Before running the freeze dryer, please check and ensure that: • There is no residual water or foreign matter inside the chamber. • The drain valve is closed. • The vacuum pump is connected to the freeze dryer correctly. •... -
Page 18: Manual Freeze-Drying Mode
User Manual 8.1 Manual freeze-drying mode To enter the “Manual Control” page, click on the “Manual” button (Figure 11). Figure 11 Figure 12 The “Manual Control” page has the flowing functions: • Manual Control On/Off: click “On” to enter Manual Control Mode (Figure 12). Version 1.0... - Page 19 User Manual • Note, once Manual Control Mode has started, you can still go into the “Program Mode” to edit the programs. However, you will not be able to start a recipe under the “Program Mode” when Manual Control Mode is running. A warning message will come up if “Program Mode”...
- Page 20 User Manual • Turn On/Off the following equipment as desired: vacuum pump, compressor, heater upper, heater lower, vacuum valve (Figure 15). Figure 15 • When the freeze-drying process is finished, open the drain valve first and when the chamber is unpressurized, open the door to retrieve the product. •...
-
Page 21: Program Mode
User Manual 8.2 Program Mode Click on “Program” on the home screen to enter the “Recipe Selector” page (Figure 16). Figure 16 The “Recipe Selector” page has the following functions” • “Flower”: used to freeze dry flowers. • “Bubble Hash”: used to freeze dry bubble hash. •... - Page 22 Best possible drying parameters can vary significantly depending on factors such as plant genetics, terpene profiles, product size and moisture content. Holland Green Science cannot guarantee that our recommended parameters suit your needs. They are solely intended to provide you with a starting point to your freeze-drying tasks.
- Page 23 User Manual • Click on individual parameter that you wish to change, enter the new value. • There are a total of 16 steps available. Even though not all steps need to have values, all steps are done in sequence. No blank step should be left between steps (A blank step would indicate the process is finished).
- Page 24 User Manual Figure 21 • The “Freezing” page displays real-time values of the shelf-temperature lower, chamber temperature, shelf-temperature upper and system vacuum (Figure 21). • The “Freezing” page also displays the current processing step. There are five processing steps, and they are “Precooling”, “Evacuating”, “Primary Drying”, “Secondary Drying”...
- Page 25 User Manual Figure 23 • When the processing step indicates “Product Storage” (Figure 23), the Program freeze-drying process is finished. Open the drain valve and wait for the chamber pressure to return to normal before opening the chamber door to retrieve the product (Figure 24).
-
Page 26: Defrost Mode
User Manual 8.3 Defrost mode When the freeze-drying process is finished, the user can click “Defrost” on the home screen to enter “System Defrost” page (Figure 25). Note, the user can also use the “Defrost” function before any freeze-drying process to defrost the chamber if needed. Figure 25 Before starting the “Defrost”... - Page 27 User Manual Click on “Start” to start the defrost process. The “System Defrost” page will display the real-time values of the temperature for the lower and upper shelf chamber temperatures (Figure 27). Click on “CANCEL” to stop the defrosting process. This will cause the system to return to the home screen.
-
Page 28: System Settings
User Manual 8.4 System settings Figure 28 Click “Settings” on the home screen (Figure 28). The following settings can be defined by user: password, time, screen save (Figure 29). Figure 29 Version 1.0... -
Page 29: History Data
User Manual 8.5 History data To recover process history, click “History” on the home screen (Figure 30). Figure 30 Then click “PAGE UP” and “PAGE DOWN” to view the history data (Figure 31). Click “DATA EXPORT” to export the history data. Data can be exported to a USB stick inserted in the USB port on the side of the freeze dryer. -
Page 30: Fault Diagnosis
User Manual Fault Diagnosis Error Solutions Check that the vacuum pump is correctly connected to the main unit with the clamp (tightly). Check that the drain valve is closed. Ultimate vacuum can’t Check that the sealing ring is installed correctly. reach 50 Pa Check that the vacuum pump functions correctly and the vacuum pump oil is clear. -
Page 31: Cleaning And Maintenance
User Manual X. Cleaning and Maintenance 10.1 Cleaning • Condensation from the product may participate inside of the chamber, please be sure to clean the inside of the chamber periodically by wiping off any the chamber walls. Clean the trays after every freeze-drying process with detergent. Wipe dry afterwards. -
Page 32: Terms Explained
User Manual XI. Terms Explained Figure 32 • Prefreeze Time: When the “Frozen product” option is switched “OFF” in the Recipe Selector page (Figure 33), meaning the product is not frozen, the program will start cooling the product once the auto-drying program starts. The program will move to the next stage (Evacuation stage) only when the shelf temperature has been lower than the Prefreeze Temp for the duration set in the Prefreeze Time. - Page 33 User Manual Figure 34 • Evacuation Time: Evacuation Time and Vacuum are used to control the evacuation stage. The program will turn the vacuum pump on when the evacuation stage begins. The program will progress to the next stage, the drying stage, when the chamber pressure has been lower than the pressure set in Vacuum for the duration set in the Evacuation Time.
- Page 34 User Manual • Vacuum Low Limit: see Vacuum High Limit. Figure 36 • Vacuum Hysteresis: Vacuum Hysteresis is used as the maximum allowable overshoot of the chamber pressure when the chamber pressure is controlled by the program via the vacuum valve. During each drying step, the range of the chamber pressure is between the current step’s target Vacuum - 5Pa and the target Vacuum + Vacuum Hysteresis.
- Page 35 User Manual • Process End Temperature: Process End Temperature and Process End Pressure are used to hold the machine until an operator makes any changes once the drying program is completed. • Process End Pressure: see Process End Temperature. • Maximum Shelf Temperature: Maximum Shelf Temperature is a safety limit to prevent the shelves from reaching a temperature which may damage the product.
